  3. Vision VXP PRO VXP3M
ESX Vision VXP PRO VXP3M 3" (8cm) Midrange Speaker
SKU:  VXP3M
EAN:  4251476409040
60 Watt

Vision VXP PRO VXP3M

SKU:  VXP3M
EAN:  4251476409040

Technical Highlights

  • 7.5 cm midrange driver, power handling 60 watts RMS, impedance 4 Ω.
  • Frequency range 300 15000 Hz, 25.5 mm voice coils, aluminum baskets.
  • Paper-fiberglass membranes, 43 mm installation depth, 74 mm installation opening.
  • More technical details
€249,00
€249,00 €249,00
5% discount with credit card
inkl. VAT , possibly plus shipping
Delivery
May 25, - May 28,
x pair
  • American Express
  • Apple Pay
  • Bancontact
  • BLIK
  • EPS
  • Google Pay
  • iDEAL Wero
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Shop Pay
  • Twint
  • Union Pay
  • Visa
Klarna Pay conveniently in 12 interest-free installments at €20,75 with Klarna .

Your benefits at Masori

Seen cheaper elsewhere?

Shipping cost calculator

Expert Image

Rob

Expert Image

Max

Unsure if this product fits your car?

We help you – quickly, personally, and without obligation.

Response on weekdays within 24 hours
ESX-Vision VXP PRO VXP3M-3" (8cm) Mitteltöner-masori-kaufen
€249,00
€249,00 €249,00

Vision VXP PRO VXP3M by ESX

The ESX Vision VXP PRO VXP3M is a 3-inch (8 cm) midrange speaker with an aluminum basket and protective grille (Pair). It features paper-fiberglass composite membranes, high-roll surround, and a large spider. 25.5 mm voice coils on a Kapton former. Power handling 60 Watts RMS and 120 Watts Max. Impedance 4 Ohms. Frequency range 300 to 15000 Hz. Mounting depth 43 mm and cutout diameter 74 mm. Aluminum basket with ESX logo.

Features
  • 3-inch (8 cm) midrange speaker
  • With protective grille, pair
  • Aluminum baskets with ESX logo
  • Paper-fiberglass composite membranes
  • High-roll surround
  • Large spider
Technical Specifications
  • Power handling 60 Watts RMS
  • Power handling 120 Watts Max
  • Impedance 4 Ohms
  • Frequency range 300 to 15000 Hz
  • Voice coil 25.5 mm on Kapton former
  • Mounting depth 43 mm
  • Cutout diameter 74 mm
  • Size 75 mm

Your benefits at Masori

ESX Vision VXP PRO VXP3M Datasheet

Open datasheet

Frequently Asked Questions about Vision VXP PRO VXP3M

How does the 30 mm voice coil of the Vision VXP PRO VXP3M affect the sound?

The 30 mm voice coil of the ESX Vision VXP PRO VXP3M midrange driver ensures remarkable sound quality by allowing for greater heat dissipation and load capacity. This results in clear midrange sound without distortion, even at high volumes. Especially if you enjoy listening to music loudly without compromising quality, this voice coil provides optimal performance through its larger excursions. The use of a Kapton carrier for the voice coil maximizes efficiency and thermal stability, which increases the lifespan of the midrange driver. Such features are ideal for audiophiles who appreciate precise midrange frequencies.

What role does the aluminum basket play in the Vision VXP PRO VXP3M?

The aluminum basket of the ESX Vision VXP PRO VXP3M is not only an aesthetic highlight with the embedded ESX brand logo, but it also offers structural advantages. Aluminum is a material that combines low weight with high strength, leading to a reduction in unwanted resonances and distortions. This significantly contributes to a clearer and more detailed sound. The basket also supports the spider and surround by providing a stable installation environment, which enhances the overall stability and performance of the midrange driver. An aluminum basket is an essential aspect for those seeking the highest sound fidelity.

How can the installation depth affect the installation of the Vision VXP PRO VXP3M?

