Musway TUNE12 12-Channel DSP

Name: Musway TUNE12 12-channel DSP | Masori
Brand: Musway
Price: 799.0 EUR
Availability: InStock

Max, Mikael and 53k+ customers already with Masori sound upgrade

Musway TUNE12 12-Channel DSP

12-channel stand-alone DSP, 12 RCA outputs at 6.5 V RMS.
6 high-level and 8 low-level inputs, 8-24 V RMS, EPS integrated.
ADAU1452 DSP chip, 295 MHz dual 64bit technology, 3 Burr-Brown converters.
Mehr technische Details

€799,00

~~€799,00~~ €799,00

5% Rabatt mit Vorkasse

inkl. VAT , possibly plus shipping

Bequem in 12 zinsfreien Raten à €66,58 mit Klarna zahlen.

Jetzt mit kostenlosem Versand ab 50€!

Shipping cost calculator

Land/Region

PLZ

Garantie & zusätzlicher Geräteschutz für dein HiFi-System

3 Jahre Masori Garantie Kostenlos 48 Monate Plusgarantie €84,99 60 Monate Plusgarantie Am beliebtesten €94,99

Deshalb wählen uns 100.000+ Kunden

3 Jahre Garantie

Sicher & sorglos
Blitzversand

mit DHL Express
Tiefpreisschutz

Nie zu viel zahlen

Rob

Max

Unsicher, ob dieses Produkt zu deinem Auto passt?

Wir helfen dir – schnell, persönlich und unverbindlich.

Antwort on weekdays within 24h

MuswayMSR-HYKI1

MuswayONE1000

TUNE12 by Musway

With the new 12-channel stand-alone DSP Musway TUNE12, the premium manufacturer Musway once again demonstrates how good high-end audio can look. The TUNE12 impresses with excellent features and internal values that are essential in very complex devices. Three Burr-Brown converters PCM3168A have been installed to optimize channel separation. This multiple use also allows for mixed operation of different sources. At its core is the state-of-the-art DSP chip ADAU1452 from Analog Devices, which has been finely tuned by Musway engineers and leaves no audiophile wishes unfulfilled. In addition to the extremely high sound level, which is expressed, among other things, by very low distortion values, the graceful DSP also impresses with its generous equipment: it not only has 12 fully processable outputs but also features AUX, S/PDIF, and optical digital inputs, as well as 6 low-level and 8 high-level inputs. The latter are equipped with the latest EPS and process up to 24 V RMS.

Features

Intelligent high-level input with EPS (Error Protection System)
Start-Stop ready, Automatic switch-on function
Three Burr-Brown converters (PCM3168A) and Analog Devices DSP (ADAU1452)
Dual 64bit, 295 MHz DSP technology, controllable via new V3 DSP software and V3 app.
Individually adjustable input sensitivity (CH1-8 high level, CH1-6 low level, AUX)
High-quality full aluminum case with glass panel
External Bluetooth® USB dongle (BTS & BTA2) for audio streaming & app control (optional)
Digital remote control (DRC1) with OLED display for controlling various DSP functions (optional)

Specifications

12-channel DSP with app and PC control
8 x high-level input 8 – 24 V RMS
6 x low-level input (RCA) 1 – 8 V RMS
1 x AUX input/stereo (RCA) 1 – 8 V RMS
1 x Optical/Stereo Input (PCM, 96 kHz / 24 bit)
1 x Input Coaxial/Stereo (S/PDIF, 96 kHz / 24 bit)
12 x RCA output 6.5 V RMS
Dimensions 220 x 38 135 mm

Musway TUNE12 Datenblatt

Datenblatt öffnen

Frequent questions about TUNE12

Was macht den 12-Kanal DSP TUNE12 von Musway besonders?

The TUNE12 from Musway is a stand-alone DSP with outstanding features that make it unique in the high-end audio world. Equipped with three Burr-Brown converters (PCM3168A), it ensures optimal channel separation, allowing for mixed operation. The centerpiece is the DSP chip ADAU1452 from Analog Devices, which operates with dual 64-bit, 295 MHz DSP technology, ensuring excellent audio processing and low distortion levels. Particularly noteworthy are the 12 processable outputs and the variety of inputs, including AUX, S/PDIF, and optical digital inputs. This equipment makes the TUNE12 both flexible and powerful.

Wie funktioniert die automatische Einschaltfunktion des TUNE12?

