Rockford Fosgate Punch P132 3" (8cm) Coaxial Speaker
SKU:  P132
EAN:  780687328979
20 Watt

Punch P132

SKU:  P132
EAN:  780687328979

Technical Highlights

  • Power 20 watts RMS, 40 watts max., impedance 4 ohms.
  • Frequency response 120 Hz–22 kHz, sensitivity 85 dB.
  • Injection-molded polypropylene cone, FlexFit basket, PEI tweeter.
  • More technical details
00 d
00 h
00 m
00 s
€66,44
€69,00 €66,44
5% discount with credit card
inkl. VAT , possibly plus shipping
Delivery
Jun 5, - Jun 8,
x pair
  • American Express
  • Apple Pay
  • Bancontact
  • BLIK
  • EPS
  • Google Pay
  • iDEAL Wero
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Shop Pay
  • Twint
  • Union Pay
  • Visa
Klarna Pay conveniently in 12 interest-free installments at €5,53 with Klarna .

Your benefits at Masori

Seen cheaper elsewhere?

Shipping cost calculator

Expert Image

Rob

Expert Image

Max

Unsure if this product fits your car?

We help you – quickly, personally, and without obligation.

Response on weekdays within 24 hours
Rockford Fosgate-Punch P132-3" (8cm) Koaxial-Lautsprecher-masori-kaufen
€66,44
€69,00 €66,44

Punch P132 by Rockford Fosgate

The Punch P132 from Rockford Fosgate is a compact 3-inch coaxial speaker. It features a injection-molded, mineral-filled polypropylene cone and a butyl rubber surround in the midrange. The rated power handling is 20 watts RMS and the maximum power handling is 40 watts. The system has a nominal impedance of 4 ohms and operates in a frequency range of 120 Hz to 22 kHz. A FlexFit basket design and a PEI dome tweeter are components of the construction. The sensitivity is 85 dB at 1 W per 1 m.

Features
  • 3-inch (8 cm) coaxial speaker
  • Injection-molded, mineral-filled polypropylene cone
  • Butyl rubber surround in the midrange
  • FlexFit basket design
  • PEI dome tweeter
  • Power: 20 watts RMS
  • Power: 40 watts max.
Technical Specifications
  • Nominal impedance: 4 ohms
  • Speaker type: 2-way coax
  • Mounting depth: 35 mm
  • Tweeter size: 12.7 mm
  • Sensitivity: 85 dB
  • Midrange size: 90 mm
  • Frequency response: 120 Hz – 22 kHz
  • Tweeter with integrated crossover

Your benefits at Masori

Rockford Fosgate Punch P132 Datasheet

Open datasheet

Frequently Asked Questions about Punch P132

What is the maximum RMS amplification factor of the Rockford Fosgate Punch P132 and how does it affect sound quality?

The Rockford Fosgate Punch P132 offers a power handling of 20 Watts RMS and can temporarily process up to 40 Watts maximum. These power ratings allow for clear and distortion-free playback, even at higher volumes. The robust construction with a molded, mineral-filled polypropylene cone contributes to the speaker's stability, while the butyl rubber surround in the midrange ensures precise midrange sound reproduction. This enables a balanced sound quality that presents both bass and treble in detail and clarity.

How does the FlexFit basket design of the Rockford Fosgate Punch P132 contribute to installation?

The FlexFit basket design of the Rockford Fosgate Punch P132 allows for straightforward and flexible installation in various vehicles. With a mounting depth of only 35 mm, the 3" coaxial speaker fits easily into tight spaces and facilitates integration into existing speaker positions. The design-oriented FlexFit system ensures that the speaker sits securely and stably, minimizing vibrations and ensuring consistent sound reproduction. This is particularly advantageous when you want to optimize the speaker in vehicles with limited space.

What advantages does the PEI dome tweeter in the Rockford Fosgate Punch P132 offer?

