Rockford Fosgate Punch P1S2-15 / P1S4-15 15" (38cm) Subwoofer

1 Review

Power handling RMS 250 watts, impedance 2 ohms or 4 ohms.
Kevlar fiber reinforced paper cone, VAST technology.
StampCast basket, integrated spider vent, ABS trim ring.
Mehr technische Details

€199,00

~~€199,00~~ €199,00

5% Rabatt mit Vorkasse

inkl. VAT , possibly plus shipping

Bequem in 12 zinsfreien Raten à €16,58 mit Klarna zahlen.

Jetzt mit kostenlosem Versand ab 50€!

Impedance: S4 (1x4 Ohm)

S2 (1x2 Ohm)
S4 (1x4 Ohm)

Shipping cost calculator

Land/Region

PLZ

Garantie & zusätzlicher Geräteschutz für dein HiFi-System

3 Jahre Masori Garantie Kostenlos 48 Monate Plusgarantie €14,99 60 Monate Plusgarantie Am beliebtesten €19,99

Deshalb wählen uns 100.000+ Kunden

3 Jahre Garantie

Sicher & sorglos
Blitzversand

mit DHL Express
Tiefpreisschutz

Nie zu viel zahlen

Rob

Max

Unsicher, ob dieses Produkt zu deinem Auto passt?

Wir helfen dir – schnell, persönlich und unverbindlich.

Antwort on weekdays within 24h

Punch P1S2-15 / P1S4-15 by Rockford Fosgate

The Rockford Fosgate P1S2-15 and P1S4-15 15-inch subwoofers are the first members of a world-famous subwoofer family called "The Punch." When introduced in the 1980s, they quickly became "The Woofer of Choice" for fanatical car audio systems, a tradition that continues to this day. The Kevlar-reinforced paper cones deliver a noticeable bass impact, and Rockford Fosgate's VAST technology increases the cone area by up to 25%. Perfectly suited for sealed and vented bass reflex enclosures. Includes soft-touch ABS trim ring.

Features

Linear spider with embedded 4mm² lamellar leads
High-temperature voice coil with spun Nomex® reinforcement collar
Kevlar fiber reinforced paper cone
StampCast basket with integrated spider venting
Rubberized ABS trim ring with optional grille
Custom 10-AWG nickel-plated push terminals
Extended pole shoe and compressed, vented backplate
Protective, textured PVC magnet cover

Specifications

15-inch subwoofer
RMS power handling 250 watts
Max power handling 500 watts
Magnet weight: 1.70 kg
Voice coil diameter: 51.6 mm
Mounting depth: 177.2 mm
Driver displacement: 4.2 liters
Cutout diameter: 351.8 mm
Shipping weight: 7.98 kg
Available in single 2-ohm and single 4-ohm impedance
2 Ohm Version:

Nominal impedance: 2 ohms
Voice coil type: Single voice coil
Qts: 0.55
Fs (Hz): 23
Qes: 0.80
Qms: 3.46
Vas (liters): 191.5
Re (ohms): 1.8
Le (mH): 1.12
Sd (cm²): 876
SPL (dB @ 1w/1m): 87
SPL (dB @ 2.8v/1m): 90
Xmax (mm): 9.0
Sealed enclosure volume (Vb): 44.7 liters
Bass reflex enclosure volume (Vb): 75.3 liters

4 Ohm Version:

Nominal impedance: 4 ohms
Re (ohms): 3.60
Sd (cm²): 876
Fs (Hz): 23
Qts: 0.55
Qes: 0.62
Qms: 3.20
Vas (liters): 191.5
Le (mH): 3.14
SPL (dB @ 1w/1m): 87
Xmax (mm): 9.0
SPL (dB @ 2.8v/1m): 90
Sealed enclosure volume (Vb): 44.7 liters
Bass reflex enclosure volume (Vb): 75.3 liters

Frequent questions about Punch P1S2-15 / P1S4-15

Welche Unterschiede gibt es zwischen dem Punch P1S2-15 und P1S4-15 Subwoofer?

The main differences between the Punch P1S2-15 and the P1S4-15 from Rockford Fosgate lie in the impedance and electrical properties. The P1S2-15 has a nominal impedance of 2 ohms, while the P1S4-15 operates with 4 ohms of impedance. These differences affect the circuit matching in your car audio system. However, both models share other technical features, such as a Kevlar fiber-reinforced paper cone and a voice coil with a Nomex® reinforcement collar. Regarding power handling, both versions are rated for 250 watts RMS and a maximum of 500 watts. The choice between the two depends on your specific amplifier setup.

Wie beeinflusst die VAST-Technologie die Leistung des Punch P1S2-15 Subwoofer?

The VAST technology (Vertical Attach Surround Technique) from Rockford Fosgate in the Punch P1S2-15 subwoofer increases the diaphragm area by up to 25%, resulting in more powerful bass. This technology maximizes the cone area by modifying the surround profile. In practical use, this means you can hear richer and deeper bass without changing the required speaker area. Especially if you enjoy listening to music loudly, this technology gives you the opportunity to enjoy even more intense sound experiences. This innovation is particularly noteworthy for compact setups in the car.

