Hertz Cento CX 690 6"x9" speaker set

Name: Hertz Cento CX 690 6x9 inch speaker set | Masori
Brand: Hertz
Price: 118.15 EUR
Availability: InStock

CYBER -15%

Max, Mikael and 53k+ customers already with Masori sound upgrade

Hertz Cento CX 690 6"x9" speaker set

Power handling RMS 100W, impedance 4 Ohm, frequency response 40-23kHz.
Tweeter cone 40mm, woofer cone 6"x9", weight 1.55kg.
SPL 93.5 dB, high efficiency, magnet neodymium and flux ferrite.
Mehr technische Details

00

€118,15

~~€139,00~~ €118,15

5% Rabatt mit Vorkasse

inkl. VAT , possibly plus shipping

Bequem in 12 zinsfreien Raten à €9,84 mit Klarna zahlen.

Jetzt mit kostenlosem Versand ab 50€!

Shipping cost calculator

Land/Region

PLZ

Garantie & zusätzlicher Geräteschutz für dein HiFi-System

3 Jahre Masori Garantie Kostenlos 48 Monate Plusgarantie €14,99 60 Monate Plusgarantie Am beliebtesten €19,99

Deshalb wählen uns 100.000+ Kunden

3 Jahre Garantie

Sicher & sorglos
Blitzversand

mit DHL Express
Tiefpreisschutz

Nie zu viel zahlen

Rob

Max

Unsicher, ob dieses Produkt zu deinem Auto passt?

Wir helfen dir – schnell, persönlich und unverbindlich.

Antwort on weekdays within 24h

HertzCento CP 1.700

HertzSPL Show SV 200 Neo

Cento CX 690 by Hertz

Discover the Cento CX 690 from Hertz, an oval 3-way coaxial speaker distinguished by its impressive performance. Designed for horizontal installation, it guarantees a balanced tonal response and high efficiency, even under the most demanding conditions. Featuring a 6x9 inch mid-bass cone, this speaker delivers maximum performance. Its technical features, including efficient reproduction of high and mid frequencies, optimization through FEM simulations, and a highly durable ABS plastic speaker grille, make it a top choice for any audio setup. Experience sound in a new quality with the Cento CX 690.

Technical Data

Size 6 x 9
Power Handling - RMS W 100
Power Handling - Peak W 300
Impedance Ohm 4
Tweeter Diaphragm mm 40
Woofer Voice Coil Ø mm 30
Tweeter Voice Coil Ø mm 28
Frequency Response Hz 40 - 23k
Woofer Magnet Size W x D x H mm 100 x 32 x 15
Tweeter Magnet Size W x H mm 19 x 3
Weight per Speaker kg 1.55
Woofer Magnet High-Density Ferrite
Tweeter Magnet Neodymium
Diaphragm Semi-Pressed Paper + Mica
Xmech mm 5.5

Electro-Acoustic Specifications

D mm 139
Re Ohm 3.3
Fs Hz 70
Le mH 0.2
Vas l 11.1
Mms g 13
Cms mm/N 0.34
BL T*m 4.9
Qts 0.67
Qes 0.83
Qms 3.3
Spl dB 93.5

Physical Specifications

Cento CX 690

A 238 mm
B 224 mm
C 95 mm
D 78.5 mm
Und 268 mm
F 29 mm

Frequency Response

Cento CX 690

FEATURES

6" x 9" oval, single-pressed SPP-M diaphragm (Pressed Paper-Mica) enhanced with mica powder for an excellent balance between weight and damping.
Wide rubber surround designed for high excursion and excellent damping.
High-density ferrite magnet combined with low-carbon pole plates for reduced distortion.
Basket with a metallic finish acoustically paired with a rubber magnet cover to suppress all types of vibrations.
40mm tweeter for efficient and distortion-free reproduction of high and mid frequencies.
20mm super tweeter to maximize the level of very high frequencies in horizontal installation position.
The design and geometry of the tweeter faceplate have been optimized with FEM (Finite Element Modeling) simulations for a linear frequency response, even in off-axis installations.
Elegant, highly durable ABS plastic speaker grille with metallic finish and a metal mesh.

Hertz Cento CX 690 Datenblatt

Datenblatt öffnen

Frequent questions about Cento CX 690

Wie beeinflusst die Membran des Cento CX 690 die Soundqualität?

The membrane of the Cento CX 690 is made of semi-pressed paper, combined with mica powder, which provides an excellent balance between weight and damping. This construction ensures precise and detailed audio with low distortion. The oval 6" x 9" design allows for optimal bass reproduction and high volume levels. The mechanical damping is further enhanced by the wide rubber surround, designed for high excursion and excellent damping. As a result, the sound remains clear and distortion-free even at high volume, which is particularly noteworthy for music lovers.