The installation depth of the ESX Vision VXP PRO VXP3M midrange driver is 43 mm, which is a crucial consideration for compatibility with the installation location in a vehicle. This depth requires careful planning of the placement, especially in vehicles with limited space in the door panels or dashboards. The deep integration into the car interior design allows for the full potential of the midrange driver to be utilized without compromising sound quality. The installation opening of 74 mm must also be precisely considered to ensure a secure and vibration-free mounting. Such technical details are critical for installation.

What frequency ranges does the ESX Vision VXP PRO VXP3M cover?

The ESX Vision VXP PRO VXP3M midrange driver has an impressive frequency range of 300 to 15000 Hz. This range allows for the reproduction of mid-range audio frequencies that are crucial for human voices and many musical instruments. The wide coverage ensures that no details in this range are lost, providing a balanced listening experience. Especially in movies or music styles that heavily rely on clear midtones, the VXP3M midrange driver fully showcases its strengths. The ability to cover such a spectrum makes it flexible and universally applicable in various audiophile applications.

How does the 'High-Roll' surround affect sound dynamics?

The 'High-Roll' surround of the ESX Vision VXP PRO VXP3M offers a significant improvement in sound dynamics, particularly for the precise reproduction of mid frequencies. This special surround is designed to maximize cone displacement without causing overextension. This allows the speaker to remain dynamic and sonically precise even during intense musical passages. The structure of the 'High-Roll' surround helps minimize unwanted distortions, leading to a clearer and more detailed sound. This feature is especially useful in applications where high dynamic flexibility is required.

What is the power handling of the ESX Vision VXP PRO VXP3M midrange driver?

The ESX Vision VXP PRO VXP3M has an RMS power handling of 60 watts and a maximum power handling of 120 watts. These specifications are crucial to ensure that the midrange driver is not overloaded and permanently damaged. Especially during longer listening sessions at high volumes, it is important to utilize the RMS values to maintain sound quality and extend the lifespan of the speaker. The power handling values also provide insights into which types of audio systems and amplifiers should be best combined with this speaker for optimal results.

How does the paper-glass fiber composite diaphragm contribute to the performance of the Vision VXP PRO VXP3M?

The paper-glass fiber composite diaphragm of the ESX Vision VXP PRO VXP3M plays a crucial role in the sound quality and durability of the midrange driver. This material combines the acoustic advantages of paper, known for its natural sound fidelity, with the robustness of fiberglass. This combination ensures balanced resonance and minimizes distortion, even at higher volumes. Furthermore, the diaphragm is lightweight, which supports the reproduction of precise transients. For audiophiles who value detailed sound reproduction, this diaphragm material is ideal for clearly defined mid frequencies and dynamic performance.

What impedance does the ESX Vision VXP PRO VXP3M midrange speaker offer?

The ESX Vision VXP PRO VXP3M has an impedance of 4 ohms, which is suitable for most car amplifiers and audio systems. An impedance of 4 ohms ensures that the midrange speaker has an appropriate power draw to ensure efficient power conversion. This impedance is particularly advantageous as it is well compatible with many types of amplifiers and factory vehicle systems, making integration into existing audio systems easier. It is important to note that impedance and amplifier power must be carefully matched to achieve the best sound quality and to avoid overloading the midrange speaker.

Can the ESX Vision VXP PRO VXP3M be installed in cars of different brands?

The compatibility of the ESX Vision VXP PRO VXP3M with various car brands depends on the specific dimensions and installation depth. With an installation depth of 43 mm and a cutout diameter of 74 mm, this midrange speaker should fit in most standard door or dashboard positions. However, special care should be taken in vehicles with limited installation space. The universal 4 ohm impedance facilitates integration into a variety of audio systems from different manufacturers. It is advisable to check the exact dimensions of the installation location before installation to ensure a conflict-free fit.

What maximum volumes can be achieved with the ESX Vision VXP PRO VXP3M?

With a maximum power handling of 120 watts, the ESX Vision VXP PRO VXP3M can achieve impressive volumes without compromising sound quality. This is particularly beneficial if you enjoy dynamic and intense music pieces at high volume. However, it is important to observe the operating limits of the speaker to avoid prolonged overload and potential damage. The combination of robust materials and precise technical design ensures that clear sound reproduction is maintained even at high volumes, making it ideal for experienced audiophiles.
