Masori 30A-175A Mini-ANL Fuse

Name: Masori 30A-175A Mini-ANL Fuse | Masori
Brand: Masori
Price: 9.0 EUR
Availability: InStock
Rating: 5.0 (5 reviews)

MasoriLR300 MPX

Deaf BonceAP-M81AC-RC

30A-175A Mini-ANL by Masori

Discover the "30A-175A Mini-ANL" fuse from Masori, which is characterized by its gold-plated surface and the selection of different fuse ratings. These Mini-ANL fuses have been specifically designed for use with amplifiers and are suitable for cable cross-sections from 4mm² to 50mm². With one delivery, you will receive five of these high-quality Mini-ANL fuses. This way, you can determine the exact right level of safety and performance for your installation and experience Masori quality and versatility at a high level.

features

Gold-plated Mini ANL fuses
Available collateral values

30A (suitable for 4mm² cable and approx. 400W amplifier power)
40A (suitable for 6mm² cable and approx. 500W amplifier power)
50A (suitable for 8mm² cable and approx. 700W amplifier power)
60A (suitable for 10mm² cable and approx. 800W amplifier power)
80A (suitable for 16mm² cable and approx. 1300W amplifier power)
100A (suitable for 25mm² cable and approx. 1400W amplifier power)
125A (suitable for 32mm² cable and approx. 1800W amplifier power)
150A (suitable for 35mm² cable and approx. 2200W amplifier power)
175A (suitable for 50mm² cable and approx. 2500W amplifier power)

Scope of delivery

5x Mini-ANL Fuse

Recommended Security Values

cable cross-section	optimal collateral value	maximal collateral value
1.5 mm²	10 A	15 A
2.5 mm²	20 A	25 A
4.0 mm²	25 A	30 A
6.0 mm²	35 A	40 A
10 mm²	50 A	60 A
16 mm²	70 A	80 A
20 mm²	90 A	100 A
25 mm²	100 A	125 A
35 mm²	125 A	150 A
50 mm²	160 A	200 A
70 mm²	200 A	250 A
95 mm²	250 A	300 A

Frequent questions about 30A-175A Mini-ANL

Was sind die technischen Merkmale der 30A-175A Mini-ANL Sicherung?

The 30A-175A Mini-ANL fuse from Masori features a gold-plated surface that offers both corrosion resistance and high conductivity. Various fuse ratings are available, ranging from 30A to 175A, suitable for different cable cross-sections from 4mm² to 50mm². These fuses are specifically designed for use with amplifiers and can support amplifier powers of approximately 400W to 2500W. Each package includes five Mini-ANL fuses, allowing you to choose the optimal safety level for your system.

Welche Kabelquerschnitte sind kompatibel mit der 30A-175A Mini-ANL Sicherung?

The 30A-175A Mini-ANL fuse is compatible with cable cross-sections from 4mm² to 50mm². For example, the 30A fuse is perfectly designed for 4mm² cables, while the 175A fuse is suitable for 50mm² cables. This means that you can select the appropriate fuse based on the cross-section of your cable and the required current strength to ensure a safe and efficient power supply. These fuses have been developed for amplifier power of up to 2500W, with each fuse tailored to a specific cable cross-section.

Welche Sicherungswerte sind für verschiedene Verstärkerleistungen geeignet?

The 30A-175A Mini-ANL fuse offers fuse ratings that correspond to various amplifier power levels. The 30A fuse rating is suitable for a power of approximately 400W, the 40A fuse can handle about 500W. For higher powers like 800W, the 60A fuse is appropriate, and the 175A fuse is suitable for up to 2500W. This variety allows for optimal adjustment of the fuse to the specific power requirements of your amplifier, ensuring smooth and safe operation.

Wie viele 30A-175A Mini-ANL Sicherungen sind im Lieferumfang enthalten?

The package of the 30A-175A Mini-ANL fuses from Masori includes a total of five pieces. This quantity allows you to either protect multiple amplifiers at the same time or have spare fuses on hand. The gold-plated Mini-ANL fuses not only provide an aesthetically pleasing appearance, but they are also technically high-quality to meet the demands of a safe and stable power supply in your audio setup.

Welche Funktion hat die Vergoldung bei der 30A-175A Mini-ANL Sicherung?

The gold plating of the 30A-175A Mini-ANL fuse serves several purposes. First, it improves the corrosion resistance of the fuse, which is particularly important in high-humidity environments to ensure a long lifespan of the fuse. Second, it increases electrical conductivity, which helps to transmit current more efficiently and with less energy loss. This contributes to the overall performance of your audio system and avoids unwanted resistance losses that could impair functionality.

Wie wird die 30A-175A Mini-ANL Sicherung für Kabeldimensionen ausgewählt?

When selecting the right 30A-175A Mini-ANL fuse for your cable cross-section, you should pay attention to the compatibility between the fuse rating and the cable dimension. A 30A fuse is recommended for a 4mm² cable, while a 175A fuse is optimal for a 50mm² cable. This adjustment is crucial to ensure optimal current transmission and protect your audio system without exceeding the maximum fuse rating. The exact selection depends on the power requirements of your entire audio setup.

Welche Bedeutung haben die unterschiedlichen Sicherungswerte bei der 30A-175A Mini-ANL Sicherung?

The different fuse ratings of the 30A-175A Mini-ANL fuse from Masori are crucial for adapting to various electrical systems. Lower fuse ratings like 30A are ideal for smaller systems with low power requirements, while higher ratings up to 175A are designed for systems with higher power demands. These ratings determine the maximum current that can flow through the fuse before it trips. This way, you can ensure that your system receives exactly the power it needs without the risk of overload.

Wie installiere ich die 30A-175A Mini-ANL Sicherung in meinem Fahrzeug?

The installation of the 30A-175A Mini-ANL fuse requires consideration of the cable dimensions and the fuse rating. First, determine the correct fuse rating based on your cable cross-section and amplifier power. Then, the fuse should be placed in a suitable fuse holder that is easily accessible and as close to the power source as possible. This minimizes energy losses and maximizes system efficiency. Ensure that all connections are tight and secure to guarantee reliable power transmission.

Mit welchen Automarken ist die 30A-175A Mini-ANL Sicherung kompatibel?

The 30A-175A Mini-ANL fuse is universally applicable and is not specifically tailored to certain car brands. Its compatibility depends more on the electrical system and the cable cross-sections in the car than on the brand of the vehicle. These connections can be installed in any type of vehicle, as long as the cable dimensions and the required fuse value are taken into account. Make sure to choose the fuse within the optimal parameters for your amplifier and your cable to avoid overheating and other technical issues.

Warum sollte ich mehrere 30A-175A Mini-ANL Sicherungen erwerben?

The acquisition of several 30A-175A Mini-ANL fuses is particularly sensible, as a delivery from Masori already includes five fuses. This variety gives you the flexibility to either secure multiple systems simultaneously or to have spare fuses available in case of a failure. The fuses are also gold-plated, making them robust and durable, which shows their resistance to environmental influences. Therefore, stockpiling is especially advisable to be able to respond to various amplifier adjustments at any time without compromising safety.
