LC-1,800

Prepare yourself for high-end audio enjoyment with the LC-1.800 1-channel amplifier from Audiocontrol. This clearly sets itself apart from the standard by offering you the industry's largest input voltage range, thanks to a mix of high and low-level inputs. Its power hits a remarkable 800 watts at 2 ohms and promises not only to meet your expectations but to exceed them. The patented ACCUBASS® feature helps you overcome heavily equalized factory settings and factory bass roll-offs. With the LC-1.800, you get not only volume but also sound quality that is second to none.

Features

• Subwoofer amplifier with patented AccuBASS®
• 800 Watts at 2 Ohms
• 500 Watts at 4 Ohms
• AccuBASS® processing
• MILC™ Maximum Input Level Control (patent pending)
• GTO™ Signal Sense
• 24 dB/octave Linkwitz-Riley crossover frequency filter
• Speaker level and preamplifier inputs
• Optional ACR-1 assignable remote control
• Solid one-piece aluminum housing

SPECIFICATIONS
ENTRANCES

• Preamp inputs: 2 balanced
• Input voltage range: 500 mV - 6 Vrms
• Speaker level inputs: 2
• Speaker level input voltage range: 3 V - 40 Vrms
• EXITS
• Continuous (RMS) rated power at 14.4 V:
• 4 Ω - 500 W RMS
• 2 Ω - 800 W RMS

performance capability

• Frequency response: 10 Hz - 30 kHz
• Noise level: 102 dBa, Ref 500 W @ 4 Ohm
• Damping factor: 670 at 10 V, 4 Ohm output, 100 Hz
• THD+N: < 0.01%
• Minimum strength of the network/grounding cable: 20mm²
• Protection value: 2 x 40 A
• Crossover: 24 dB/octave Linkwitz-Riley, adjustable from 30 Hz - 230 Hz
• PFM Subsonic Filter: 24 Hz

WEIGHT & DIMENSIONS

• Dimensions: 32.5 x 20 x 5.3cm
• Weight: 2.0kg
