Hertz Mille Pro MPCX 2 TM.3 crossover

Name: Hertz Mille Pro MPCX 2 TM.3 Crossover | Masori
Brand: Hertz
Price: 41.65 EUR
Availability: InStock

CYBER -15%

Max, Mikael and 53k+ customers already with Masori sound upgrade

Hertz Mille Pro MPCX 2 TM.3 crossover

Tweeter adjustment 0/+2 dB, crossover 5.5 kHz.
Bimetallized polyester film capacitors, high sound quality.
Compact dimensions, high installation flexibility, low weight.
Mehr technische Details

00

€41,65

~~€49,00~~ €41,65

5% Rabatt mit Vorkasse

inkl. VAT , possibly plus shipping

Jetzt mit kostenlosem Versand ab 50€!

Shipping cost calculator

Land/Region

PLZ

Garantie & zusätzlicher Geräteschutz für dein HiFi-System

3 Jahre Masori Garantie Kostenlos 48 Monate Plusgarantie €14,99 60 Monate Plusgarantie Am beliebtesten €19,99

Deshalb wählen uns 100.000+ Kunden

3 Jahre Garantie

Sicher & sorglos
Blitzversand

mit DHL Express
Tiefpreisschutz

Nie zu viel zahlen

Rob

Max

Unsicher, ob dieses Produkt zu deinem Auto passt?

Wir helfen dir – schnell, persönlich und unverbindlich.

Antwort on weekdays within 24h

HertzCento CG 250

HertzHEX 6.5 IC-W

Mille Pro MPCX 2 TM.3 by Hertz

The Mille Pro MPCX 2 TM.3 from Hertz is a car crossover that works excellently in combination with the MP 70.3 and MP 25.3 models. It was developed for use in a 3-way amplifier system and can be used actively together with an MP 165.3 / MP 165P.3 woofer. Its technical highlights include a tweeter adjustment of 0/+2 dB and crossover characteristics of midrange low pass 5.5 kHz @ -6 dB/octave as well as tweeter high pass 5.5 kHz @ -12 dB/octave. For optimal sound quality, it features extremely high-quality, bimetallized polyester film capacitors. With its compact dimensions and low weight, it also offers high installation flexibility.

Technical Data

Tweeter adjustment 0 / +2 dB
Weight - Crossover kg 0.16
Crossover

Midrange low pass 5.5 kHz @ – 6 dB/octave
Tweeter high pass 5.5 kHz @ – 12 dB/octave

Physical Specifications

Mille Pro MPCX 2 TM.3

G 102 mm
H 76.5 mm
I 37 mm

FEATURES

Two-stage switch (0 / +2 dB) for adjusting the tweeter level to fine-tune the transducer's emission.
160 V extremely high-quality bimetallized polyester film capacitors with extremely low DF for maximum sound transparency and clean mid/high frequencies.
1 mm pure copper wire inductors with low series resistance for minimal loss in the midrange, where high transient currents are required.
Space-saving design for easy installation, with a top ventilation grille for efficient heat dissipation.
Passive crossover specifically designed for MP 70.3 and MP 25.3 when installed in a 3-way multi-amp system and combined with an actively driven MP 165.3/ MP 165P.3 woofer.

Hertz Mille Pro MPCX 2 TM.3 Datenblatt

Datenblatt öffnen

Frequent questions about Mille Pro MPCX 2 TM.3

Was sind die technischen Highlights der Mille Pro MPCX 2 TM.3?

The Mille Pro MPCX 2 TM.3 from Hertz impresses with its technical highlights, including the tweeter adjustment of 0/+2 dB. It offers crossover characteristics with a midrange low pass at 5.5 kHz with -6 dB/oct. and a tweeter high pass at 5.5 kHz with -12 dB/oct. High-quality, bi-metalized polyester film capacitors and 1-mm inductors made of pure copper wire ensure exquisite sound quality. These features guarantee perfect sound transparency and clean mid and high frequencies. Additionally, the design is space-saving, allowing for easy installation. An upper ventilation grille ensures efficient heat dissipation.

Wie beeinflusst die Hochtöneranpassung der MPCX 2 TM.3 den Klang?

The tweeter adjustment of the Mille Pro MPCX 2 TM.3 allows for fine-tuning of the sound emission of the transducer through a two-position switch (0 / +2 dB). This feature is particularly valuable if you have different acoustic preferences or specific requirements regarding sound characteristics. With this adjustment, you can set the level of the tweeter according to your individual needs, achieving an optimal balance between bass, midrange, and high frequencies, thereby improving the overall clarity and sound fidelity of the audio system. This is beneficial for anyone who prefers subtle nuances in sound.

