DD Audio D1100 1-Channel Amplifier

Name: DD Audio D1100 1-Channel Amplifier | Masori
Brand: DD Audio
Price: 254.15 EUR
Availability: InStock

CYBER -15%

Max, Mikael and 53k+ customers already with Masori sound upgrade

DD Audio D1100 1-Channel Amplifier

Total output power: 1100W, continuous power @1Ohm: 1100 x 1.
Frequency response 20-500Hz, THD below 0.2%, RCA input S/N: >80dB.
Full bandpass crossovers, subsonic filter: 25-100Hz, LP filter: 50-500Hz.
Mehr technische Details

00

€254,15

~~€299,00~~ €254,15

5% Rabatt mit Vorkasse

inkl. VAT , possibly plus shipping

Bequem in 12 zinsfreien Raten à €21,17 mit Klarna zahlen.

Jetzt mit kostenlosem Versand ab 50€!

Shipping cost calculator

Land/Region

PLZ

Garantie & zusätzlicher Geräteschutz für dein HiFi-System

3 Jahre Masori Garantie Kostenlos 48 Monate Plusgarantie €24,99 60 Monate Plusgarantie Am beliebtesten €34,99

Deshalb wählen uns 100.000+ Kunden

3 Jahre Garantie

Sicher & sorglos
Blitzversand

mit DHL Express
Tiefpreisschutz

Nie zu viel zahlen

Rob

Max

Unsicher, ob dieses Produkt zu deinem Auto passt?

Wir helfen dir – schnell, persönlich und unverbindlich.

Antwort on weekdays within 24h

Soundigital2000.4 EVOPS

NakamichiN60T

D1100 by DD Audio

The D1100 model from DD Audio is an impressive 1-channel amplifier with special features that set it apart from competitors. As part of the D-Series, the D1100 impresses with its compact size without sacrificing power. With a total output power of 1100 watts, this stable amplifier is ideally suited for your 1-ohm monoblock subwoofer. Your fine-tuning is facilitated by variable bandpass crossovers and an LED clipping indicator, while installation is simplified by single-sided controls and connections as well as an automatic turn-on function. With corrosion-protected switches and conformally coated internal circuits, the D1100 is perfect for use on boats, motorcycles, and ATVs. Rely on the D1100 for accurate power delivery and increased stability and durability in any situation.

features

Conformal coated internal circuits
Corrosion-resistant switches
full bandpass switches
Automatic activation
Clipping Indicators
Differential RCA inputs
Signal looping
Remote level control

Data

1-Channel Amplifier
Operating voltage: 9 - 16
Test voltage: 14.4
Input channel(s): 1
Output channel(s): 1
Continuous power @4ohm: 380 x 1
Continuous power @2Ohm: 700 x 1
Continuous power @1Ohm: 1100 x 1
Maximum current consumption (Amperes): 110
Sensitivity of the RCA input voltage: 8 ~ 0.2
RCA input S/N: > 80dB
Damping factor: > 100
THD: < 0.2%
Frequency response (Hz): 20 ~ 500
Subsonic filter: 25 - 100
Low-pass filter: 50 - 500
Pass Thru Output: Yes
Remote control: Remote control included in the delivery
Power cable diameter: 20mm²
Speaker cable diameter: 6mm²
Dimensions (MM): 220 x 104 x 43

DD Audio D1100 Datenblatt

Datenblatt öffnen

Frequent questions about D1100

Welche Leistung liefert der D1100 Verstärker bei unterschiedlichen Widerständen?

The D1100 amplifier from DD Audio delivers different power levels depending on the impedance of the connected speaker. At an impedance of 4 ohms, the amplifier provides a continuous power output of 380 watts. When the impedance is reduced to 2 ohms, the power increases to an impressive 700 watts. The maximum power is achieved by the D1100 at a 1-ohm impedance, where it can deliver up to 1100 watts of continuous power. This power variability makes the amplifier ideal for various subwoofer configurations without compromising sound quality. Especially with 1-ohm subwoofers, it unleashes its full power.

Wie funktioniert die automatische Einschaltfunktion des D1100?

The automatic power-on function of the D1100 amplifier from DD Audio works by detecting an input signal at the RCA input. Once a signal is detected, the amplifier activates on its own, simplifying the installation process and increasing user-friendliness. This function eliminates the need to manually turn the amplifier on and off, which is particularly advantageous in the realm of ATVs, boats, and motorcycles, where access to the device controls can be limited. In conjunction with the differential RCA inputs, this allows for smooth operation even in challenging environments.

