  3. Zeus ZXS8D2
Hifonics Zeus ZXS8D2 8" (20cm) Subwoofer
SKU:  ZXS8D2
EAN:  4251476405066

6 Reviews

300 Watt

Zeus ZXS8D2

SKU:  ZXS8D2
EAN:  4251476405066

6 Reviews

Technical Highlights

  • Power of 300 W/RMS, 600 W/MAX, impedance of 2 + 2 Ω.
  • 50 mm dual voice coil, X-Max. +/16 mm, Qts of 0.44.
  • Fs 31.3 Hz, VAS of 12.4 L, 20 cm subwoofer diameter.
  • More technical details
00 d
00 h
00 m
00 s
€76,56
-23% €99,00 €76,56
5% discount with credit card
inkl. VAT , possibly plus shipping
Delivery
May 29, - Jun 1,
x piece
  • American Express
  • Apple Pay
  • Bancontact
  • BLIK
  • EPS
  • Google Pay
  • iDEAL Wero
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Shop Pay
  • Twint
  • Union Pay
  • Visa
Klarna Pay conveniently in 12 interest-free installments at €6,38 with Klarna .

Your benefits at Masori

Seen cheaper elsewhere?

Shipping cost calculator

Expert Image

Rob

Expert Image

Max

Unsure if this product fits your car?

We help you – quickly, personally, and without obligation.

Response on weekdays within 24 hours
A black and blue Hifonics Zeus ZXS8D2 8” subwoofer with dual voice coil, angled view showing brand name and 300W RMS on the center.
€76,56
€99,00 €76,56

Zeus ZXS8D2 by Hifonics

Zeus ZXS8D2 by Hifonics is an 8 inch 20 cm Subwoofer with a 50 mm dual voice coil and impedance 2 + 2 Ohm. The handcrafted, coated paper cone works with double-stitched surround. A dual magnet with 2 x 30 ounces 2 x 0.85 kg as well as pole core holes and ventilation channels is integrated. X-Max is +/- 16 mm. RMS power is 300 W and maximum power is 600 W. Fs 31.3 Hz, Qts 0.44, and VAS 12.4 L. Dimensions Ø 182 mm, ‡ 125 mm, blue magnet protector. 83 d.

Features
  • 8 inch 20 cm Subwoofer
  • Dual magnet 2 x 30 ounces 2 x 0.85 kg
  • 50 mm dual voice coil
  • X-Max +/- 16 mm
  • Double-stitched surround
  • Handcrafted, coated paper cone
  • Blue magnet protector
  • Pole core holes and ventilation channels
Technical Specifications
  • RMS power 300 W
  • Maximum power 600 W
  • Impedance 2 + 2 Ohm
  • Fs 31.3 Hz
  • Qts 0.44
  • VAS 12.4 L
  • Dimensions Ø 182 mm, ‡ 125 mm
  • 83 d

Your benefits at Masori

Frequently Asked Questions about Zeus ZXS8D2

What technical features does the Hifonics Zeus ZXS-8D2 have?

The Hifonics Zeus ZXS-8D2 is a 20 cm (8 inch) Subwoofer specifically designed for use in small sealed enclosures and larger bass reflex systems. It features a double-stitched surround and a hand-crafted, coated paper cone optimized for high pressure in small enclosures. The Subwoofer has a 50 mm dual voice coil with an X-Max of +/- 16 mm and uses a dual magnet weighing 2 x 30 ounces. The impedance is 2 + 2 ohms. Additionally, it is equipped with a blue magnet protector.

How much power does the Zeus ZXS-8D2 Subwoofer deliver?

The Hifonics Zeus ZXS-8D2 Subwoofer offers an RMS power of 300 watts and a maximum power of 600 watts. These power ratings allow the Subwoofer to achieve excellent acoustic results in various enclosure types. The combination of the double-stitched surround and the specially coated paper cone ensures that it operates effectively under high pressure conditions, making it ideal for use in performance-oriented car audio systems. If you value high sound pressure, this Subwoofer is an excellent choice.

