Rockford Fosgate

Color Optix M1D2-10 / M1D4-10

10" (25cm) Subwoofer

239,00€
239,00€ 239,00€
incl. VAT , possibly plus shipping

Stock options

Zahle in 3 zinsfreien Raten von 79,66€ mit Klarna. Mehr erfahren

Highlights

  • 300 watts RMS, 1200 watts MAX, 1-ohm/4-ohm impedance.
  • 91.5 dB sound pressure level, 20 Hz 750 Hz frequency response.
  • Element Ready™ design, IPX6 certified, UV and water resistant.
Impedance: D2 (2x2 Ohm)
Seen more cheaply Personal Offer
brand: Rockford Fosgate
Delivery time:
Available, in 2-5 days with you
Number:
Piece
Watt RMS:
300
Subwoofer Type:
ferrite
Expert Image

Rob

Expert Image

Max

E-Mail Beratung von Experten

Werktags innerhalb von 24h

info@masori.de

HertzHMS 10 B-2
Hertz-HMS 10 B-2-10" (25cm) Subwoofer-masori-kaufen
Accuton-AS250-6-552-10" (25cm) Subwoofer-masori-kaufen
AccutonAS250-6-552
Rockford Fosgate-Color Optix M1D2-10 / M1D4-10-10" (25cm) Subwoofer-masori-kaufen
239,00€
239,00€ 239,00€

The M1D2-10 Color Optix™ 10-inch subwoofers deliver loud, clear, and precise bass, paving the way for your journey! The subwoofers can be connected to the Rockford Fosgate Color Optix™ controller and the RF Connect app, allowing you to customize your own color patterns. Thanks to the Element Ready™ design and IPX6 certification, they are specifically designed for marine or motorsport applications where protection from harmful UV rays and splashes is essential.

