Axton AT101 24V 1-Channel Amplifier

Name: Axton AT101 24V 1-Channel Amplifier | Masori
Brand: Axton
Price: 179.1 EUR
Availability: InStock
Rating: 5.0 (1 reviews)

1 Review

CYBER -10%

Max, Mikael and 53k+ customers already with Masori sound upgrade

Axton AT101 24V 1-Channel Amplifier

1 Review

Power: 230W RMS @ 4 ohms, 380W RMS @ 2 ohms.
Impedance: optimized for 4 or 2 ohm applications.
Crossovers: 12 dB/oct., low-pass/subsonic filter.
Mehr technische Details

00

€179,10

~~€199,00~~ €179,10

5% Rabatt mit Vorkasse

inkl. VAT , possibly plus shipping

Bequem in 12 zinsfreien Raten à €14,92 mit Klarna zahlen.

Jetzt mit kostenlosem Versand ab 50€!

Shipping cost calculator

Land/Region

PLZ

Garantie & zusätzlicher Geräteschutz für dein HiFi-System

3 Jahre Masori Garantie Kostenlos 48 Monate Plusgarantie €14,99 60 Monate Plusgarantie Am beliebtesten €19,99

Deshalb wählen uns 100.000+ Kunden

3 Jahre Garantie

Sicher & sorglos
Blitzversand

mit DHL Express
Tiefpreisschutz

Nie zu viel zahlen

Rob

Max

Unsicher, ob dieses Produkt zu deinem Auto passt?

Wir helfen dir – schnell, persönlich und unverbindlich.

Antwort on weekdays within 24h

AxtonAT401 24V

ETONAG 25

AT101 24V by Axton

The AT101 24V from Axton is a 1-channel amplifier. This ultra-compact Class-D amplifier is especially suitable for use in trucks and features a 24 V power supply that covers a voltage range of 12 - 32 V. An aluminum heat sink ensures optimal heat dissipation. The amplifier offers both high-level and low-level inputs and supports auto turn-on via DC offset or music signal. Integrated electronic crossovers include a 12 dB/oct. low-pass filter and a 12 dB/oct. subsonic filter. Other features include bass boost control at 45 Hz and the included bass level remote control. With an output power of 230 watts RMS @ 4 ohms and 380 watts RMS @ 2 ohms, the amplifier provides sufficient power for various applications.

Highlights

Ultra-compact Class-D amplifier for trucks
24 V power supply, voltage range from 12 - 32 V
Aluminum heat sink for optimal heat dissipation
High-level/low-level input
Auto turn-on via DC offset or music signal
Integrated electronic crossovers: 12 dB/oct. low-pass filter (50 – 250 Hz)
12 dB/oct. subsonic filter (10 – 55 Hz)
Bass boost control @ 45 Hz (0 – 18 dB)
Bass level remote control

Specifications

Output power @ 4 ohms 1 x 230 watts RMS
Output power @ 2 ohms 1 x 380 watts RMS
Frequency response: 15 Hz – 250 Hz
Signal-to-noise ratio: >86 dB
Variable input sensitivity: 0.4 – 10 V
Dimensions (W x H x D) 185 x 40 x 105 mm

Axton AT101 24V Datenblatt

Datenblatt öffnen

Frequent questions about AT101 24V

Welche Funktionen bietet der AT101 24V Verstärker von Axton?

The AT101 24V amplifier from Axton is an ultra-compact 1-channel Class-D amplifier, ideal for use in trucks. Technically, it features a 24V power supply that supports voltages in the range of 12 to 32 V. Its functions include high-level and low-level inputs as well as an auto-turn-on function via DC offset or music signal. Electronic crossovers with a 12 dB/oct. low-pass filter from 50 to 250 Hz and a subsonic filter from 10 to 55 Hz are also integrated. Additionally, there is a bass boost control at 45 Hz between 0 and 18 dB with an included bass level remote control.

Wie hoch ist die Ausgangsleistung des AT101 24V bei unterschiedlichen Impedanzen?

The Axton AT101 24V amplifier delivers impressive output power. With an impedance of 4 ohms, the amplifier achieves an RMS power of 230 watts, while at 2 ohms, a higher power of 380 watts RMS is reached. This power allows for efficient driving of power-hungry speakers. Especially for applications in trucks, this power is more than sufficient to ensure a strong acoustic performance. An important aspect is the signal-to-noise ratio, which at >86 dB ensures clear sound quality without disturbing background noise, which is extremely beneficial during long journeys.

