12-cell LTO Extreme battery pack 90Ah
Technical Highlights
- 5000-8000W RMS, 90Ah, 14.4-15V, 12x 45Ah, >16000 cycles, 2.4V.
- Peak 1125A, Max discharge 10C (450A), 1C 45A.
- 90Ah, recommended 14.4-15V, -55°C to 65°C, 60x160mm.
- More technical details
Availability for pickups could not be loaded.
Shipping cost calculator
Shipping cost calculator
Rob
Max
Unsure if this product fits your car?
We help you – quickly, personally, and without obligation.
Fill out the form and we'll send you a personalised offer
This product is not universally compatible. Send us your vehicle details and we will check fitment for your model free of charge.
12-cell LTO Extreme battery pack 90Ah by GS Audio
The 12-cell LTO Extreme battery pack 90Ah from GS Audio is an energy storage system of the type Lithium - LTO. It consists of 12 Extreme individual cells, each with 45Ah, achieving a total capacity of 90Ah. The recommended operating voltage of the pack is between 14.4 V and 15 V. This system is designed for power ranges from 5000 W to 8000 W RMS. The cells used are based on Lithium-Titanium Oxide technology and have a lifespan of over 16,000 cycles. The allowable temperature range for operation extends from -55 degrees Celsius to 65 degrees Celsius.
- Product Type: Lithium - LTO
- Manufacturer: GS Audio
- Number of Cells: 12 Extreme Cells
- Technology: Lithium-Titanium Oxide
- Capacity: 90Ah
- Recommended Voltage: 14.4 V to 15 V
- Power: 5000 W to 8000 W RMS
- Lifespan: over 16,000 cycles
- Operating Range per Cell: 2.0 V to 2.5 V
- Nominal Voltage per Cell: 2.4 V
- Capacity per Cell: 45Ah
- Dimensions per Cell: 60 mm x 160 mm
- Weight per Cell: approx. 1 kg
- Nominal Discharge Rate: 1C (45 A)
- Maximum Discharge Rate: 10C (450 A)
- Peak Discharge Rate at 25 degrees Celsius: 1125 A
- Temperature Range: -55 degrees Celsius to 65 degrees Celsius
