  5. HX 130 Phase Aktiv Evo 3

Audio System HX 130 Phase Aktiv Evo 3 5" (13cm) speaker set

Audio System HX 130 Phase Aktiv Evo 3 5" (13cm) speaker set

  • 5" speaker set, neodymium drive, 130 mm HIGH-END speaker, 3 Ohm.
  • NAWI paper cone, fiberglass, Nomex spider, phase plug, precise sound.
  • Compact design, 140/95 watts, fabric neodymium tweeter, 4 ohms.
  • Mehr technische Details
€549,00
€549,00 €549,00
5% Rabatt mit Vorkasse
inkl. VAT , possibly plus shipping
Klarna Bequem in 12 zinsfreien Raten à €45,75 mit Klarna zahlen.
Delivery to Home
Dec 18, - Dec 21,
x set
  • American Express
  • Apple Pay
  • Bancontact
  • BLIK
  • EPS
  • Google Pay
  • iDEAL
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Twint
  • Union Pay
  • Visa

Looking for a discount?

Shipping cost calculator

Warranty & additional device protection for your Hi‑Fi system

Deshalb wählen uns 100.000+ Kunden

Expert Image

Rob

Expert Image

Max

Not sure if this product fits your car?

We help you — quickly, personally and without obligation.

Antwort on weekdays within 24h
Audio SystemHX 100 Phase Aktiv Evo 3
Audio System-HX 100 Phase Aktiv Evo 3-4" (10cm) Lautsprecherset-masori-kaufen
Audio System-HX 165 Phase Aktiv Evo 3-6.5" (16,5cm) Lautsprecherset-masori-kaufen
Audio SystemHX 165 Phase Aktiv Evo 3

HX 130 Phase Aktiv Evo 3 by Audio System

Discover the HX 130 Phase Aktiv Evo 3, a 5-inch speaker set from Audio System. This set impresses with the combination of a powerful 130 mm midrange driver with neodymium drive and a 30 mm fabric neodymium tweeter. The NAWI paper cone with fiberglass and Nomex spider ensures deep sound reproduction and high stability, while the phase plug delivers precise sound. With a power rating of 140/95 watts and an impedance of 3 ohms, the midrange driver offers outstanding sound characteristics. The tweeter complements the set with an impedance of 4 ohms and an aluminum flange. The compact design allows for easy installation.

EX 130 Phase EVO 3 Features

  • Audio System midrange driver with neodymium drive
  • 130 mm HIGH-END speaker with ventilated cast basket
  • Ultra-light/stable NAWI paper cone with fiberglass, Nomex spider, and phase plug
  • Deep sound reproduction
  • Impedance: 3 ohms
  • Power: 140/95 watts
  • Outer diameter: 133/150 mm
  • Installation depth: 60 mm
  • Mounting dimension: 120 mm

HS 30 Phase EVO Features

  • Audio System HIGH-END tweeter
  • 30 mm fabric neodymium tweeter with aluminum flange + coupling volume
  • Protective grille
  • Coupled volume
  • Fs: 690 Hz
  • Impedance: 4 ohms
  • Outer diameter: 60 mm
  • Installation depth: 27 mm
  • Mounting dimension: 54 mm

Scope of delivery

  • HX SERIES fully active
  • 2x EX 130 Phase EVO 3
  • 2x HS 30 Phase EVO

Audio System HX 130 Phase Aktiv Evo 3 Datenblatt

Datenblatt öffnen

Frequent questions about HX 130 Phase Aktiv Evo 3

Was macht den HX 130 Phase Aktiv Evo 3 Mitteltöner so besonders?

The HX 130 Phase Aktiv Evo 3 midrange driver impresses with its powerful 130 mm neodymium drive, which not only provides high sound pressure but also enables precise sound reproduction. The use of a NAWI paper diaphragm reinforced with fiberglass ensures deep reproduction and high stability, minimizing distortion. The phase plug also ensures precise phase reproduction and increases sound clarity. The ventilated cast basket improves air circulation and thus cooling, resulting in stable performance even at high volumes.

Welche technischen Daten hat der Hochtöner des HX 130 Phase Aktiv Evo 3?

The tweeter in the HX 130 Phase Aktiv Evo 3 is a 30 mm textile neodymium tweeter that stands out due to its aluminum flange and the coupled volume. The impedance of 4 Ohms allows for broad compatibility with various amplifiers. With a resonance frequency (Fs) of 690 Hz, the tweeter provides clear and precise reproduction of high frequencies. The installation depth of 27 mm and the installation diameter of 54 mm make it compact and versatile, allowing for easy integration into various vehicle configurations.

Welche Leistung kann das HX 130 Phase Aktiv Evo 3 Lautsprecherset liefern?

