DD Audio SS4.1300 4-channel amplifier

Name: DD Audio SS4.1300 4-Channel Amplifier | Masori
Brand: DD Audio
Price: 296.65 EUR
Availability: InStock
Rating: 5.0 (1 reviews)

1 Review

CYBER -15%

Max, Mikael and 53k+ customers already with Masori sound upgrade

DD Audio SS4.1300 4-channel amplifier

1 Review

Continuous power at 4 ohms: 180W x 4/650W x 2, at 2 ohms: 325W x 4.
Input voltage sensitivity: RCA 6-0.25V, high level 20-1.1V.
Crossovers: 12 dB/oct. high-pass filter 35-600 Hz, 20 mm² connectors.
Mehr technische Details

00

€296,65

~~€349,00~~ €296,65

5% Rabatt mit Vorkasse

inkl. VAT , possibly plus shipping

Bequem in 12 zinsfreien Raten à €24,72 mit Klarna zahlen.

Jetzt mit kostenlosem Versand ab 50€!

Shipping cost calculator

Land/Region

PLZ

Garantie & zusätzlicher Geräteschutz für dein HiFi-System

3 Jahre Masori Garantie Kostenlos 48 Monate Plusgarantie €24,99 60 Monate Plusgarantie Am beliebtesten €34,99

Deshalb wählen uns 100.000+ Kunden

3 Jahre Garantie

Sicher & sorglos
Blitzversand

mit DHL Express
Tiefpreisschutz

Nie zu viel zahlen

Rob

Max

Unsicher, ob dieses Produkt zu deinem Auto passt?

Wir helfen dir – schnell, persönlich und unverbindlich.

Antwort on weekdays within 24h

FOR-XXAM-200.4

RebecES4s

SS4.1300 by DD Audio

The SS4.1300 from DD Audio is a powerful 4-channel amplifier that stands out for its versatile features. With high-level inputs and 12 dB/oct. high-pass/low-pass crossovers, it offers flexible application possibilities. The heavy DD aluminum housing ensures stability and durability. Thanks to the 20mm² power connections, optimal power supply is guaranteed. Its technical specifications include a operating voltage of 9–16V, a maximum current draw of 150 Amperes, and a frequency response of 20 - 20kHz. The compact design with dimensions of 159 x 117 x 50 mm facilitates installation.

features

High Level Inputs
12 dB/oct. high-pass/low-pass crossovers
Heavy DD aluminum housing
20mm² power connections

Technical Data

Operating voltage: 9–16V
Continuous power at 4 Ohms: 180 Watts x 4 / 650 Watts x 2
Continuous power at 2 Ohms: 325 Watts x 4
Max. current consumption (Amperes): 150
RCA input voltage sensitivity: 6 - 0.25
High level input voltage sensitivity: 20 - 1.1
RCA input signal noise ratio: > 95
Damping factor: > 100
THD: < 1.0 %
Frequency response (Hz): 20 - 20kHz
High-pass filter: 35 - 600Hz
Low-pass filter: 35 - 600Hz
Power cable thickness: 20mm²
Speaker cable thickness: 2mm²
Dimensions (mm): 159 x 117 x 50

Frequent questions about SS4.1300

Welche Betriebsspannung unterstützt der SS4.1300 Verstärker von DD Audio?

The DD Audio SS4.1300 amplifier operates reliably within a supply voltage of 9 to 16 volts. This flexibility allows for stable operation even under varying vehicle voltage fluctuations. Especially in vehicles with start-stop systems or in vehicles with an enhanced electrical system, this voltage range ensures continuous and powerful audio output. The adaptability to such a wide voltage range makes this amplifier an excellent choice for car audio enthusiasts who expect the same high standard in different vehicle environments. A detailed and clear sound is thus guaranteed, regardless of the respective voltage conditions.

Wie viel Leistung liefert der Verstärker SS4.1300 bei verschiedenen Impedanzen?

The SS4.1300 amplifier from DD Audio offers impressive performance. At an impedance of 4 ohms, it delivers a continuous power of 180 watts per channel with four channels or 650 watts per channel with two channels. When you switch to a lower impedance of 2 ohms, the power increases to 325 watts per channel with four channels. This flexibility in power output allows for the efficient operation of a variety of speaker systems and maximizes the full potential of the audio system while maintaining sound quality.

