Audison Voce II AV 10 D2 II 10" (25cm) Subwoofer

550 Watt

Audison Voce II AV 10 D2 II 10" (25cm) Subwoofer

Technical Highlights

  • Leistung: 550 W RMS (1100 W Peak), Impedanz: 2+2 Ohm, dB: 83,5.
  • Hub: max. 16,8 mm, Frequenz: 25 bis 400 Hz, Vas: 15,16 Liter.
  • Doppelschwingspule: 38,6 mm, Re: 3,25 Ohm, BL: 16,2 Tm.
  • More technical details
€499,00
€499,00 €499,00
5% discount with prepayment
inkl. VAT , possibly plus shipping
Delivery
Mar 23, - Mar 26,
x Stück
  • American Express
  • Apple Pay
  • Bancontact
  • BLIK
  • EPS
  • Google Pay
  • iDEAL Wero
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Twint
  • Union Pay
  • Visa
Klarna Pay conveniently in 12 interest-free installments at €41,58 with Klarna .

Your benefits at Masori

Seen cheaper elsewhere?

Shipping cost calculator

Expert Image

Rob

Expert Image

Max

Unsure if this product fits your car?

We help you – quickly, personally, and without obligation.

Response on weekdays within 24 hours
Audison-Voce II AV 10 D2 II-10" (25cm) Subwoofer-masori-kaufen
€499,00
€499,00 €499,00

Voce II AV 10 D2 II by Audison

The Voce II AV 10 D2 II from Audison is a 10-inch Subwoofer designed for powerful sound. It offers a nominal impedance of 2+2 Ohm with a dual voice coil that allows for a serial connection. With a power handling of 550 W RMS and a sound pressure level of 83.5 dB, it delivers convincing bass from 25 Hz to 400 Hz. The Subwoofer is made from high-quality materials such as an aluminum basket, a polypropylene diaphragm, and a nitrile rubber surround. It weighs 5 kg and is ideally suited for a recommended enclosure volume of 13.2 liters.

Technical specifications

  • Nominal diameter: 250 mm (10 inches) high-performance Subwoofer.
  • Impedance: 2+2 Ohm dual voice coil (serial connection possible).
  • Power handling: 550 W RMS (1100 W Peak).
  • Sensitivity: 83.5 dB sound pressure level.
  • Frequency response: 25 Hz to 400 Hz.
  • Voice coil: 38.6 mm diameter made of CCAW on fiberglass carrier.
  • Magnet material: Highly compressed ferrite (134 x 57 x 36 mm).
  • Material mix: Aluminum basket, polypropylene diaphragm, and nitrile rubber surround.
  • Weight: 5 kg total weight.

Electroacoustic parameters

  • Resonance frequency (Fs): 35 Hz for deep bass performance.
  • Equivalent volume (Vas): 15.16 liters.
  • Maximum excursion (Xmax): 16.8 mm (Xmech 20 mm).
  • Moving mass (Mms): 264 g.
  • Total quality (Qts): 0.63 (Qes 0.7 / Qms 5.5).
  • DC resistance (Re): 3.25 Ohm (in series).
  • Drive factor (BL): 16.2 T•m.

Enclosure recommendation & installation

  • Recommended enclosure volume: 13.2 liters.
  • Recommended tuning frequency: 51 Hz.
  • Outer diameter (A): 274.5 mm.
  • Installation diameter (B): 232 mm.
  • Installation depth (C): 97 mm.
  • Total depth (C2): 128.5 mm.
  • Hole circle diameter (E): 245 mm.
  • Effective diaphragm area (D): 368 cm²

Your benefits at Masori

Frequently Asked Questions about Voce II AV 10 D2 II

What are the main features of the Voce II AV 10 D2 II?

The Voce II AV 10 D2 II from Audison is a 250 mm (10 inch) high-performance Subwoofer with a dual voice coil of 2+2 Ohm, allowing for a series connection. With a power handling of 550 W RMS and a maximum sound pressure level of 83.5 dB, it delivers effective performance. It covers a frequency range from 25 Hz to 400 Hz and is equipped with a CCAW fiberglass former that has a voice coil diameter of 38.6 mm. The basket material is aluminum, the diaphragm is made of polypropylene, and the surround is made of nitrile rubber. The unit weighs a total of 5 kg.

What are the electroacoustic parameters of the Voce II AV 10 D2 II?

