MANL fuse holder

Name: Ground Zero GZFH 3.50/4.20 ANL/MANL fuse holder
Brand: Ground Zero
Price: 67.15 EUR
Availability: InStock

CYBER -15%

Max, Mikael and 53k+ customers already with Masori sound upgrade

Ground Zero GZFH 3.50/4.20 ANL/MANL fuse holder

3x 50 mm² input, 4x 20 mm² output, anodized copper.
ANL or Mini-ANL fuse holder, screw terminals, robust.
Plastic cover, recommended fuse values up to 300 A.
Mehr technische Details

00

€67,15

~~€79,00~~ €67,15

5% Rabatt mit Vorkasse

inkl. VAT , possibly plus shipping

Bequem in 12 zinsfreien Raten à €5,59 mit Klarna zahlen.

Jetzt mit kostenlosem Versand ab 50€!

Shipping cost calculator

Land/Region

PLZ

Garantie & zusätzlicher Geräteschutz für dein HiFi-System

3 Jahre Masori Garantie Kostenlos 48 Monate Plusgarantie €14,99 60 Monate Plusgarantie Am beliebtesten €19,99

Deshalb wählen uns 100.000+ Kunden

3 Jahre Garantie

Sicher & sorglos
Blitzversand

mit DHL Express
Tiefpreisschutz

Nie zu viel zahlen

Rob

Max

Unsicher, ob dieses Produkt zu deinem Auto passt?

Wir helfen dir – schnell, persönlich und unverbindlich.

Antwort on weekdays within 24h

Ground ZeroCompetition GZCK 165 XSPL

Ground ZeroGZST 4S

GZFH 3.50/4.20 ANL/MANL by Ground Zero

Discover the GZFH 3.50/4.20 ANL/MANL fuse holder from Ground Zero. It features a robust anodized copper construction, making it designed for durability. Additionally, it comes with useful features such as an ANL or Mini-ANL fuse holder and a 3x 50 mm² input and 4x 20 mm² output. Furthermore, it includes screw terminals and a plastic cover. The recommended fuse values allow you to determine and utilize optimal and maximum fuse performance based on cable cross-section. Rest assured that with Ground Zero, you have a high-quality and reliable tool at hand.

features

ANL or Mini-ANL fuse holder
3x 50 mm² input and 4x 20 mm² output
Massive anodized copper
Incl. plastic cover
screw connections

Recommended security values

cable cross-section	optimal collateral value	maximal collateral value
1.5 mm²	10 A	15 A
2.5 mm²	20 A	25 A
4.0 mm²	25 A	30 A
6.0 mm²	35 A	40 A
10 mm²	50 A	60 A
16 mm²	70 A	80 A
20 mm²	90 A	100 A
25 mm²	100 A	125 A
35 mm²	125 A	150 A
50 mm²	160 A	200 A
70 mm²	200 A	250 A
95 mm²	250 A	300 A

Frequent questions about GZFH 3.50/4.20 ANL/MANL

Wie viele Eingänge und Ausgänge hat der GZFH 3.50/4.20 ANL/MANL Sicherungshalter?

The GZFH 3.50/4.20 ANL/MANL fuse holder from Ground Zero features a configuration that includes three 50 mm² inputs and four 20 mm² outputs. This capacity allows for versatile adaptation to various application scenarios in the field of vehicle technology. The sizing of the inputs and outputs is optimally matched to the power requirements that may be needed in demanding audio and vehicle installations. This specification also enables efficient power distribution in complex systems, ensuring the simultaneous use of multiple devices while maintaining consistent performance.

Welche Materialien werden im GZFH 3.50/4.20 ANL/MANL verwendet?

The fuse holder GZFH 3.50/4.20 ANL/MANL from Ground Zero is made of solid anodized copper, which ensures durability and high conductivity. Anodized copper provides optimal protection against corrosion, which is especially important when the fuse holder is used in high-humidity environments. In addition, a robust plastic cover protects sensitive components from physical influences and maintains the internal integrity of the cable management. The material used not only guarantees lasting functionality but also supports the high electrical stability and efficiency of the fuse holder.

Welche Arten von Sicherungen können mit dem GZFH 3.50/4.20 ANL/MANL verwendet werden?

The GZFH 3.50/4.20 ANL/MANL fuse holder from Ground Zero is compatible with ANL and Mini-ANL fuses. This versatility allows for a wide range of applications, as ANL fuses are typically designed for larger current ratings, while Mini-ANL fuses represent a more compact option. The choice between these two formats enables users to tailor the fuse option precisely to the respective electrical load and cable cross-section. With the recommended fuse ratings, an optimal balance between protection and performance can be achieved. This is particularly relevant in the field of demanding audio and vehicle installations.

