LFB BMW/Mercedes/Smart/VW 40Pin Quadlock

SKU:  42A-1190-003
EAN:  4026724672558

Technical Highlights

  • CAN Bus connector: 40 pin Quadlock, compatible Mercedes vehicles.
  • Active system adapter MOST>Cinch, supports Mercedes/Porsche.
  • Item number 13-1190-52-1, ensures optimal connection.
  • More technical details