Welche Frequenzweichen sind im D1100 integriert?

The DD Audio D1100 mono amplifier features variable crossovers that allow for precise sound control. The bandpass crossovers are fully adjustable, with the frequency range limits for the low-pass set between 50 to 500 Hz and those for the subsonic filter between 25 to 100 Hz. These options allow for detailed customization for optimal sound performance and bass reproduction. The combination of low-pass and subsonic filters ensures that only the desired frequencies are sent to the subwoofers, reducing distortion and improving sound quality. This is especially important for audiophiles who want to create a specific soundscape.

Welche Dimensionen hat der D1100 Verstärker?

The D1100 amplifier from DD Audio is designed in a compact format that makes its installation easier in numerous vehicle types. With dimensions of 220 mm in length, 104 mm in width, and a height of 43 mm, it fits easily into tight spaces, which is particularly advantageous when space in a vehicle or on a motorcycle is limited. These dimensions make the amplifier an ideal choice for applications where a powerful yet unobtrusive amplifier is required. Keep in mind that the compactness of the device does not limit its performance.

Welche Schutzmechanismen hat der D1100 Verstärker?

The D1100 amplifier offers various protection mechanisms to ensure its performance and longevity. It features conformally coated internal circuits that provide protection against moisture, which is particularly important in environments such as boats and motorcycles. Corrosion-resistant switches minimize the risk of failures due to weather influences. An LED overload indicator warns of excessive signal strength, thus protecting the connected speakers. These features ensure that the amplifier operates stably under diverse conditions and provides a reliable audio experience, regardless of the location of use. Signal pass-throughs complement the protection through error-free signal transmissions.

Welche Anschlüsse bietet der D1100?

The DD Audio D1100 amplifier is equipped with one-sided controls and connections that make installation and connection intuitive. It features differential RCA inputs for main signal processing and offers a signal pass-through option to integrate additional amplifiers into the audio system. For power input, it is designed for a 20 mm² cable connection, while the speaker connections are sized for 6 mm² cables. This variety of connections combines easy installation with high flexibility and ensures excellent audio integrity without performance loss or complications during the sound system configuration.

Wie ist der Frequenzgang des D1100 verstärkers?

The frequency response of the D1100 amplifier from DD Audio ranges from 20 Hz to 500 Hz, making it specifically optimized for bass reproduction. The extensive frequency range allows for seamless integration into sound systems that require a full and powerful bass without unnecessarily affecting the higher frequency range. This frequency response is also relevant for the precise tuning of the bandpass crossovers integrated into the D1100. By adjusting the subsonic filter and the low-pass filter, users can exert precise control over the frequencies that are sent to the subwoofer.

Wie hoch ist der Dämpfungsfaktor beim D1100 Verstärker?

The DD Audio D1100 amplifier offers a damping factor of over 100, making it ideal for controlling and stabilizing speaker membranes in the bass range. A higher damping factor contributes to a more precise and tighter bass sound by effectively controlling the movement of the speaker membrane. This means that the amplified sound remains clean and distortion-free even at high volumes and heavy loads. The combination of the damping factor and the optimized mono-block structure makes the D1100 an essential component for a high-fidelity audio system that values detailed and controlled sound.

Wie wird der D1100 im Fahrzeug installiert?

For the installation of the DD Audio D1100 in the vehicle, the chosen location should provide adequate ventilation and consider the dimensions of 220 x 104 x 43 mm. A stable mounting is essential to minimize vibrations and prevent acoustic interference. The amplifier requires a power cable diameter of 20 mm² and speaker cables with a diameter of 6 mm² for optimal operation. The one-sided controls and connections simplify cable routing, making both the wiring and access to the main functions efficient. The reliable power supply is provided through the specified operating voltage of 9 to 16 volts.

Welche Stromversorgung ist für den D1100 erforderlich?

The D1100 amplifier from DD Audio requires an operating voltage between 9 and 16 volts to function properly. During the voltage test, a voltage of 14.4 volts is used, which serves as a reference value for maximum power output. The maximum current draw is 110 amperes, which means that the power source must be appropriately sized to fully utilize the amplifier's power. A stable and well-sized power supply is crucial for optimal operation of the amplifier and to ensure its continuous power at various speaker variations. This ensures high power reserves for sound requirements of various applications in the vehicle.