Technical Features
  • Optically clear, UV-stable RGB lighting encapsulation
  • Ultra-bright wide-angle RGB LEDs provide rich, reliable lighting.
  • 2" (50 mm) High-Temperature Kapton™ Voice Coil
  • Ventilated motor design with water-repellent nano-coated mesh screen
  • The industry's first in-frame connectors for easy connectivity in addition to conventional flat plug connections.
  • Linear spiders made from synthetic fiber blend
  • Connection terminals made of galvanized and nickel-plated brass in marine quality
  • Santoprene VAST Sick
  • The VAST Vertical Attach Surround technology increases the effective diaphragm area by up to 25%.
  • The VERSA impedance switch allows for quick series or parallel configuration without additional wiring.
Technical Data
  • Size 10"
  • Impedance D2 (Ohm): 1 Ohm or 4 Ohm, switchable
  • Impedance D4 (Ohm): 2 Ohm or 8 Ohm, switchable
  • Load capacity (RMS): 300 Watts
  • Load capacity (MAX): 1200 Watts
  • Swaging coil diameter: 2.0" (50 mm)
  • Magnet weight: 1.35 kg
  • Swing coil type: double swing coil
  • Frequency response: 20 Hz - 750 Hz
  • Fs (Hz): 34
  • Ohms: 3.7
  • Le (mH): 2.22
  • Sd (cm2): 394.1
  • Qms: 7.80
  • Qes: 0.47
  • Qts: 0.44
  • Vas: 44.2
  • Sound pressure level (dB at 1 W/1 m): 91.5
  • Woofer displacement: 2.80 liters
  • Xmax (mm): 7.0
  • Cutout diameter: 226 mm
  • Mounting depth: 107.4 mm
  • Shipping weight: 3.9 kg
The Rockford Fosgate Color Optix M1D2-10 is a 10-inch subwoofer with a switchable impedance of 1 or 4 ohms thanks to its dual voice coil. With an RMS power of 300 watts and a maximum handling capacity of 1200 watts, it is ideal for loud, clear bass. The 2-inch high-temperature Kapton™ voice coil and a vented motor design, protected by a nano-coated mesh screen, provide additional protection and efficiency. With a sound pressure level of 91.5 dB and a resonance-free mounting, it is suitable for demanding applications in marine and motorsport.
These subwoofers utilize visually clear, UV-stable RGB lighting enclosures that provide stable and intense illumination over wide angles. The ultra-bright wide-angle RGB LEDs ensure a rich color presence that can be individually adjusted using the Rockford Fosgate Color Optix Controller and the RF Connect app. With this connectivity, you can customize your color patterns, creating an impressive visual presentation specifically designed for locations with strong light exposure, such as in marine or motorsport applications.
The VAST (Vertical Attach Surround Technique) in the Color Optix M1D4-10 subwoofers increases the effective diaphragm area by up to 25%. This technique allows for more air movement than traditional designs, thereby improving overall output and bass reproduction. The Santoprene VAST surround provides a larger diaphragm area, which not only delivers more bass volume but also enhances the performance and sound quality of the subwoofer in demanding environments such as marine applications.
The Rockford Fosgate Color Optix M1D2-10 subwoofer has the following Thiele/Small parameters: a resonant frequency (Fs) of 34 Hz, a mechanical quality factor (Qms) of 7.80, an electrical quality factor (Qes) of 0.47, and a total quality factor (Qts) of 0.44. The equivalent air volume (Vas) is 44.2 liters. These parameters indicate the subwoofer's ability to produce deep and powerful bass and how it behaves in sealed or vented enclosures. The high Qms value optimally supports use in open, vented systems.
The installation of the Rockford Fosgate Color Optix Subwoofer is simplified by the innovative in-frame connectors. These allow for a quick and straightforward connection to your audio system, in addition to conventional flat plug connections. The mounting depth is 107.4 mm, which allows for convenient installation in many vehicles, provided that the cutout diameter of 226 mm can be accommodated. Another highlight is the VERSA impedance switch, which enables quick adjustments of the impedance without additional wiring.
The Color Optix M1D4-10 is specifically designed for marine requirements. The Element Ready™ design and IPX6 certification ensure that the subwoofer is protected against harmful UV rays as well as water splashes. The ventilated motor design with water-repellent nano-coated mesh grille provides additional protection in humid and salty environments. Together with the marine-grade terminals made of galvanized and nickel-plated brass, this guarantees a long lifespan and reliable performance under demanding conditions at sea.
The Color Optix M1D4-10 offers enhanced bass performance with a dual coil configuration that provides switchable impedances of 2 or 8 ohms. It features an RMS power handling of 300 watts and a peak power handling of 1200 watts. The robust construction with a voice coil diameter of 2.0 inches (50 mm) allows for a frequency response of 20 Hz to 750 Hz, enabling deep and powerful bass sound. Designed for discerning music lovers, this subwoofer is the ideal addition to high-performance audio systems.
Whether the Color Optix M1D2-10 fits in your vehicle depends on the available installation opening. With a mounting depth of 107.4 mm and a cutout diameter of 226 mm, it is essential to match these dimensions with your vehicle. The subwoofer also requires space for the impressive 2.80 liters of displacement of the woofer. Ensure that there is sufficient depth and width in your car or boat to allow for the installation of this powerful component and that no other connections or structures are affected.
The Rockford Fosgate M1D4-10 subwoofer significantly enhances the audio experience in the vehicle with its powerful and precise bass. The advanced VAST technology and ultra-bright RGB LEDs not only provide impressive audio performance but also an optical enhancement. Even at high volumes, the sound remains deep and clear, as the dual voice coils allow for optimal impedance matching. This makes it ideal for car enthusiasts looking for an immersive sound experience that appeals to both the acoustic and visual senses.
In the Color Optix M1D2-10 Subwoofer, high-quality materials such as galvanized and nickel-plated brass are used for the connection terminals to ensure durable contacts. The voice coil is made of high-temperature Kapton™, known for its excellent heat resistance. The synthetic fiber blend of the linear spiders provides additional stability and performance under demanding conditions. The Santoprene VAST surround maximizes the diaphragm area, and the nano-coated protective grille offers protection against the elements, making it ideal for use in marine environments.

Audio Design Loudspeaker Sales GmbH
Am Breilingsweg 3
76709 Kronau
Germany

Authorized Managing Director:
Bruno Dammert

Contact: info@audiodesign.de

Product Specifications

Manufacturer

Rockford Fosgate

Product type

10" (25cm) subwoofer

Features

  • Highlights

    • 300 watts RMS, 1200 watts MAX, 1-ohm/4-ohm impedance.
    • 91.5 dB sound pressure level, 20 Hz 750 Hz frequency response.
    • Element Ready™ design, IPX6 certified, UV and water resistant.

  • Uvp

    239

weight

2.55 kg

Watt RMS Load Capacity

300

configurators

Recently viewed products

Masori-Komplettanlage Car HiFi mit DSP-Einbauservice-masori-kaufen
Masori-Akustikdämmung & Hitzeisolierung Dachhimmel-Einbauservice-masori-kaufen

Have it installed directly!

  • Individual products or entire systems
  • Insulation of doors and more
  • Calibration and system settings, as well as troubleshooting
  • And much more in our installation service in Frankfurt (Oder)
Learn more!

Your advantages with Masori

Buy Rockford Fosgate Color Optix™ M1D2-10 / M1D4-10 Subwoofer at a great price: Highlights and specifications

If you're looking to buy the Rockford Fosgate Color Optix™ M1D2-10 or M1D4-10 subwoofer at a great price, Masori offers a Lowest Price Guarantee to ensure you get the best deal. This 10-inch subwoofer is known for its loud, clear, and precise bass and allows for customization via the Color Optix™ controller and the RF Connect app. IPX6 certification and Element Ready™ design make them ideal for marine and motorsport applications. The M1D2-10/M1D4-10 features a 2 high-temperature Kapton™ voice coil for optimal power handling. VAST technology increases the effective cone area by a whopping 25% for more intense bass. These features combined offer an unparalleled car hi-fi experience.