Warum ist der Aluminium Kühlkörper des AT101 24V wichtig?

The aluminum heat sink of the AT101 24V plays a crucial role in heat dissipation. Due to the compact design of the amplifier, optimized cooling is necessary to ensure operational efficiency and longevity. Aluminum is characterized by good thermal conductivity and low weight, which is often used in electronics to ensure thermal stability. Especially under high power operation, such as at the maximum output power of the amplifier, the heat sink ensures that the components do not overheat, which guarantees a consistently reliable operation.

Welche Arten von Eingängen unterstützt der AT101 24V Verstärker?

The Axton AT101 24V amplifier offers versatile connection options through its support for high-level and low-level inputs. The high-level inputs are ideal for connecting to existing speaker signals, allowing for integration into existing audio systems without the need for an additional adapter. Low-level inputs, on the other hand, provide a direct connection to source devices with preamplifier levels, such as car radios with RCA outputs. This flexibility in input options makes the AT101 24V an adaptable amplifier that can be easily integrated into various audio setups.

Wie funktioniert die Auto-Turn-On-Funktion des AT101 24V?

The AT101 24V is equipped with an auto turn-on function that automatically activates the amplifier. This function can be triggered by a DC offset or a music signal. A DC offset detects voltage changes in the audio signal, while the music signal is activated by the first incoming sound wave. For example: As soon as the vehicle's engine is started and an audio signal is sent from the radio, the amplifier activates itself without the need for manual switching. This is particularly useful for use in trucks, where comfort and ease of operation are paramount.

Welche elektronische Frequenzweichen bietet der AT101 24V Verstärker?

The AT101 24V from Axton is equipped with advanced electronic crossovers that enable precise sound processing. It features a 12 dB/octave low-pass filter that is adjustable from 50 to 250 Hz, as well as a 12 dB/octave subsonic filter that processes frequencies from 10 to 55 Hz. The low-pass filter selects lower frequencies that are sent to the subwoofer, while the subsonic filter removes unwanted ultra-low frequencies that could damage speakers. These crossovers are essential for tailoring the sound to personal preferences and enhance the efficiency of the speakers.

Was ist die Funktion der Bass Boost Control im AT101 24V?

The Bass Boost Control in the AT101 24V amplifier allows for adjustment of the bass intensity at 45 Hz in the range of 0 to 18 dB. This feature is particularly useful when strong bass adjustments are required – for example, to maximize the effect of a subwoofer in large truck cabins. The included bass level remote control allows for regulation directly from the driver's seat, without the need to manually adjust the amplifier. This way, the bass playback can be optimally tailored to different music genres or listening habits, providing a more personalized sound experience.

Wie beeinflussen die Abmessungen des AT101 24V seine Installation?

With its compact dimensions of 185 mm width, 40 mm height, and 105 mm depth, the AT101 24V is specifically designed for easy installation, even in limited space, as is often found in trucks. These small dimensions allow for flexible placement under seats, behind trim parts, or in smaller control areas. The minimalist design and low profile are particularly advantageous when the amplifier needs to be discreetly integrated into existing vehicle interiors. Due to its module size, it is ideal for concealed installations without compromising on performance.

Wie wird die variable Eingangsempfindlichkeit des AT101 24V eingestellt?

The AT101 24V amplifier offers a variable input sensitivity that can be adjusted from 0.4 to 10 V. This wide range allows for the adaptation of the amplifier to different signal levels from source devices, such as car radios. The correct setting of the input sensitivity ensures that the volume is utilized optimally without distortion, leading to improved sound quality. It allows for fine tuning to match the relationship between the source device and the amplifier, achieving the desired volume settings with clear, distortion-free sound.

Für welche Fahrzeugarten ist der AT101 24V Verstärker besonders geeignet?

The AT101 24V from Axton is particularly designed for use in trucks due to its design and technical specifications. Its 24V power supply, which covers a voltage range of 12 to 32 V, offers flexible application in trucks that often operate with this voltage system. The robust performance combined with a compact design allows for easy integration into the often cramped installation conditions in trucks. In particular, the high output power and extended frequency processing are optimized for the demands and operation in larger vehicle cabins, making the AT101 24V the ideal choice for mobile use in commercial vehicles.