The TUNE12 features an intelligent power-on function that automatically activates the DSP when a signal is applied to the input. This occurs regardless of the signal source, whether through one of the 8 high-level inputs, the 6 low-level inputs, or for example, the AUX input. This function provides comfort and flexibility in daily use, especially in combination with various signal sources. The start-stop compatibility of the TUNE12 also ensures that the DSP operates seamlessly in modern vehicles by adapting to the onboard voltage.

Welche Eingänge bietet der TUNE12 DSP und wie sind sie konfiguriert?

The TUNE12 DSP offers a wide range of input options that allow for flexible integration into various audio setups. It features 8 high-level inputs equipped with an EPS (Error Protection System) that can process signals from 8 to 24 V RMS. Additionally, there are 6 low-level inputs available with a range of 1 to 8 V RMS. The TUNE12 also provides additional connection options through an AUX input, as well as an optical and a coaxial digital input, both with 96 kHz / 24 bit. This versatility supports various audio sources and signal types.

Wie optimiert der DSP-Chip ADAU1452 die Klangqualität im TUNE12?

The sound quality of the TUNE12 is significantly enhanced by the ADAU1452 DSP chip from Analog Devices. This state-of-the-art chip operates with a 64-bit dual 295 MHz DSP technology, which allows for low distortion and precise signal processing. The fine-tuning by Musway engineers ensures that the chip meets audiophile standards. The result is a remarkably strong sound level that impresses across all frequency ranges, catering to even the most demanding music lovers. These technologies make the TUNE12 an impressively powerful DSP for the discerning user.

Wie groß ist der TUNE12 und wie lässt er sich im Auto installieren?

The TUNE12 measures a compact 220 x 38 x 135 mm, making it easy to integrate into the vehicle. These small dimensions facilitate installation in different vehicle models, regardless of the brand or model. However, since no specific car brands are mentioned, you should ensure in advance that the necessary space is available in your vehicle. The DSP can be easily mounted in its handy size either under the seat, in the trunk, or another suitable location. Make sure that ventilation is optimal to avoid overheating.

Welche Verbindungsmöglichkeiten bietet der TUNE12 für externe Steuerungen?

The TUNE12 offers multiple expandable control options for individual customization. An optional external Bluetooth® USB dongle enables audio streaming as well as app control and expands control over the entire system. Furthermore, a digital remote control, the DRC1 model with OLED display, is offered, allowing various DSP functions to be controlled directly and intuitively. These options ensure that even the most demanding configurations can be easily and comfortably adjusted to personal preferences. Example: You can quickly adjust settings without having to change the actual installation.

Welche Leistungsdaten sind für die Ausgänge des TUNE12 angegeben?

The Musway TUNE12 features 12 RCA outputs that deliver a signal with an output voltage of 6.5 V RMS. This ensures that even at greater distances or in more complex setups, the quality and power of the audio signal are not lost. The processable outputs allow for comprehensive control and individual adjustment of the audio signals. In conjunction with the various inputs provided by the DSP, you can create a very differentiated and powerful sound profile for your audio system. Especially if you enjoy listening to music loudly, this power will do justice to the installed speakers.

Welche Materialien wurden beim Gehäuse des TUNE12 verwendet?

The TUNE12 is housed in a high-quality full aluminum casing that is not only robust but also visually appealing. The aluminum structure offers several advantages, such as excellent heat dissipation and protection against mechanical influences. The casing is additionally equipped with a stylish glass panel that gives the DSP a modern and elegant appearance. The choice of these materials not only conveys aesthetic beauty but also combines functionality and protection, which is especially beneficial in demanding audio environments.

Wie wird die Eingangsempfindlichkeit beim TUNE12 geregelt?

The TUNE12 from Musway offers the ability to individually adjust the input sensitivity. This is done separately for the high and low level inputs as well as the AUX input. This includes the CH1-8 high level inputs, which operate with signals between 8 to 24 V RMS, and the CH1-6 low level inputs, which can process 1 to 8 V RMS. This specific adjustability allows for fine-tuning of the input levels, thereby optimally integrating different signal sources into the setup. This ensures that the DSP always provides optimal signal processing and avoids distortion.

Welche digitale Verarbeitung unterstützt der optische Eingang des TUNE12?

The optical input of the Musway TUNE12 supports PCM signals with a maximum resolution of 96 kHz at 24 bit, contributing to exceptional sound transparency. This technical specification ensures that high-resolution audio data can be processed without loss of quality. The optical stereo input allows for the connection of digital sources of any kind to the DSP, ensuring lossless signal transmission. This is particularly useful for modern entertainment systems that output high-resolution audio data, and is also ideal for users who value first-class bitstream quality.
