Discover the Prima APK 165P, a 6.5-inch front system set from Audison. The two-piece speaker system, consisting of AP 1P and AP 6.5P, is supported by a crossover. It features cutting-edge technology and delivers an outstanding peak power of 345W. The highlight of this set is the AIF technology (Any Install Faceplate), which offers extensive application versatility and significantly reduces installation time. The woofer also ensures excellent performance in OEM configurations. The kit integrates seamlessly into any high-performance setup, allowing you to unlock the full potential of your AP F8.9 bit or other Prima amplifiers.

TECHNICAL DATA

• Woofer size 165 mm
• Tweeter size 29 mm
• Woofer voice coil diameter 32 mm
• Tweeter voice coil diameter 25 mm
• Woofer magnet size 100 x 40 x 18
• Power handling - Peak 345 W
• Power handling - Continuous 115 W
• Sensitivity 92.5 dB
• Impedance 4 Ohm
• Frequency response 50 - 24k
• Woofer crossover low-pass: 4 kHz @ 6 dB/oct
• Tweeter crossover high-pass: 4 kHz @ 12 dB/oct
• Tweeter level adjustment Tweeter level; 0 / +3
• Woofer cone diameter 132 mm
• Woofer Xmax 5.6 mm

ELECTRO-ACOUSTIC FEATURES

• Re Woofer 3.1 Ohm
• Fs Woofer 60 Hz
• Le Woofer mH @ 1 kHz 0.29
• Vas Woofer 11.4 l
• Mms Woofer 14.6 g
• Cms Woofer 0.47
• Bxl Woofer 5.35
• Qts Woofer 0.55
• Qms Woofer 7.6
• Qes Tweeter 1.74
• Spl Woofer 89.5 dB

GENERAL

• Woofer weight 1.45 kg
• Tweeter weight 0.067 kg

FEATURES

• AP 1P
  • AIF technology (Any Install Faceplate) for extensive application versatility and a significant reduction in installation time.
  • Three included mounting accessories provide a solution for every type of installation.
  • Magnet assembly with dual neodymium tablets for excellent high-frequency extension.
  • 1 CCAW voice coil for outstanding dynamics.
  • Dome profile optimized with FEM simulations for wide off-axis dispersion.
• AP 6.5P
  • Increased excursion of the moving assembly for superior dynamic response.
  • Optimized electro-acoustic parameters to maximize performance for OEM placements.
  • The magnet assembly is sized to provide perfect control even at maximum cone excursion.
  • CCAW (Copper-Clad Aluminium Wire) voice coil (32 x 14 mm) to optimally handle higher power.
  • Compact basket size for easy OEM installations.
• APCX P 2T, APCX P 2W
  • Separate, ultra-compact crossovers for tweeter and woofer minimize space requirements and simplify wiring, making specialists' work easier.
  • Use of components selected and sized to handle high power and avoid saturation.
  • Asymmetric slope, 12 dB/oct for the tweeter and 6 dB/oct for the woofer for optimal balance between the two components.