Frequency response and power handling of the Rockford Fosgate subwoofer with 300 watts RMS

The Rockford Fosgate Color Optix™ M1D2-10 and M1D4-10 subwoofers offer an impressive frequency response from 20 Hz to 750 Hz. They have a solid 300 watts RMS power handling and can reach up to 1200 watts MAX. These ratings ensure the subwoofer is powerful enough to produce powerful and distortion-free sound, accurately reproducing even deep bass lines. This makes these subwoofers ideal for a variety of music styles and applications, whether offshore or in motorsports. A higher RMS rating could theoretically provide even more power, but 300 watts is already an excellent value for delivering excellent acoustics in car hi-fi applications.

Impressive 91.5 dB sound pressure level for optimal sound

With a sound pressure level of 91.5 dB at 1 W/1 m, Rockford Fosgate subwoofers efficiently deliver loud sound with minimal degradation in sound quality. Such high efficiency means the subwoofer doesn't require much power to produce impressively loud sounds. This is especially important for applications where efficiency and volume are critical, such as outdoor use. This makes them a strong contender in the car hi-fi sector. A lower efficiency would require higher power input to achieve similar volume levels.

Combination with Rockford Fosgate Color Optix™ Controller

A particular highlight of the M1D2-10 and M1D4-10 subwoofers is their seamless integration with the Rockford Fosgate Color Optix™ controller and the RF Connect app. This technology enables individual lighting adjustments directly from your smartphone, providing additional visual appeal and contributing to the personalization of your audio system. This combination makes the subwoofers ideal for use in stylish, distinctive in-car or on-water setups where individuality matters.

Simple impedance switching for maximum flexibility

The Rockford Fosgate models feature a VERSA impedance switch, which allows the impedance to be quickly adjusted between 1 ohm and 4 ohms for the M1D2-10, and 2 ohms and 8 ohms for the M1D4-10, without the need for additional wiring. This flexibility helps the user adapt to diverse amplifier specifications and system settings. The advantage is the ability to ensure the most efficient power delivery based on the individual requirements of your setup. Understandably, lower impedance draws more current from the amplifier, delivering more volume, while higher impedance results in a more concerted performance.

Technical details on voice coil and magnet weight

A key technical feature is the 2 (50 mm) high-temperature Kapton™ voice coil. A solid 1.35 kg magnet weight ensures consistently strong magnetic interaction, resulting in precise bass projection. This specific combination of voice coil and magnet weight contributes significantly to the subwoofer's longevity and performance. A lighter voice coil could increase responsiveness, but the current balance offers a proven combination of power and stability in use.

Alternative connection options for maximum connectivity

For the first time in the industry, the M1D2-10 and M1D4-10 subwoofers feature in-frame connectors. These simplify installation and, combined with traditional flat-pin terminals, offer an exceptionally simple connectivity approach. The premium terminals, made of zinc- and nickel-plated brass, are marinized for corrosion resistance. This feature allows for flexible integration into various systems, which is particularly important for users with specific or complex setups. A less versatile connectivity solution would offer fewer customization options.

Intelligent design: VAST technology and synthetic spiders

Rockford Fosgate's unique VAST Vertical Attach Surround technology also significantly expands the usable area for sound production by up to 25%. This further enhances clear and powerful bass performance. Linear spiders made from synthetic fiber blends are also used. These contribute to overall stability and respond flexibly under pressure, ensuring consistent sound under varying load conditions. This makes this technology well worth the price—especially in demanding soundscapes where performance counts.

Optimized motor design with nano-coated mesh screen

A vented motor design, equipped with a water-resistant nano-coated mesh screen, ensures the durability and performance of Rockford Fosgate subwoofers under extreme conditions. These technological features are critical to preventing environmental influences on sound performance and ensuring longevity in locations with particularly high humidity or direct sunlight. A substandard coating would have drastically increased the risk of corrosion and reduced efficiency over time.

Mounting instructions for easy installation with 107.4 mm depth

The Rockford Fosgate subwoofer can be flexibly integrated into a wide variety of installation situations thanks to its 107.4 mm mounting depth and 226 mm cutout diameter. Its 2.80-liter woofer displacement ensures it's relatively space-saving without compromising on performance. This is supported by a shipping weight of 3.9 kg, which simplifies installation. These optimized dimensions allow for installation in enclosures of various sizes, providing versatile placement options. ***INCLUDES SUPPORT LINKS*** If you need further support with the integration or have questions about the use of the subwoofers, please visit our on-site installation in Frankfurt (Oder) , our comprehensive expert support FAQ & Help , or our informative audio blog .