The Rockford Fosgate Punch P132 is equipped with a PEI dome tweeter that provides superior high-frequency reproduction. PEI (Polyetherimide) is a material known for its high stiffness and durability, resulting in distortion-free and clear sound reproduction. This tweeter allows for precise playback of high frequencies, enhancing music details and speech intelligibility. The integrated crossover in the tweeter also ensures efficient separation of frequency ranges, contributing to an overall balanced sound.

What frequency ranges does the Rockford Fosgate Punch P132 cover and how does this affect the listening experience?

The Rockford Fosgate Punch P132 has a frequency response of 120 Hz to 22 kHz, covering a wide range of tones. This range allows for the reproduction of deep bass to clear, high-frequency sounds, ensuring a detailed and balanced listening experience. Particularly, the high frequency range of 22 kHz enables the reproduction of fine details and ambient sounds in music, while the 120 Hz goes lower to provide enough bass for a full sound profile. This makes the Punch P132 suitable for those who desire versatile and precise sound quality in their vehicle.

How does the nominal impedance of 4 ohms affect the Rockford Fosgate Punch P132 in an audio system?

The nominal impedance of 4 ohms in the Rockford Fosgate Punch P132 means that the speaker can operate with a wider frequency range at lower voltages. This allows for more efficient power utilization by amplifiers, especially those with a 4-ohm output. A 4-ohm impedance helps the speaker allow for higher current draw, which can lead to better volume and dynamics without distortion. It is important that your audio system is tuned to a 4-ohm load to ensure optimal performance and sound quality.

What advantages does the injection-molded, mineral-filled polypropylene cone in the Punch P132 offer?

The injection-molded, mineral-filled polypropylene cone in the Rockford Fosgate Punch P132 provides high stiffness and damping, minimizing resonances and ensuring clean sound reproduction. Polypropylene itself is a lightweight material that is still robust enough to withstand the stresses of operation. The mineral filling adds mass, improving control over the cone's vibrations and allowing for more precise reproduction of audio signals. This construction ensures that the Punch P132 delivers clear and distortion-free sound output, even at higher volumes.

How does the Rockford Fosgate Punch P132 utilize the butyl rubber surround and what advantages does this offer?

The Rockford Fosgate Punch P132 is equipped with a butyl rubber surround in the midrange. This rubber surround serves to dampen vibrations and minimize resonances in the speaker enclosure. This results in cleaner and more precise midrange sound reproduction, as unwanted vibrations are reduced. Butyl rubber is also durable and resistant to temperature fluctuations, ensuring the stability and reliability of the speaker over time. This technical measure significantly contributes to the clarity and fidelity of the midrange tones.

What role does the integrated Crossover play in the Tweeter of the Punch P132?

The integrated Crossover in the Tweeter of the Rockford Fosgate Punch P132 plays a crucial role in separating and distributing frequencies among the various speaker elements. It ensures that only the high frequencies are directed to the PEI dome Tweeter, while the mid and low frequencies go to the midrange driver. This prevents overlap of frequency ranges and allows for clear and precise sound reproduction. The Crossover thus helps maintain a balanced and distortion-free overall sound, which is particularly beneficial for complex musical pieces and high volumes.

How does the Punch P132 support precision in midrange sound reproduction?

The Rockford Fosgate Punch P132 supports precision in midrange sound reproduction by combining a butyl rubber surround in the midrange and a injection-molded, mineral-filled polypropylene cone. These materials and constructions minimize unwanted resonances and vibrations that could impair the clarity of the midrange. Additionally, the 2-way coaxial design ensures that sound reproduction is consistent and precise, as the midrange driver is directly aligned with the Tweeter. This guarantees coherent sound delivery that enhances the detail and understanding of the midrange frequencies.

What sensitivity does the Punch P132 have and how does it affect volume?

The Rockford Fosgate Punch P132 has a sensitivity of 85 dB at 1 watt and 1 meter. This sensitivity means that the speaker can produce solid volume with lower power input, which is particularly advantageous when your Amplifier is not extremely powerful. A sensitivity of 85 dB allows for efficient use of the supplied energy, achieving good volume and dynamic sound delivery without increasing distortion at moderate volumes. This makes the Punch P132 an effective choice for high-quality vehicle audio systems.