What are the dimensions of the Hifonics Zeus ZXS-8D2?

The Hifonics Zeus ZXS-8D2 Subwoofer has a diameter of 182 mm and a mounting depth of 125 mm. These compact dimensions allow for flexible installation, both in small enclosures and in larger bass reflex systems. The optimized design with powerful 50 mm dual voice coils enables the Subwoofer to be integrated into a variety of audio systems. When mounting, ensure there is enough space for installation to guarantee maximum performance and efficiency.

What is the frequency response of the Zeus ZXS-8D2?

The Hifonics Zeus ZXS-8D2 is optimized for resonance-free playback in the bass range. With an Fs value of 31.3 Hz, this Subwoofer delivers deep bass that is particularly powerful in compact enclosures. The Qts value of 0.44 ensures that the bass reproduction remains clear and precise, making it ideal for demanding audio systems. With a VAS of 12.4 liters, it is tuned to work efficiently in a variety of enclosure volumes.

What materials are used in the Hifonics Zeus ZXS-8D2?

For the Zeus ZXS-8D2 Subwoofer, Hifonics uses high-quality materials such as a handcrafted and specially coated paper cone. This construction is combined with a double-stitched surround, contributing to the durability and stability of the Subwoofer. The dual magnet with 2 x 30 ounces and the 50 mm dual voice coil emphasize the robust characteristics of the product. This choice of materials not only ensures superior sound quality but also provides a long lifespan for the Subwoofer under intense operating conditions.

How can the Zeus ZXS-8D2 Subwoofer be installed in a car?

Installing the Zeus ZXS-8D2 in a car requires some planning due to its dimensions of 182 mm diameter and 125 mm mounting depth. You should ensure that there is enough space in the designated area and that the enclosure type used considers the Thiele Small parameters Qts of 0.44 and VAS of 12.4 L. Ideally, use sealed enclosures or bass reflex systems for the best sound. When wiring, the dual voice coils must be connected correctly to utilize the specified impedance of 2 + 2 ohms.

Are there ventilation features in the Hifonics Zeus ZXS-8D2?

Yes, the Hifonics Zeus ZXS-8D2 Subwoofer is equipped with special ventilation channels that reduce operating temperature while improving acoustic efficiency. Additionally, the large dual magnets have pole core vents integrated, which help dissipate heat effectively. These ventilation features ensure that the Subwoofer operates more reliably under high power consumption and extreme conditions while delivering consistent performance. These design characteristics contribute to the longevity and protection of the internal components.

What advantages does the double-stitched surround offer in the Zeus ZXS-8D2?

The double-stitched surround of the Zeus ZXS-8D2 Subwoofer from Hifonics offers several technical advantages, including increased stability and improved durability under heavy loads. It is particularly resistant to mechanical stress, which is important for long-term use in compact enclosures with high pressure conditions. This design decision results in more precise bass reproduction and reduces distortion at high volumes. For audiophiles who value accurate bass reproduction, the double-stitched surround is a crucial quality feature.

What impedance options does the Zeus ZXS-8D2 offer?

The Zeus ZXS-8D2 from Hifonics is equipped with dual voice coils that provide a flexible impedance of 2 + 2 ohms. This configuration allows the Subwoofer to be connected either in parallel or in series, depending on requirements, to achieve the desired total impedance in the audio system. This versatility is particularly useful when you want to connect the subwoofer system to different Amplifiers. Be sure to choose the correct impedance to utilize the full power of the Subwoofer while maintaining sound integrity.

How does the Zeus ZXS-8D2 differ in bass performance?

The Zeus ZXS-8D2 is characterized by exceptional bass performance, enabled by an Fs value of 31.3 Hz and a unique diaphragm construction. The coated paper diaphragm and the double-stitched surround contribute to excellent bass reproduction, ensuring low distortion even at high volumes. Additionally, the efficient magnetic structure with pole core venting enhances the dynamic performance of the Subwoofer. As a result, the Zeus ZXS-8D2 is particularly suitable for music genres that benefit from deep bass frequencies.
