DD Audio C4.60 4-channel amplifier

Name: DD Audio C4.60 4-Channel Amplifier | Masori
Brand: DD Audio
Price: 152.15 EUR
Availability: InStock

CYBER -15%

Max, Mikael and 53k+ customers already with Masori sound upgrade

DD Audio C4.60 4-channel amplifier

Power: 4 x 60W @ 4Ω, 4 x 90W @ 2Ω, 2 x 180W bridge.
2 Ohm stereo stable, 4 Ohm bridged, Class AB design.
Variable HPF/LPF crossovers, 4-way protection system integrated.
Mehr technische Details

00

€152,15

~~€179,00~~ €152,15

5% Rabatt mit Vorkasse

inkl. VAT , possibly plus shipping

Bequem in 12 zinsfreien Raten à €12,67 mit Klarna zahlen.

Jetzt mit kostenlosem Versand ab 50€!

Shipping cost calculator

Land/Region

PLZ

Garantie & zusätzlicher Geräteschutz für dein HiFi-System

3 Jahre Masori Garantie Kostenlos 48 Monate Plusgarantie €14,99 60 Monate Plusgarantie Am beliebtesten €19,99

Deshalb wählen uns 100.000+ Kunden

3 Jahre Garantie

Sicher & sorglos
Blitzversand

mit DHL Express
Tiefpreisschutz

Nie zu viel zahlen

Rob

Max

Unsicher, ob dieses Produkt zu deinem Auto passt?

Wir helfen dir – schnell, persönlich und unverbindlich.

Antwort on weekdays within 24h

DD AudioSS4.1300-24V

DD AudioD4.75

C4.60 by DD Audio

Discover the dynamics of sound with the C4.60, a 4-channel amplifier from DD Audio. This amplifier from the C-Series offers a perfect solution for driving subwoofers and tweeters. The unique Class-AB circuit design ensures a warm, dynamic sound across the entire frequency range. Thanks to its single-sided control panel, installation is quick and clean, and the new housing design gives it an elegant aesthetic. With additional features such as bandpass crossovers, signal loop-through outputs, and screw terminals, the C4.60 provides convenient cable management and easy audio settings.

C Series Features

Mosfet power supply amplifier
20mm2 power connections
Variable 12dB/oct HPF and 18dB/oct LPF crossovers
Pass-Through Outputs (RCA)
Subwoofer remote control optionally available
4-way protection: surge, short circuit, thermal, DC offset

data

4-channel amplifier
Stereo 2 Ohm / bridged 4 Ohm stable
Dimensions 318x175x54 mm
Power @ 4Ω 14.4v 1% THD: 4 x 60 W
Power @ 2Ω 14.4v 1% THD: 4 x 90 W
Power @ 4Ω Bridge 14.4v 1% THD: 2 x 180 W

Frequent questions about C4.60

Was sind die wichtigsten technischen Merkmale des C4.60 Verstärkers von DD Audio?

The C4.60 from DD Audio is a 4-channel Class AB amplifier that offers unparalleled sound dynamics. It features a Mosfet power supply amplification and serves both low and high-frequency speakers. With 20mm² power connections and a frequency range through variable 12dB/oct HPF and 18dB/oct LPF crossovers, it allows for fine adjustments. Additional signal loop-through outputs (RCA) and optional subwoofer remote control provide excellent control. A quadruple protection system safeguards against overvoltage, short circuits, thermal, and DC offset hazards. Its dimensions are 318x175x54 mm.

Wie hoch ist die Ausgangsleistung des C4.60 bei unterschiedlichen Ohm-Lasten?

The amplifier C4.60 delivers a power of 4 x 60 watts at a load of 4Ω and a voltage of 14.4V with 1% THD. At a load of 2Ω, it provides a better output of 4 x 90 watts under the same conditions. When used in bridge mode, it delivers two channels with 180 watts each at 4Ω. This power is paired with an exceptionally high level of sound detail, which becomes particularly relevant when you wish to enjoy your music in the best quality even at high volumes.

Wie erfolgt die Installation des DD Audio C4.60 im Fahrzeug?

