Deaf Bonce Apocalypse DB-3012R 12" (30cm) Subwoofer

4 Reviews

2800 Watt

Apocalypse DB-3012R

4 Reviews

Technical Highlights

  • RMS power 2800 watts, ribbed surround structure, carbon dust cap.
  • Impedance 1+1 / 2+2 Ohm, SPL 86.00 / 86.50 dB.
  • Installation depth 224.0 mm, cut-out size 284.0 mm, weight 27.90 kg.
  • More technical details
10% Code "PREORDER-10"
€899,00
€899,00 €899,00
inkl. VAT , possibly plus shipping
Impedance: D1 (2x1 Ohm)
Delivery
Delivered automatically as soon as available from the supplier.
x Piece
  • American Express
  • Apple Pay
  • Bancontact
  • BLIK
  • EPS
  • Google Pay
  • iDEAL Wero
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Shop Pay
  • Twint
  • Union Pay
  • Visa
Klarna Pay conveniently in 12 interest-free installments at €74,91 with Klarna .

Your benefits at Masori

Seen cheaper elsewhere?

Shipping cost calculator

Expert Image

Rob

Expert Image

Max

Unsure if this product fits your car?

We help you – quickly, personally, and without obligation.

Response on weekdays within 24 hours
Deaf BonceApocalypse AP-M61SE Pro
Deaf Bonce-Apocalypse AP-M61SE Pro-6.5" (16,5cm) Tiefmitteltöner-masori-kaufen
Masori-LR-15/18-165mm massiv-Lautsprecherringe-masori-kaufen
MasoriLR-15/18-165mm solid
Deaf Bonce-Apocalypse DB-3012R-12" (30cm) Subwoofer-masori-kaufen
€899,00
€899,00 €899,00

Compatible with Apocalypse DB-3012R

  • Deaf Bonce-Apocalypse ASA-4000.1-1-Kanal Verstärker-masori-kaufen Deaf Bonce-Apocalypse ASA-4000.1-1-Kanal Verstärker-masori-kaufen
    4000 Watt

    Apocalypse ASA-4000.1

    Deaf Bonce
    €799,00
    €799,00 €799,00
    Delivery
    May 11, - May 16,
  • DD Audio-M5000-1-Kanal Verstärker-masori-kaufen DD Audio-M5000-1-Kanal Verstärker-masori-kaufen
    5000 Watt

    M5000

    DD Audio
    €1.199,00
    €1.199,00 €1.199,00
    Delivery
    May 11, - May 16,
  • Deaf Bonce-Apocalypse Atom 5.5K Pro-1-Kanal Verstärker-masori-kaufen Deaf Bonce-Apocalypse Atom 5.5K Pro-1-Kanal Verstärker-masori-kaufen
    5500 Watt

    Apocalypse Atom 5.5K Pro

    Deaf Bonce
    €569,00
    €569,00 €569,00
    Delivery
    May 11, - May 16,
  • The Masori Big Pro BR12-60 is a black, empty 12 subwoofer box with circular cutout, rectangular port, and blue wires inside, shown on a white background.

    Big Pro BR12-60

    Masori
    €239,00
    €239,00 €239,00
    Delivery
    Delivered automatically as soon as available from the supplier.

Apocalypse DB-3012R by Deaf Bonce

Apocalypse DB-3012R is a 12-inch (30 cm) Subwoofer from Deaf Bonce. Designed for 2800 Watts RMS and 5600 Watts maximum. The ribbed surround structure allows for linear displacements of 19 mm in each direction; Xmech 38 mm. The dust cap is made of carbon, reducing the diaphragm mass and additionally stiffening the diaphragm. The voice coil is generously ventilated. Paper cone, foam surround, ferrite magnet, and aluminum frame. The voice coil measures 76.2 mm. Impedance 1+1 Ohm or 2+2 Ohm, SPL 86.0 / 86.5 dB, Fs 33.0 / 33.8 Hz, Qts 0.41 / 0.43, BL 23.8 / 26.0, Vas 29.5 / 30.2 liters. Installation depth 224 mm, cutout size 284 mm, gross weight 27.9 kg.

Features
  • 12-inch (30 cm) Subwoofer
  • RMS power 2800 Watts
  • Maximum power 5600 Watts
  • Impedance 1+1 Ohm or 2+2 Ohm
  • Variants DB-3012R D1 / DB-3012R D2
  • Voice coil 76.2 mm
  • Ribbed surround structure
  • Linear displacement 19 mm in each direction
  • Dust cap made of carbon
  • Reduced diaphragm mass
  • Additional diaphragm stiffening
  • Generously ventilated voice coil
  • Cone paper
  • Magnet ferrite
  • Surround foam
  • Frame aluminum
Technical Specifications
  • SPL 86.0 / 86.5 dB
  • Resonance frequency Fs 33.0 / 33.8 Hz
  • Total quality factor Qts 0.41 / 0.43
  • BL 23.8 / 26.0
  • Equivalent volume Vas 29.5 / 30.2 liters
  • Xmech 38.0 mm
  • Xmax 19.0 mm
  • Installation depth 224.0 mm
  • Cutout size 284.0 mm
  • Gross weight 27.90 kg

Your benefits at Masori

12" (30cm) Subwoofer available now

    Deaf Bonce Apocalypse DB-3012R Datasheet

    Open datasheet

    Frequently Asked Questions about Apocalypse DB-3012R

    What performance does the Apocalypse DB-3012R Subwoofer offer?