Welche Signal-Rausch-Abstände bietet der SS4.1300 Verstärker von DD Audio?

The DD Audio SS4.1300 amplifier impresses with high signal-to-noise ratios. For the RCA inputs, this value is over 95 dB. This means that unwanted background noise is minimized and a clear, distortion-free sound is ensured. The high signal-to-noise ratio is essential to fully exploit the potential of your music without losing details in distracting noise. This is especially important with high-quality audio sources, where every nuance counts, and allows for an acoustically uplifting listening experience in any driving situation.

Wie sieht der Frequenzgang des SS4.1300 Verstärkers aus?

The frequency response of the SS4.1300 amplifier from DD Audio ranges from 20 Hz to 20 kHz. This covers the entire range audible to the human ear and ensures a full, dynamic sound reproduction. Within this frequency range, both high-pass and low-pass filters at 35 to 600 Hz guarantee the perfect adaptation of the audio signal to the speakers. These filters allow for targeted control of frequency adjustment, so you can precisely implement your sound preferences, whether it's pumping rich bass or crystal-clear reproduction of high tones.

Welche Maße hat der DD Audio SS4.1300 Verstärker?

The dimensions of the DD Audio SS4.1300 amplifier are 159 mm in length, 117 mm in width, and 50 mm in height. Thanks to these compact measurements, the amplifier is easy to install in various vehicles. Due to its size, it fits effortlessly under seats or behind panels without sacrificing power and functionality. Its robust aluminum chassis not only provides stability to the device but also protects it from external influences, giving more room and flexibility for installation and placement.

Welche Eingangsoptionen bietet der Verstärker SS4.1300?

The SS4.1300 amplifier from DD Audio is equipped with variable input options. These include high-level inputs as well as RCA inputs. The RCA inputs have a voltage sensitivity between 6 and 0.25 volts, while the high-level inputs offer a sensitivity of 20 to 1.1 volts. This flexibility ensures that the amplifier is compatible with both factory-installed and aftermarket audio sources. The user can thus optimally utilize any desired audio input, allowing for maximum adaptation to different audio systems.

Welches Material wird beim Gehäuse des SS4.1300 Verstärkers verwendet?

The SS4.1300 amplifier from DD Audio features a heavy aluminum housing. This material not only offers impressive strength and durability but also excellent shielding against electromagnetic interference. Additionally, aluminum is lightweight, making installation in the vehicle comfortable without compromising vehicle dynamics. This choice of housing improves the heat dissipation of the device, thus providing reliable performance even under intense use. The combination of robustness and functionality makes it ideal for demanding audio applications.

Welche Filtermöglichkeiten bietet der DD Audio SS4.1300?

The DD Audio SS4.1300 amplifier is equipped with 12 dB/octave high-pass and low-pass crossovers. These allow for precise adjustment of the frequency response from 35 Hz to 600 Hz to realize your sound preferences. Such filters enable you to specifically control the bass and treble frequencies and tailor them to your specific audio profile. This is particularly important to minimize distortion and individualize the sound, allowing for a more intense and customized listening experience, depending on the requirements of your speaker configuration.

Wie hoch ist der Dämpfungsfaktor des Verstärkers SS4.1300?

The damping factor of the SS4.1300 amplifier from DD Audio is over 100. Such a damping factor guarantees precise control over the movement of the speaker diaphragm, especially at low frequencies. The control over diaphragm movements allows for more precise and detailed bass reproduction, which is a significant advantage, especially with complex musical pieces or at high volume levels. This enables the amplifier to ensure clear, uncolored sound reproduction without distortions affecting the enjoyment of the music.

Welche Strom- und Lautsprecherkabelstärken werden beim SS4.1300 verwendet?

The SS4.1300 amplifier from DD Audio uses 20mm² power cables and 2mm² speaker cables. These cable sizes are crucial to ensure sufficient power and signal transmission capacity, which is particularly advantageous under high power demands. The choice of these cable cross-sections allows for minimizing electrical losses, thereby increasing both efficiency and sound quality. Additionally, the reduced resistance of the cables can achieve surprisingly clear sound characteristics, especially when reproducing critical musical elements.
