  3. Voce II AV 10 D4 II

Audison Voce II AV 10 D4 II 10" (25cm) Subwoofer

550 Watt

Audison Voce II AV 10 D4 II 10" (25cm) Subwoofer

Technical Highlights

  • Leistung 550 W RMS, Impedanz 4+4 Ohm, Frequenz 25-400 Hz.
  • Empfindlichkeit 83,5 dB, Schwingspule 38,6 mm auf Glasfaser.
  • Resonanzfrequenz 36 Hz, Antriebsfaktor 11,2 Tm, Xmax 16,8 mm.
  • More technical details
€499,00
€499,00 €499,00
5% discount with prepayment
inkl. VAT , possibly plus shipping
Delivery
Mar 23, - Mar 26,
x Stück
  • American Express
  • Apple Pay
  • Bancontact
  • BLIK
  • EPS
  • Google Pay
  • iDEAL Wero
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Twint
  • Union Pay
  • Visa
Klarna Pay conveniently in 12 interest-free installments at €41,58 with Klarna .

Your benefits at Masori

Seen cheaper elsewhere?

Shipping cost calculator

Expert Image

Rob

Expert Image

Max

Unsure if this product fits your car?

We help you – quickly, personally, and without obligation.

Response on weekdays within 24 hours
Audison-Voce II AV 10 D4 II-10" (25cm) Subwoofer-masori-kaufen
€499,00
€499,00 €499,00

Voce II AV 10 D4 II by Audison

The Voce II AV 10 D4 II from Audison is a 10" Subwoofer that features a dual 4-ohm voice coil. With a power handling of 550 W RMS and a peak value of 1100 W, this Subwoofer delivers impressive sound, complemented by a wide frequency response of 25 to 400 Hz. The sensitivity is 83.5 dB, ensuring powerful bass reproduction. The Subwoofer features a 38.6 mm CCAW voice coil on a fiberglass carrier, as well as a magnetic system made of highly compressed ferrite. A mix of aluminum basket, polypropylene diaphragm, and nitrile rubber surround ensures durability and performance.

Technical specifications

  • 10" (25cm) Subwoofer
  • Impedance: 4+4 Ohm dual voice coil.
  • Power handling: 550 W RMS (1100 W Peak).
  • Sensitivity: 83.5 dB sound pressure level.
  • Frequency response: Wide range from 25 to 400 Hz.
  • Voice coil: 38.6 mm diameter CCAW on fiberglass carrier.
  • Magnet material: Highly compressed ferrite (134 x 55 x 36 mm).
  • Material mix: Aluminum basket, polypropylene diaphragm, and nitrile rubber surround.

Electroacoustic parameters

  • Resonance frequency (Fs): 36 Hz for deep bass reproduction.
  • Equivalent volume (Vas): 14.8 liters.
  • Maximum excursion (Xmax): 16.8 mm (Xmech 20 mm).
  • Moving mass (Mms): 250 g for controlled displacement.
  • Total quality (Qts): 0.72 (Qes 0.823 / Qms 5.62).
  • DC resistance (Re): 1.82 Ohm.
  • Drive factor (BL): 11.2 T•m.

Dimensions & Installation

  • Outer diameter (A): 274.5 mm.
  • Installation diameter (B): 232 mm.
  • Installation depth (C): 102.5 mm.
  • Total depth (C2): 128.5 mm.
  • Hole circle diameter (E): 245 mm.
  • Effective diaphragm area (D): 368 cm²

Your benefits at Masori

Frequently Asked Questions about Voce II AV 10 D4 II

What is the frequency response of the Audison Voce II AV 10 D4 II Subwoofer?

The Audison Voce II AV 10 D4 II offers a wide frequency response from 25 to 400 Hz, allowing it to reproduce deep bass tones with high precision. This frequency range is ideal for music styles that benefit from rich bass, such as electronic music or hip-hop. When combined with an Amplifier, the Subwoofer can unleash its full power, enhancing the sound volume in a vehicle. Especially at low frequencies, the quality of the Subwoofer is crucial, and the broad coverage of the frequency range highlights its versatility across different music genres.

What impedance does the Voce II AV 10 D4 II Subwoofer have?

The Voce II AV 10 D4 II Subwoofer from Audison is equipped with a dual voice coil that has an impedance of 4+4 ohms. This configuration allows for flexible adaptation to various amplifier systems, for example, using a parallel connection to reduce the total impedance to 2 ohms or a series connection to increase it to 8 ohms. This versatility is particularly advantageous when you want to add a customized performance to your audio systems. The dual voice coil not only provides flexibility but also improved control over the voice coil under high power demands.