Für welche Verstärkeranlage ist die Mille Pro MPCX 2 TM.3 geeignet?

The Mille Pro MPCX 2 TM.3 crossover from Hertz has been specifically designed for use in a 3-way amplifier system. It harmonizes perfectly with the models MP 70.3 and MP 25.3 and can be actively used in combination with a woofer such as the MP 165.3 or MP 165P.3. This synergy allows for the creation of a multi-channel audio system that impresses with precise frequency separation and excellent sound quality. Especially in conjunction with the mentioned components, an optimally tuned acoustic performance is achieved that is sure to delight music lovers.

Welche Rolle spielen die bimetallisierten Polyesterfolienkondensatoren in der MPCX 2 TM.3?

The bimetallized polyester film capacitors are a key element for the sound quality of the Mille Pro MPCX 2 TM.3. These capacitors are extremely high quality and feature a very low dissipation factor (DF). They significantly contribute to maximum sound transparency and enable clean midrange and high-frequency reproduction. Their use effectively reduces signal losses and improves the transient response of the audio system, ensuring accurate and dynamic sound reproduction. These technical characteristics make the capacitors essential for discerning audiophiles.

Wie ist die Frequenztrennung der MPCX 2 TM.3 konzipiert?

The frequency separation in the Mille Pro MPCX 2 TM.3 occurs precisely at 5.5 kHz for both the midrange low-pass and the tweeter high-pass. The midrange low-pass has a slope of -6 dB/octave, while the tweeter high-pass operates with a steeper slope of -12 dB/octave. This careful tuning ensures precise frequency control and allows for smooth integration between different speaker elements. This separation minimizes frequency overlaps and interferences, which in turn improves the sound resolution and fidelity of the entire audio system.

Welche physikalischen Abmessungen hat die Mille Pro MPCX 2 TM.3?

The Mille Pro MPCX 2 TM.3 from Hertz has compact physical specifications that make it particularly flexible and easy to install. The dimensions are 102 mm in length, 76.5 mm in width, and 37 mm in height. This space-saving design allows the crossover to fit into a variety of installation environments without taking up valuable space. Particularly advantageous is the low weight of only 0.16 kg, which further facilitates handling and assembly. Overall, these dimensions contribute to the flexibility of use.

Welche Materialien werden bei der MPCX 2 TM.3 für die Induktivitäten verwendet?

In the Mille Pro MPCX 2 TM.3, 1-mm thick pure copper wire coils are used for the inductors. This material choice is crucial to ensure low-loss signal transmissions, especially in the mid-frequency range where high transient currents occur. Pure copper wire is characterized by a low series resistance, which improves electrical efficiency and minimizes losses. These properties significantly contribute to the crossover providing excellent sound dynamics and an impressive frequency response, which is optimal for demanding sound reproduction.

Wie einfach ist die Installation der Mille Pro MPCX 2 TM.3?

The installation of the Mille Pro MPCX 2 TM.3 is simple and flexible due to its space-saving and well-thought-out design. Its compact dimensions of 102 x 76.5 x 37 mm allow for installation in various vehicle models and situations without taking up significant space. Additionally, a top ventilation grille supports efficient heat dissipation, which increases longevity and reliability when used in the vehicle. These physical properties facilitate integration into existing audio systems, allowing even novices to perform an installation easily without special tools.

Warum ist ein Lüftungsgitter bei der MPCX 2 TM.3 wichtig?

The ventilation grille plays a crucial role in the Mille Pro MPCX 2 TM.3 by ensuring efficient heat dissipation. During operation, the active components generate heat that must be dissipated to avoid impairing the performance and lifespan of the device. The above design with a ventilation grille helps to lower the operating temperature, which can protect the crossover from overheating, thereby increasing the stability and reliability of the entire audio system. Thus, it significantly contributes to the functionality and safety of the installation.

Welche Kompatibilität bietet die Mille Pro MPCX 2 TM.3 mit anderen Hertz-Produkten?

The Mille Pro MPCX 2 TM.3 is specifically designed for seamless integration into Hertz product systems. It works particularly well with the models MP 70.3 and MP 25.3 and is ideal for combination with the woofers MP 165.3 and MP 165P.3 when they are operated actively. These compatible systems form a coordinated unit that offers outstanding sound performance. This specific tuning ensures that frequency separation and sound dynamics are optimally matched, providing an impressive acoustic backdrop for music lovers.
