BassPro HUB

The new JBL BassPro Hub subwoofer delivers show & shine performance without crowding your passengers or compromising cargo space. This all-in-one subwoofer system fits into the hub of your spare tire and is super easy to install. The built-in Class-D amplifier delivers 200 W RMS and is designed to work with the BassPro Hub subwoofer and enclosure as a system. The 279 mm (11") lightweight fiberglass woofer with rubber surround provides the signature kick and punch of JBL bass. And thanks to the over-temperature protection (OTP) and over-current protection (OCP), you can rely on reliability even at peak volumes. The included remote control allows you to adjust crossover frequency, gain, phase, and a bass boost of 12 dB when you're in the mood and on the go. Whether you're traveling or competing, the JBL BassPro leaves the competition behind without missing a beat.

• Fiber optic deep tone cone with rubber coating
• The 11" (279 mm) low-frequency diaphragm was designed to deliver fast and tight deep bass with low distortion and unwanted second and third-order anomalies.
• Built-in Class D amplifier with 200 W RMS
• The built-in amplifier of the JBL subwoofer system is optimized to work as a system with the woofer. Its Class-D design runs cooler and consumes less power from your vehicle's electrical system, making it the perfect solution for a hidden subwoofer.

properties

• Wired remote control with controls for the user interface
• With the gain control, you can adjust the volume directly from the driver's seat. The phase switch changes the input phase to inverted or non-inverted. (This can sometimes be helpful during troubleshooting.) With the crossover frequency control, you can set the crossover frequency to any value between 50 Hz and 150 Hz. The bass EQ control provides a boost of 12 dB.
• Line-level inputs and speaker-level inputs
• The JBL BassPro Hub features line-level inputs and speaker inputs, allowing you to connect it to any audio system in your car, making it a great upgrade for your factory system or the bass foundation for the aftermarket system of your dreams.

General Specifications

• Amplifier power 200W RMS (2 Ohm)
• Frequency response 30Hz - 150Hz
• 30A fuse
• Maximum current draw 30A
• Standby current consumption <1.2A
• Low-Pass Filter 50Hz - 150Hz
• Slope of the crossover 24 dB/octave
• Bass boost 0 - 12dB Variable @ Fixed 50 Hz
• Input sensitivity line level 0.2 V - 4 V
• Input sensitivity at speaker level 0.5 V - 10 V
• Dimensions (D x H) D360mm x H165mm

What is included in the delivery?

• 1 x BassPro Hub Subwoofer
• 1 x Safety Data Sheet
• 1 x mounting kit for attachment to the vehicle
• 1 x wiring harness
• 1 x remote control with 5 meter cable
• 1 x Quick Start Guide (full manual online)