What is the power handling of the Audison Voce II AV 10 D4 II?

The power handling of the Audison Voce II AV 10 D4 II Subwoofer is specified at 550 watts RMS and a maximum of 1100 watts peak. This capability ensures that the Subwoofer delivers clear and distortion-free bass even at high volumes. The high power handling makes it ideal for sound systems that need to manage a high level of energy without sacrificing performance. At the same time, this extends the lifespan of the Subwoofer, as it is designed to withstand the stresses of intense music playback without suffering thermal or mechanical damage.

What materials are used in the construction of the Voce II AV 10 D4 II?

The Audison Voce II AV 10 D4 II Subwoofer is made from a combination of high-quality materials that make it robust and powerful. The basket is made of aluminum, which provides stability and minimizes vibrations. The diaphragm is made of polypropylene, ensuring precise and controlled bass reproduction. The surround made of nitrile rubber contributes to the flexibility and durability of the subwoofer. Additionally, a voice coil with a diameter of 38.6 mm is used, made of CCAW (Copper-Clad Aluminum Wire) on a fiberglass former, to ensure high temperature and power resistance.

What are the dimensions of the Audison Voce II AV 10 D4 II?

The dimensions of the Audison Voce II AV 10 D4 II are carefully designed to ensure easy integration into various vehicle configurations. The outer diameter is 274.5 mm, the cutout diameter is 232 mm. The mounting depth of 102.5 mm ensures that the subwoofer can be accommodated even in space-restricted environments, while the overall depth of 128.5 mm allows room for the voice coil movement. The bolt circle diameter of 245 mm enables a stable attachment. These dimensions are crucial for integrating the subwoofer cleanly without compromising audio quality.

What electroacoustic properties does the Voce II AV 10 D4 II have?

The Audison Voce II AV 10 D4 II impresses with its electroacoustic parameters, which are carefully tuned to enable clear and deep bass reproduction. The resonance frequency (Fs) is 36 Hz, providing a deep bass experience. The equivalent volume (Vas) is 14.8 liters and supports bass flexibility. The maximum excursion (Xmax) of 16.8 mm allows for impressive displacement for powerful bass. A total quality factor (Qts) of 0.72 ensures a balanced sound image, while the drive factor (BL) of 11.2 T•m improves the efficiency of the drive.

How loud is the Audison Voce II AV 10 D4 II Subwoofer?

With a sensitivity of 83.5 dB, the Audison Voce II AV 10 D4 II Subwoofer is capable of producing a respectable volume even with limited amplifier power. This sensitivity is crucial as it determines how efficiently the subwoofer converts electrical power into acoustic power. For everyday use, moderate amplifier power can be utilized to generate powerful bass impulses. If you want to achieve a higher sound pressure level, a powerful amplifier is recommended to fully exploit the sub's capacity and experience the bass effect in the vehicle intensely.

What voice coil materials does the Voce II AV 10 D4 II use?

The Audison Voce II AV 10 D4 II Subwoofer uses a voice coil with a diameter of 38.6 mm, made of CCAW (Copper Clad Aluminium Wire) on a fiberglass carrier. This material combination offers several advantages: CCAW combines the low density of aluminum with the high conductivity of copper, resulting in a lightweight yet efficient voice coil. The fiberglass carrier also provides excellent thermal stability, which is beneficial during operation under high loads. These properties ensure improved performance and durability of the subwoofer.

What is the moving mass of the Audison Voce II AV 10 D4 II Subwoofer?

The moving mass (Mms) of the Voce II AV 10 D4 II Subwoofer is set at 250 grams. This mass is crucial for controlling the displacement and precision in bass reproduction. A subwoofer with an optimally weighted diaphragm can reproduce low frequencies with high efficiency and without distortion. Control over the moving mass allows the subwoofer to appear precise and dynamic even at high volume levels, enhancing the musical enjoyment.

What factors influence the bass output of the Voce II AV 10 D4 II?

The bass output of the Voce II AV 10 D4 II is influenced by several factors. The resonance frequency (Fs) of 36 Hz determines how low the subwoofer can play, while the total quality factor (Qts) of 0.72 affects the balance between electrical and mechanical damping. The drive factor (BL) of 11.2 T•m plays a key role in the efficiency of the transducer by describing the strength of the magnetic field. Additionally, the voice coil is layered on a fiberglass carrier, which improves thermal resistance. Together, these properties ensure powerful bass output characterized by clarity and dynamic depth.