The installation of the DD Audio C4.60 is intuitive and clean due to the one-sided control panel. The compact dimensions of the housing are 318x175x54 mm, allowing for flexible placement in various environments. The amplifier offers screw terminals for cable management, enabling careful storage of the connection cables. It is advisable to leave sufficient space around the amplifier to ensure that heat is effectively dissipated. Also essential: ensuring a secure power connection via the 20mm² power connections.

Wie unterscheiden sich die Frequenzweichen des C4.60 in Bezug auf Hoch- und Tieftöne?

The C4.60 offers highly customizable crossovers: a variable 12dB/octave high-pass filter (HPF) and an 18dB/octave low-pass filter (LPF). These allow for precise adjustment of the crossover frequencies to optimally tune the sound characteristics for both tweeters and subwoofers. Especially when used in a vehicle, where both low and high frequencies are reproduced at different positions within the interior, the tuning capability of the crossovers plays a significant role in creating a harmonious sound experience.

Welche Schutzmechanismen hat der Verstärker C4.60 eingebaut?

The DD Audio C4.60 is equipped with a comprehensive 4-way protection system that protects against overvoltage, short circuits, thermal overloads, and DC offset. This is particularly important to prevent damage to both the amplifier and the connected components such as speakers. The overvoltage protection prevents excessive voltage spikes from damaging the electronics, while the short circuit protection acts to safeguard against sudden current flow. Thermal monitoring helps control heat developments to keep the amplifier operation within a safe temperature range.

Wie verbessert das Klasse-AB-Schaltungsdesign des C4.60 den Klang?

The Class AB circuit design of the C4.60 allows for the combination of the advantages of both Class A and Class B amplifiers: efficiency and sound fidelity. This circuit provides a warm, dynamic sound across the entire frequency range, ideal for music lovers who value fine sound details. The Class AB architecture enhances linearity and reduces distortion in the audible frequency range, making the sound particularly vibrant. Especially when you enjoy listening to music at high volumes, this technology ensures that no sound distortions occur.

Welche Kabelmanagementoptionen bietet der C4.60?

The DD Audio C4.60 is equipped with a thoughtful cable management system that allows for a clean and organized installation. The screw terminals for the cable connections provide a firm and secure hold for the power and speaker cables, while the pass-through outputs (RCA) facilitate easy wiring between different audio components. The carefully designed single-sided control panel makes access to all connections easy, allowing for efficient installation without creating unwanted clutter in the vehicle's interior.

Beeinflusst die Abmessung des C4.60 seine Eignung für mein Auto?

The dimensions of the amplifier C4.60 are 318x175x54 mm, which gives it versatile popularity in various car installations. When selecting an installation location, it should be considered that there is enough space for air circulation and cable connections. Its slim, compact design ensures that it blends in unobtrusively and can be installed more easily in small or cramped spaces where larger amplifiers would not fit. It remains important to utilize this space efficiently to ensure maximum sound performance.

Was unterscheidet die C-Serie Mosfet-Stromversorgungsverstärker?

The C-Series Mosfet power supply amplifiers from DD Audio, including the C4.60, utilize state-of-the-art Mosfet technology for voltage amplification. This ensures fast switching times and high energy efficiency while the power supply remains reliable. Compared to traditional transistor amplifiers, the Mosfet circuit provides improved thermal stability and resilience against electrical fluctuations. Such characteristics make the C4.60 a reliable companion in demanding audio applications, where consistently high performance and rapid rise in distortion are crucial for audio quality.

Für welche Fahrzeuge ist der C4.60-Verstärker besonders geeignet?

The C4.60 from DD Audio is compatible with a variety of vehicle types due to its universal dimensions and performance features. With a height of only 54 mm, it fits seamlessly into smaller vehicles or compact installation spaces without compromising sound quality. No specific brand recommendations are given; however, it harmonizes well with vehicles that have existing 2- or 4-ohm speaker systems, which it can optimally serve. Such a complete package makes it a great choice for car enthusiasts who desire excellent sound amplification.