    The Apocalypse DB-3012R from Deaf Bonce impresses with remarkable performance. The RMS power is 2800 watts, while the maximum power reaches an impressive 5600 watts. This performance makes it an ideal companion for those seeking powerful bass output. The Subwoofer is perfect for applications where high power and precise bass reproduction are required, and its robust construction supports various acoustic demands. The maximum excursion of 38 mm ensures powerful bass reproduction, while the carbon dust cap and ribbed surround structure optimize performance.

    What are the Thiele-Small parameters of the Apocalypse DB-3012R?

    The Thiele-Small parameters of the Apocalypse DB-3012R are optimized for precision and performance. The Subwoofer has an Fs value of 33.00 Hz for the DB-3012R D1 model and 33.80 Hz for the D2 model, indicating its deep bass capabilities. The Qts value is 0.41 and 0.43, the BL is 23.80 and 26.00, and the Vas is 29.50 and 30.20 liters. These parameters are tuned for use in various sized enclosures. The SPL value is 86.00 dB and 86.50 dB, indicating an enormous efficiency, ideal for loud and dynamic music.

    What materials are used in the construction of the Apocalypse DB-3012R?

    The construction of the Apocalypse DB-3012R from Deaf Bonce features high-quality materials. The diaphragm is made of paper, which is commonly used in speaker construction due to its acoustic properties. The dust cap is made of carbon, which reduces the diaphragm mass and achieves increased stiffness. The frame is made of aluminum, providing stability and effective vibration damping. The ferrite magnet is a central component that supplies the Subwoofer with strong attraction. This combination of materials makes it robust and acoustically convincing.

    How is the installation compatibility of the Apocalypse DB-3012R in the car ensured?

    The installation compatibility of the Apocalypse DB-3012R is well thought out to allow for easy integration into vehicles. The Subwoofer has a mounting diameter of 284.0 mm and a mounting depth of 224.0 mm, making it compatible with a variety of vehicle models. An important requirement for installation is the availability of a sufficiently large cutout and suitable mounting space in the vehicle. When integrating into the vehicle, attention should be paid to the electrical impedance, which is 1+1 Ohm for model D1 and 2+2 Ohm for model D2, to ensure safe and optimal performance.

    Can the Apocalypse DB-3012R be used with different types of vehicles?

    The use of the Deaf Bonce Apocalypse DB-3012R is versatile, as its dimensions and impedance options allow for adaptability to various vehicles. Importantly, the mounting depth of 224.0 mm and the mounting diameter of 284.0 mm are crucial when checking compatibility with the installation location in the vehicle. Regarding brand compatibility, there is nothing against using the Subwoofer in common brands and models; however, the final decision depends on the specific space conditions and audio requirements of the car. Further adjustments may be necessary to optimize space and mounting.

    What are the features of the ribbed surround structure on the DB-3012R?

    The ribbed surround structure of the Apocalypse DB-3012R is a unique design feature that was carefully chosen by Deaf Bonce. This structure allows the diaphragm to have particularly long excursions of up to 19 mm in any direction, resulting in exceptional bass performance. The ribs of the surround significantly contribute to ensuring stability at high volumes while minimizing distortion. Especially if you enjoy listening to music loudly, this structure provides improved linearity and greater control over diaphragm movement, ultimately producing clearer and more comprehensive bass.

    What influence does the carbon dust cap have on the sound of the DB-3012R?

    The carbon dust cap of the Apocalypse DB-3012R offers both aesthetic and technical advantages. By using carbon, the diaphragm mass is reduced, which increases its movement speed. This increased speed of diaphragm movement allows for faster and more precise reproduction of bass notes, leading to improved impulse response. The additional stiffness achieved through carbon helps minimize unwanted resonances, further enhancing the sound purity and accuracy of bass reproduction. Thus, the carbon dust cap significantly contributes to the acoustically optimal performance of the Subwoofer, making it suitable for audiophile applications.

    How do the large ventilation openings affect the performance of the DB-3012R?

    The generous ventilation in the Deaf Bonce DB-3012R plays a crucial role in reducing heat buildup during operation. The strategically placed openings on the centering spider ensure that the heat generated in the Subwoofer is efficiently dissipated. This feature is particularly important for the longevity of the system under high loads and during prolonged use at high volume. By lowering the temperature inside the Subwoofer, the electrical components are protected from overheating, which positively affects the overall stability and performance of the Subwoofer.

    Why was a ferrite magnet used in the DB-3012R?

    The ferrite magnet in the Apocalypse DB-3012R from Deaf Bonce is designed for performance and cost efficiency. Ferrite magnets are known for their high stability and resistance to temperature fluctuations. These properties make them ideal for use in high-performance Subwoofers that are subjected to heavy loads. The strong magnetic attraction of the ferrite material ensures precise control of the voice coil, resulting in deep and controlled bass. Compared to other materials, ferrite represents a cost-effective solution that does not compromise on high performance.

    What impedance options are available for the DB-3012R and how do they affect usage?

    The Apocalypse DB-3012R offers various impedance options that make it flexible in use. It is available as model DB-3012R D1 with 1+1 ohm and as model D2 with 2+2 ohm. These options allow the Subwoofer to be configured appropriately depending on the amplifier and wiring. A lower impedance can lead to higher power consumption, provided the amplifier is designed for it. This flexibility in impedance choice is particularly useful for users who prefer customized audio solutions and want to optimally match their hardware.