Welche Leistung bietet der Cento CX 690 Lautsprecher?

The Hertz Cento CX 690 is a powerful 3-way coaxial speaker with an RMS power handling of 100 watts and a peak power handling of 300 watts. It is designed for high loads, allowing for powerful and dynamic music playback. The speaker has an efficiency of 93.5 dB, which means it can achieve significant sound pressure even at lower amplifier power levels. With an impedance of 4 ohms, it is compatible with most car audio amplifiers, making it versatile for use in various audio systems. The high performance ensures an exceptional listening experience.

Welche Techniken verbessern die Hochfrequenzwiedergabe im Cento CX 690?

The Cento CX 690 uses a 40 mm tweeter to achieve efficient and distortion-free high and mid-frequency reproduction. This is complemented by a 20 mm super tweeter, specifically designed to maximize the level of very high frequencies, even in a horizontal installation position. The geometry of the tweeter faceplate has been optimized using FEM simulations (Finite Element Modeling). This technique ensures a linear frequency response and minimizes distortion, which is particularly advantageous in off-axis installations, as the sound remains balanced and the highs crystal clear.

Wie tragen die Magnetmaterialien des Cento CX 690 zur Klangqualität bei?

The Cento CX 690 from Hertz uses high-density ferrite magnets in the woofer, optimized to work with low-carbon pole plates to minimize distortion. The tweeter relies on neodymium magnets, known for their high energy efficiency, enabling precise high-frequency reproduction. This combination of magnetic materials supports excellent acoustic performance, resulting in detailed and powerful audio playback. The high density of the woofer magnets significantly contributes to bass reproduction by allowing strong, resonance-free vibrations.

Welche Frequenzbereiche deckt der Cento CX 690 ab?

The Cento CX 690 has a wide frequency range of 40 Hz to 23 kHz, which means it can reproduce deep bass as well as very high frequencies. This bandwidth ensures that both the lowest bass notes and the finest high tones are detailed and clear. Particularly noteworthy is the speaker's ability to reproduce deep bass extremely powerfully despite its size, while the super tweeter finely resolves the highs. This allows for comprehensive coverage of all frequency ranges important for music and ensures a thoroughly satisfying listening experience.

Welche Installationshinweise gibt es für den Cento CX 690?

The Cento CX 690 is designed for horizontal installation and offers a variety of installation options with its dimensions of 238 mm in width, 224 mm in depth, and 95 mm in height. The speaker can be installed in many vehicles, taking into account the installation depth of 78.5 mm. The metal and ABS plastic basket construction with a metallic finish ensures a vibration-free installation. This versatile design significantly simplifies integration into existing car audio systems, as it provides stable mounting points and a harmonious aesthetic.

Wie wirkt sich die Schwingspule des Cento CX 690 auf den Klang aus?

The Cento CX 690 features a midrange and bass driver voice coil with a diameter of 30 mm, allowing for excellent control over the bass driver. This design helps ensure that even at higher volumes, the bass remains powerful and precise. The tweeter uses a voice coil with a diameter of 28 mm for maximum distortion-free high-frequency reproduction. These voice coils enable quick and accurate movement of the membranes, ensuring a smooth and dynamic sound reproduction that supports even the most demanding listening enjoyment.

Was sind die Vorteile des Lautsprechergitters im Cento CX 690?

The speaker grille of the Cento CX 690 is made of highly durable ABS plastic and features a metallic finish. This combination of materials provides effective protection for the speaker components against physical damage and external influences, while the metal grille does not impair sound radiation. Additionally, the grille offers an elegant appearance that contributes to the high-quality look of the speaker. This construction ensures that the acoustic quality is maintained and that the visual and mechanical requirements of a modern sound setup are met.

Warum ist der Hertz Cento CX 690 für hohe Lautstärken geeignet?

The Hertz Cento CX 690 is designed for high volumes, as it has a high load capacity of up to 300 watts peak power. The use of robust materials such as the combination of ferrite and neodymium magnets, as well as the large voice coil, strengthens the structure and enables powerful performance without distortion. The oval diaphragm shape and the wide rubber surround further support dynamic playback. These technical features ensure that the speaker delivers clear and powerful sound even at high levels, ideal for car enthusiasts who enjoy listening to music loudly.

Welche speziellen Optimierungen hat der Cento CX 690 erfahren?

The Cento CX 690 has been optimized through FEM simulations (Finite Element Modeling), particularly the geometry of the tweeter faceplate, to ensure a linear frequency response. This technology allows for targeted improvement of acoustic performance, especially in off-axis installations. The optimization ensures consistent and precise frequency reproduction, even at different installation angles. Additionally, the diaphragm has been reinforced with mica powder to achieve an optimal balance between weight and damping, significantly enhancing sound quality and reducing distortion.