Welche technischen Merkmale unterstützen die Bassleistung des Punch P1S4-15?

The Punch P1S4-15 subwoofer utilizes a range of technical features to deliver outstanding bass performance. This includes the Kevlar-reinforced paper cone, which ensures clear and precise bass reproduction. The high-temperature voice coil with spun Nomex® reinforcement collar enhances thermal stability and performance, especially at high volumes. Complemented by the StampCast basket with integrated spider ventilation, the subwoofer ensures effective cooling. The extended pole piece and vented back plate also contribute to thermal efficiency, which is beneficial for demanding bass requirements.

Welche Kompatibilitätsüberlegungen sollten beachtet werden bei der Installation im Auto?

When installing the Rockford Fosgate Punch P1S2-15 or P1S4-15 in your vehicle, the dimensions are crucial. With a mounting diameter of 351.8 mm and a mounting depth of 177.2 mm, these subwoofers fit into numerous enclosure configurations. The recommended volume for sealed enclosures is 44.7 liters and for bass reflex enclosures is 75.3 liters, making installation in various car models easier. These measurements are particularly important to ensure that the subwoofer has the necessary space both in the enclosure and in the vehicle, without compromising sound quality.

Welche elektrischen Parameter sind wichtig für die Installation?

For the installation of the Punch P1S2-15 or P1S4-15 subwoofers, various electrical parameters are important. The nominal impedance of 2 ohms or 4 ohms determines compatibility with your amplifier. An RMS value of 250 watts and a maximum of 500 watts indicates the power capacity. The Qts value of 0.55 affects the resonance properties. Other parameters such as Re, Le, and Vas (191.5 liters) play a role in frequency adjustment and dynamics. These technical characteristics are crucial to ensure optimal sound quality in conjunction with other audio components.

Wie tragen die Thiele-Small Parameter zur Leistung des Punch P1S2-15 bei?

The Thiele-Small parameters are crucial for the performance of the Punch P1S2-15 subwoofer. The high Vas value of 191.5 liters indicates how much air the subwoofer can move, which is beneficial for deep bass. With an Fs of 23 Hz, the subwoofer is capable of accurately reproducing very low frequencies. The Qts value of 0.55 shows the balance between mechanical and electrical damping, ideal for various enclosure types. These parameters help to understand how the subwoofer will perform in different acoustic environments and assist you in choosing the appropriate enclosure types.

Welche Materialien wurden für die Konstruktion des Punch P1S2-15 verwendet?

The Punch P1S2-15 subwoofer is characterized by its high-quality material selection, which is crucial for its durability and performance. The cone is reinforced with Kevlar fibers, which not only allows for extreme robustness but also precise sound at high volumes. The high-temperature voice coil features a Nomex® reinforcement collar to ensure thermal stability. The StampCast basket provides a solid construction and improved heat dissipation. The protective, textured PVC magnet cover and a soft-touch ABS cover ring complete the functional aesthetics. These materials significantly contribute to performance and durability.

Was sind die speziellen Features des Punch P1S4-15 im Vergleich zu anderen Subwoofern?

The Punch P1S4-15 subwoofer offers specialized features that set it apart from other subwoofers. In addition to VAST technology, which significantly increases the diaphragm area, it features a Kevlar fiber-reinforced paper cone that ensures extremely clear bass reproduction. The high-temperature voice coil guarantees durability and resistance to thermal stress. A StampCast basket with integrated spider ventilation improves heat dissipation. The subwoofer is also equipped with a rubberized ABS trim ring that can optionally accommodate a grille, and it has custom 10-AWG nickel-plated push terminals for optimal electrical conductivity.

Wie beeinflusst die Schwingspule die Leistung von Punch P1S2-15 Subwoofer?

The voice coil of the Punch P1S2-15 subwoofer is an essential element for its performance. With a diameter of 51.6 mm and made from high-temperature materials, it withstands intense conditions and provides stable performance even at high volumes. The Nomex® reinforcement collar supports the structural integrity of the voice coil, leading to reliable and sustained audio playback. These technical characteristics enable the subwoofer to deliver high performance without distortion, ensuring that the bass remains smooth and clear even in demanding applications.

Wie sollte der Punch P1S2-15 für optimale Leistung montiert werden?

The installation of the Punch P1S2-15 should take into account both the technical parameters and the specific requirements of your vehicle. For optimal performance, the subwoofer can be installed in sealed enclosures with a volume of 44.7 liters as well as in bass reflex enclosures with a volume of 75.3 liters. The correct placement in the trunk or another suitable area can significantly affect bass reproduction. A well-ventilated space around the StampCast basket is ideal for efficiently utilizing the integrated spider ventilation. These measures ensure that the subwoofer unleashes its full sound potential.