The Voce II AV 10 D2 II has a resonance frequency of 35 Hz, contributing to outstanding bass performance. The equivalent volume (Vas) is 15.16 liters, and the maximum excursion (Xmax) is 16.8 mm, with Xmech at 20 mm. The moving mass (Mms) is 264 g, while the total quality factor (Qts) is 0.63, with a Qes of 0.7 and a Qms of 5.5. The direct current resistance (Re) is 3.25 Ohm in series, and the drive factor (BL) is 16.2 T•m, ensuring powerful bass reproduction.

What enclosure recommendations are there for the Voce II AV 10 D2 II?

For the Voce II AV 10 D2 II, an enclosure volume of 13.2 liters is recommended, with a tuning frequency of 51 Hz. The enclosure installation should consider the specific dimensions, with an outer diameter of 274.5 mm and a cutout diameter of 232 mm. The mounting depth is 97 mm and the total depth is 128.5 mm. The bolt circle diameter is 245 mm and the effective diaphragm area is 368 cm². These specifications ensure optimal performance of the Subwoofer in the desired frequency range.

How is the impedance of the Voce II AV 10 D2 II configured?

The Voce II AV 10 D2 II Subwoofer is configured with a 2+2 Ohm dual voice coil, allowing for the possibility of a series connection. This configuration enables the impedance to be varied depending on the connection type, optimizing the performance requirements of the respective Amplifier. The flexible connections ensure that the woofer can be connected to various amplifier systems, enhancing adaptability to different audio setups in your vehicle.

What material is used in the Voce II AV 10 D2 II?

The Voce II AV 10 D2 II uses various high-quality materials for its construction. The basket is made of aluminum, combining lightness with stability. The diaphragm is made of polypropylene, which is valued for its durability and acoustic properties. Additionally, a nitrile rubber surround is used, ensuring longevity and flexibility. This combination of materials allows for powerful and durable bass reproduction, perfectly tuned to the demands of a high-performance car audio system.

How do you install the Voce II AV 10 D2 II in the car?

To install the Voce II AV 10 D2 II, you need to note that the outer diameter is 274.5 mm and the cutout diameter is 232 mm. A mounting depth of 97 mm should be considered, while the total depth is 128.5 mm. The bolt circle diameter is 245 mm, which is important when planning the installation in your vehicle. An effective diaphragm area of 368 cm² ensures powerful bass sounds. Careful measurement and vehicle adaptation are necessary to fully utilize the capabilities of this Subwoofer.

What frequency ranges does the Voce II AV 10 D2 II cover?

The Voce II AV 10 D2 II covers a frequency range of 25 Hz to 400 Hz, making it ideal for deep bass applications. The low resonance frequency of 35 Hz particularly supports the lower frequency ranges, while the tuning frequency is 51 Hz with a recommended enclosure. These specifications allow the Subwoofer to accurately reproduce both hard hits and deep, resonant bass lines, making it well-suited for the demanding playback of music genres with deep bass.

How does the sensitivity of the Voce II AV 10 D2 II affect performance?

The sensitivity of the Voce II AV 10 D2 II is 83.5 dB. Such sensitivity means that the Subwoofer can achieve a premium sound pressure level with relatively low power input. While more powerful Amplifiers may be required to fully utilize the dynamic range of this Subwoofer, the high sensitivity ensures that impressive sound and clear bass are produced even at moderate power. This feature makes it particularly effective for audio setups that demand high sound fidelity without excessive energy input.

What is the power handling of the Voce II AV 10 D2 II?

The Voce II AV 10 D2 II has an RMS power handling of 550 watts and a peak power handling of 1100 watts. This allows the Subwoofer to handle high power demands and perform with clear bass even at maximum volume. Power handling is a crucial factor when it comes to the lifespan and thermal resilience of the Subwoofer. These specifications are therefore essential for durable and stable sound reproduction in any type of application, whether in everyday use or during intense audio sessions.

Which vehicle models is the Voce II AV 10 D2 II compatible with?

Without considering specific car brands in the product information, the compatibility of the Voce II AV 10 D2 II can mainly be assessed based on its dimensions. The outer diameter is 274.5 mm and the mounting depth is 97 mm. These measurements are critical to determine whether the Subwoofer can be installed in your vehicle. By checking the dimensions of the available space in your car, you can ensure that this powerful Subwoofer integrates well into your audio setup.