The HX 130 Phase Aktiv Evo 3 speaker set offers excellent performance with a nominal power handling of 140 watts and a music power handling of 95 watts. These power ratings refer to the entire range of mid and high frequencies, making this setup suitable for both home use and automotive applications. With an impedance of 3 ohms for the midrange driver and 4 ohms for the tweeter, the set is designed to provide a harmonious and powerful sound reproduction that impresses both at low music settings and at high volume.

Wie komplex ist der Einbau des HX 130 Phase Aktiv Evo 3 Lautsprechersets?

The installation of the HX 130 Phase Active Evo 3 speaker set is relatively simple, thanks to its compact design and precise dimensions. The midrange driver has an outer diameter of 133/150 mm, a mounting depth of 120 mm, and a mounting depth of 60 mm. The tweeter is equipped with an outer diameter of 60 mm, a mounting depth of 54 mm, and a mounting depth of 27 mm. These dimensions facilitate integration into a variety of vehicle types, and the low mounting depths minimize adjustments to the vehicle interior.

Wie ist die Klangqualität des HX 130 Phase Aktiv Evo 3 Lautsprechersets von Audio System?

The sound quality of the HX 130 Phase Aktiv Evo 3 speaker set is outstanding, thanks to the high-end components and thoughtful construction. The NAWI paper membrane with fiberglass provides significantly deep and stable reproduction that remains clean even at higher volumes. The Nomex spider ensures additional stability and appealing dynamics. Particularly noteworthy is the neodymium drive of the midrange driver, which delivers powerful sound without distortion, and the 30 mm fabric neodymium tweeter, which reproduces high frequencies crystal clear. The tuning is excellent for both bass lovers and detail-oriented listeners.

Welche Materialien kommen beim HX 130 Phase Aktiv Evo 3 zum Einsatz?

In the HX 130 Phase Aktiv Evo 3, high-quality materials are used to achieve the best possible sound quality. The midrange driver features a special NAWI paper diaphragm reinforced with fiberglass to ensure stability and detailed sound reproduction at any volume. The phase plug and Nomex spider complement this system and contribute to its vibrational capability and resilience. For the tweeter, a fabric neodymium material is used, enabling reliable and precise high-frequency performance. Additionally, the aluminum flange provides improved stability and an elegant appearance.

Ist das HX 130 Phase Aktiv Evo 3 Lautsprecherset mit meinem Fahrzeug kompatibel?

The compact design of the HX 130 Phase Active Evo 3 speaker set ensures broad vehicle compatibility. The midrange drivers have an outer diameter of 133/150 mm and a mounting depth of 60 mm, while the tweeter has an outer diameter of 60 mm and a mounting depth of 27 mm. These dimensions allow for flexible installation in many vehicle models without major modifications. If specific coupling volumes are required, the tweeter offers additional flexibility in installation due to the coupled volume, which can be advantageous depending on the vehicle design.

Welche Rolle spielt der Phase Plug im HX 130 Phase Aktiv Evo 3?

The phase plug in the HX 130 Phase Aktiv Evo 3 is crucial for precise sound reproduction. It improves the dispersion of sound waves, which is particularly beneficial in complex musical passages. By minimizing interference, the sound remains consistently clear and natural. Additionally, the phase plug helps to maintain phase coherence by minimizing frequency disturbances, leading to a realistic listening experience. This demonstrates its significant impact on transparency and detail accuracy, especially when listening at high volumes. The phase plug is an essential aspect of sound design.

Wie unterstützt der Neodymantrieb die Leistung des HX 130 Phase Aktiv Evo 3?

The neodymium drive of the HX 130 Phase Aktiv Evo 3 midrange speaker is a key element for the powerful and dynamic sound reproduction of the speaker set. Neodymium is a strong magnetic material that provides high drive energy in a compact size. This drive allows for high efficiency and precise sound control even with low weight and size. The compact neodymium magnet system leads to improved mobility of the diaphragm, which in turn enhances subtleties in the sound image and helps to accurately reproduce both subtle details and strong bass frequencies.

Wie wirken sich die Thiele Small Parameter auf den Klang der HX 130 Phase Aktiv Evo 3 aus?

The Thiele Small parameters are fundamental technical specifications that determine the performance and sound behavior of a speaker like the HX 130 Phase Aktiv Evo 3. Parameters such as total Q factor (Qts), moving mass (Mms), and effective diaphragm area (Sd) directly influence how accurately the speaker reproduces frequencies. By optimally utilizing these parameters, a balanced bass, midrange, and treble performance is achieved. Even in compact enclosures, well-balanced and precise frequency tuning is evident, providing exceptional detail and clarity across the entire sound spectrum.