Wie installiere ich den GZFH 3.50/4.20 ANL/MANL Sicherungshalter im Fahrzeug?

The installation of the GZFH 3.50/4.20 ANL/MANL fuse holder is carried out using the integrated screw terminals, which ensure secure and reliable cable connections. Ensure that the cable cross-sections match the recommended fuse ratings to ensure optimal performance and safety. The plastic cover serves as additional protection during installation and reduces the risk of short circuits due to unintended contact. Since the design is compact, the fuse holder can be mounted in various positions in the vehicle without taking up unnecessary space. Proper installation can also maximize the performance yield of the connected components.

Welche Sicherungswerte werden für den GZFH 3.50/4.20 ANL/MANL empfohlen?

The fuse ratings for the GZFH 3.50/4.20 ANL/MANL vary depending on the cable cross-section. For 1.5 mm², an optimal fuse rating of 10 A is recommended, with 15 A as the maximum. For 2.5 mm², 20 A is considered optimal, 25 A as the maximum. For 4.0 mm², 25 A is optimal, 30 A maximum. 6.0 mm² has an optimal value of 35 A, with a maximum of 40 A. Furthermore, for 10 mm², 50 A is optimal, 60 A maximum fuse. 16 mm² follows with 70 A optimal and 80 A maximum. 20 mm², 25 mm², 35 mm², 50 mm², 70 mm², and 95 mm² require fuse rating adjustments according to the power, with values ranging from 90 A to 300 A depending on the need for continuous power safety.

Welche technischen Vorteile bietet das eloxierte Kupfer des GZFH 3.50/4.20 ANL/MANL?

The anodized copper of the GZFH 3.50/4.20 ANL/MANL fuse holder offers significant technical advantages over conventional materials. Anodized copper ensures outstanding conductivity, which is essential for reliable power transmission. The anodization also protects the material from external influences and corrosion, meaning that the fuse holder demonstrates a long lifespan even in harsher environments. These properties are particularly important for initiating stable power flows in electrical circuits, where meticulous stability and power transmission are of central importance. Therefore, the material is suitable for both demanding and everyday applications in the vehicle interior.

Kann der Sicherungshalter GZFH 3.50/4.20 ANL/MANL mit gängigen Fahrzeugaudiosystemen verwendet werden?

The design of the GZFH 3.50/4.20 ANL/MANL fuse holder from Ground Zero is designed to be easily integrated into widely used vehicle audio systems. The use of screw terminals and prescribed cable solutions ensures a secure installation and connection with the audio units. With the broad application of ANL and Mini-ANL fuses, it covers a variety of power requirements that radios and speaker systems from certain brands may have. The proper selection of the maximum fuse value according to the cable cross-section is crucial to guarantee functionality and safety in the car system.

Welche Funktionen bietet die Kunststoffabdeckung des GZFH 3.50/4.20 ANL/MANL?

The plastic cover included with the GZFH 3.50/4.20 ANL/MANL fuse holder plays an essential role in protecting the electrical components. It prevents external influences such as dust or moisture from entering the fuse holder and impairing performance. This is particularly crucial for the long-term assurance of electrical integrity and the reliable functioning of the fuse unit. Additionally, the cover reduces the risk of short circuits due to unintended contact with metal parts. It reliably protects even in environments where physical stresses could potentially cause damage without the protection of the cover.

Wie helfen die empfohlenen Sicherungswerte beim Schutz der GZFH 3.50/4.20 ANL/MANL Installation?

The recommended fuse values of the GZFH 3.50/4.20 ANL/MANL fuse holder ensure optimal protection against electrical overloads by ensuring that the cable cross-section used can safely handle the current transit. These specifications are designed to keep the loads within certain limits to avoid overheating or potential damage to the wiring. For example, the maximum limit of 200 A for 50 mm² cables prevents excessive current flow from overloading the cables. At the same time, they ensure that the total power required by the fuse can flow smoothly without overloading or damaging the vehicle components.

Welche Rolle spielen die Schraubanschlüsse im GZFH 3.50/4.20 ANL/MANL?

The screw connections in the GZFH 3.50/4.20 ANL/MANL fuse holder ensure firm and secure connections of power cables. These mechanical connections provide long-term hold and electrical stability, ensuring that the power load flows through the fuse holder without interruption or connection loss. This type of connection is essential for applications where constant movement and vibration may occur, such as in automotive. The precision of the screw connections also allows for an efficient installation process, enabling tech-savvy users to implement or modify the vehicle's electrical infrastructure with minimal effort.
