Vehicle Search

  3. Rebec Speakers, Subwoofers & More for Cars
  5. WL10
Rebec WL10 10" (25cm) Subwoofer
SKU:  WL10
350 Watt

WL10

SKU:  WL10

Technical Highlights

  • 10" subwoofer, RMS 350W, max. 700W, frequency 22-1400 Hz.
  • Impedance 2x4 Ω, sensitivity 86.9 dB, installation depth 134 mm.
  • Easy installation, flexible installation hole 273 mm.
  • More technical details
00 d
00 h
00 m
00 s
€477,36
-18% €579,00 €477,36
5% discount with prepayment
inkl. VAT , possibly plus shipping
Delivery
May 23, - May 28,
x Piece
  • American Express
  • Apple Pay
  • Bancontact
  • BLIK
  • EPS
  • Google Pay
  • iDEAL Wero
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Shop Pay
  • Twint
  • Union Pay
  • Visa
Klarna Pay conveniently in 12 interest-free installments at €39,78 with Klarna .

Your benefits at Masori

Seen cheaper elsewhere?

Shipping cost calculator

Expert Image

Rob

Expert Image

Max

Unsure if this product fits your car?

We help you – quickly, personally, and without obligation.

Response on weekdays within 24 hours
RebecRX3
Rebec-RX3-3" (8cm) Koaxial-Lautsprecher-masori-kaufen
Rebec-BMW 120C-BMW-Lautsprecherset-masori-kaufen
RebecBMW 120C
Rebec-WL10-10" (25cm) Subwoofer-masori-kaufen
€477,36
€579,00 €477,36

WL10 by Rebec

Rebec WL10 as a 10-inch (25 cm) Subwoofer with 350 Watts RMS and 700 Watts MAX. Frequency range 22–1400 Hz. Impedance 2x4 Ω. Sensitivity 86.9 dB. Installation depth 134 mm. Cutout diameter 273 mm. Resonance frequency Fs 48 Hz. Qts 0.35. Vas 10.662 L. 10-inch mounting plate.

Features
  • 10-inch Subwoofer
  • Rated power 350 Watts RMS
  • Power handling 700 Watts MAX
  • Frequency range 22–1400 Hz
  • Impedance 2x4 Ω
  • Sensitivity 86.9 dB
  • Installation depth 134 mm
  • Cutout diameter 273 mm
  • 10-inch mounting plate
Technical Specifications
  • Resonance frequency Fs 48 Hz
  • Qts 0.35
  • Vas 10.662 L
  • Mounting plate 254 mm

Your benefits at Masori

Frequently Asked Questions about WL10

What is the rated power of the Rebec WL10 Subwoofer?

The WL10 from Rebec has a rated power of 350 Watts RMS. This means it can continuously handle 350 Watts without distortion. These power specifications make the Subwoofer ideal for applications where reliable, long-lasting bass reproduction is required. If you often listen to loud music, you ensure that your Subwoofer can deliver consistently high performance without compromising sound quality. The WL10 was specifically designed for this purpose, to provide deep and powerful sound, regardless of your listening habits.

What frequency range does the Rebec WL10 cover?

The frequency range of the Rebec WL10 spans from 22 Hz to 1400 Hz. This means that this Subwoofer is capable of producing extremely deep bass that provides a powerful sound experience, as well as handling higher frequencies that are typically covered by woofers. While 22 Hz is considered a particularly deep bass range, the upper limit of 1400 Hz allows for versatile applications across various music genres. These technical parameters offer fans of deep sounds the flexibility to integrate the WL10 into different audio setups.

What is the impedance of the Rebec WL10 Subwoofer?

The Rebec WL10 consists of a dual voice coil, each with an impedance of 4 Ohms, so the total impedance is 2x4 Ohms. This dual impedance offers flexibility in wiring and makes the WL10 adaptable for various audio amplifier systems. The choice between parallel or series-connected voice coils allows for achieving the optimal resistance for the amplifier. This variability ensures that the Subwoofer can unleash maximum performance, making it ideal for technical audio enthusiasts who appreciate flexible usability.

How sensitive is the WL10 Subwoofer?

The sensitivity of the Rebec WL10 Subwoofer is specified at 86.9 dB. This sensitivity describes the efficiency with which the subwoofer is converted into sound energy, directly influencing the volume that the device can produce at a given amplifier power level. If you enjoy powerful, clear bass, a higher sensitivity ensures that the subwoofer plays louder at comparable amplifier power. The WL10 is designed to produce impressively deep frequencies even with low amplification, making it ideal for audiophile applications.

What installation depth should be considered for the WL10?

The intended installation depth of the WL10 Subwoofer is 134 mm. This installation depth allows the subwoofer to be integrated into a variety of enclosures, which is particularly advantageous when space is a critical factor. With such a depth, there is flexible installation potential within vehicles or home audio setups, depending on individual requirements. Before installation, the installation depth should be carefully measured to ensure optimal placement for the subwoofer without interfering with or damaging the components of other systems.

What are the Thiele Small parameters of the WL10?

The Thiele Small parameters of the Rebec WL10 include an FS value (resonance frequency) of 48 Hz, a QTS value (total quality) of 0.35, and a VAS (equivalent volume) of 10.662 liters. These parameters are critical in the design and tuning of speaker enclosures, as they significantly influence the acoustic characteristics of the subwoofer. An FS value of 48 Hz indicates that the subwoofer naturally favors low frequencies. The QTS value of 0.35 suggests that the subwoofer performs optimally in medium-sized enclosures, while the VAS provides an equivalent volume for enclosure planning.

What are the dimensions of the installation hole diameter of the WL10?

The installation hole diameter of the Rebec WL10 Subwoofer is 273 mm. This dimension specification ensures that the subwoofer can be correctly integrated into the designated opening. A precisely fitting installation hole is essential to avoid sound leaks and ensure optimal bass reflection. Before installation, the hole should be carefully measured to ensure that the subwoofer fits flush and is securely mounted. These exact dimensions are important to meet expectations for sound level and to provide fast, powerful bass.

What is the maximum load capacity of the WL10 Subwoofer?

The maximum load capacity of the Rebec WL10 Subwoofer is a robust 700 watts. This figure describes the Subwoofer's ability to handle high power impulses for short periods without damage. Music with fast, intense bass hits like EDM or Hip-Hop greatly benefits from a Subwoofer's ability to manage power impulses. However, to achieve maximum benefit, care should be taken not to exceed the power limit continuously, as this can lead to overheating. The maximum load capacity also supports resilience against electrical power spikes.

How do I install the WL10 in a car?

Installing the Rebec WL10 requires consideration of the installation depth of 134 mm and the cutout diameter of 273 mm. When placing it in the car, ensure that the intended space accommodates these dimensions. Start by selecting a suitable installation location in your vehicle that offers enough depth and does not interfere with other systems. It is important that any mounting pole or bracket securely holds the Subwoofer to avoid unwanted noise and vibrations. Therefore, installation in enclosures that are tailored to these dimensions is recommended.

Is the WL10 Subwoofer compatible with my audio system?

The compatibility of the WL10 depends on the power parameters of your audio system, particularly the Amplifier's ability to operate with an impedance of 2x4 ohms. Its dual voice coils allow flexibility in wiring, which is advantageous for many common Amplifiers. Whether your system can fully utilize FS, QTS, or VAS values depends on the individual setups. If both the audio system and the Amplifier are optimized for the WL10, frequency range and sensitivity can be maximized to achieve high-quality, deep bass sound.
