  5. Voce AV 6.5

Audison Voce AV 6.5 6.5" (16,5cm) Mid-Woofer

4 Reviews

100 Watt

Audison Voce AV 6.5 6.5" (16,5cm) Mid-Woofer

4 Reviews

Technical Highlights

  • The power is 200 watts peak, impedance is 4 ohms.
  • Frequency range from 50 to 7k Hz, voice coil Ø 30 mm.
  • Copper-clad aluminum, radial venting system available.
  • More technical details
€179,00
€179,00 €179,00
5% discount with prepayment
inkl. VAT , possibly plus shipping
Delivery
Mar 23, - Mar 26,
x Couple
  • American Express
  • Apple Pay
  • Bancontact
  • BLIK
  • EPS
  • Google Pay
  • iDEAL Wero
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Twint
  • Union Pay
  • Visa
Klarna Pay conveniently in 12 interest-free installments at €14,91 with Klarna .

Your benefits at Masori

Seen cheaper elsewhere?

Shipping cost calculator

Expert Image

Rob

Expert Image

Max

Unsure if this product fits your car?

We help you – quickly, personally, and without obligation.

Response on weekdays within 24 hours
AudisonSR 5,600
Audison-SR 5.600-5-Kanal Verstärker-masori-kaufen
Audison-Thesis TH 3.0 II voce-3" (8cm) Mitteltöner-masori-kaufen
AudisonThesis TH 3.0 II voce
Audison-Voce AV 6.5-6.5" (16,5cm) Tiefmitteltöner-masori-kaufen
€179,00
€179,00 €179,00

Voce AV 6.5 by Audison

Introducing the Voce AV 6.5, the components of this 6.5-inch mid-bass driver are derived from the experience with the components of the renowned Audison Thesis line. Equipped with a remarkably aerodynamic structure and paper-pressed membranes made of cotton fibers, this model stands out for its lightweight design and strong performance. In addition to its 200-watt peak power, it also features an impressive frequency range from 50 to 7k Hz. To complete your audio experience, the Voce AV 6.5 also offers a triple-wave surround made of butyl rubber and extremely lightweight coils made of copper-clad aluminum wire.

TECHNICAL SPECIFICATIONS

  • Size 165 mm
  • Power Handling - Peak 200 W
  • Power Handling - Continuous 100 W
  • Impedance 4 Ohm
  • Frequency Response 50 - 7k Hz
  • Voice Coil Ø 30 mm
  • Voice Coil Material CCAW
  • Woofer Qes 0.82
  • Xmax 3 mm

ELECTRO-ACOUSTIC PROPERTIES

  • D 130 mm
  • Re 3.5 Ohm
  • Fs 68 Hz
  • Vas 8.2 l
  • Mms 16.1 g
  • Cms 0.34 mm/N
  • BL 5.5 T•m
  • Qms 7.84
  • Qts 0.74
  • Le Standard 0.31 mH
  • Le mH @ 10 kHz 0.07 - 0.17
  • SPL 91 dB

GENERAL

  • Weight 1.2 kg

DIMENSIONS

  • Dimension A 167 mm
  • Dimension B 146 mm
  • Dimension C 76 mm
  • Dimension D 69 mm
  • Dimension E 156 mm
  • Dimension G 30 mm
  • Dimension H 193 mm

FEATURES

  • The profile of the spokes of the aerodynamic basket combined with the open design drastically reduces rear wave reflections.
  • The exclusive triple-wave surround made of butyl rubber offers full linearity as well as reliable performance under extreme conditions.
  • Extremely light and compact, the CCAW (Copper Clad Aluminium Wire) wound voice coils with double layers provide very high efficiency and clean, dynamic sound.
  • Cone made of pressed paper with cotton fibers and light damping treatment.
  • The Radial Venting System ensures high thermal performance, power handling, and reliability.

Your benefits at Masori

Audison Voce AV 6.5 Datasheet

Open datasheet

Frequently Asked Questions about Voce AV 6.5

What power does the Audison Voce AV 6.5 offer?

The Audison Voce AV 6.5 has a peak power of 200 Watts and a continuous power handling of 100 Watts. These power parameters allow the speaker to meet demanding audio requirements. The frequency response ranges from 50 Hz to 7 kHz, covering a wide range of audio signals. Technically, the speaker is equipped with a 30 mm CCAW voice coil (Copper Clad Aluminium Wire), which impresses with its light weight and efficiency. Together with the aerodynamic structure and paper-pressed membranes, this ensures a balanced sound reproduction, ideal for high fidelity in music. These features make the speaker an excellent choice for anyone seeking high performance and clarity.

What are the specific dimensions of the Voce AV 6.5?

The dimensions of the Audison Voce AV 6.5 speaker are carefully designed for optimal integration and flexibility. The speaker has a diameter of 165 mm, while the mounting hole has a diameter of 146 mm. Other important measurements include an outer diameter of 167 mm and an overall depth of 76 mm. The installation depth is also 69 mm, ensuring easy adaptation to various installation locations. These specific dimensions are crucial for ensuring compatibility with a variety of applications, especially when space restrictions in the vehicle are a factor. When installing, the space for the depth and the diameter of the speaker should be considered.

How do the material properties of the Voce AV 6.5 affect sound quality?

The sound quality of the Voce AV 6.5 speaker from Audison is influenced by various high-quality material properties. The diaphragm made of pressed paper and cotton fibers is lightweight yet strong, resulting in clear sound reproduction and fast responsiveness. The Triple Wave surround made of butyl rubber contributes to the linear movement of the diaphragm and provides reliable performance even under extreme conditions. Additionally, the CCAW voice coil supports high efficiency due to its low weight. This combination of materials ensures a dynamic audio reproduction with clear highs and rich bass, making the Voce AV 6.5 an excellent choice for demanding audio installations.

What technical parameters define the electro-acoustic properties of the Voce AV 6.5?

The electro-acoustic properties of the Voce AV 6.5 speaker from Audison are defined by a number of specific parameters. The total DC resistance (Re) is 3.5 Ohms and the resonance frequency (Fs) is 68 Hz. Other characteristic values include the equivalent volume (Vas) of 8.2 l and the moving mass (Mms) of 16.1 g. The mechanical quality factor (Qms) is 7.84, while the electrical quality factor (Qes) is 0.82. The total system Q (Qts) is 0.74. The BL factor is 5.5 T•m, reflecting the motor strength. These specific parameters demonstrate a balanced relationship between efficiency, linearity, and performance, ensuring versatile acoustic performance.

How does the voice coil of the Voce AV 6.5 affect its performance?

The voice coil of the Voce AV 6.5 from Audison plays a crucial role in the speaker's performance. The 30 mm CCAW voice coil, wound from copper-coated aluminum wire, is extremely lightweight, significantly enhancing its responsiveness and efficiency. This design allows the speaker to react quickly and precisely to auditory signals without losing sound details. The double-layer winding of the CCAW voice coil reduces the moving mass while simultaneously providing high thermal resilience. This is ideal for applications where both durability and dynamic reproduction are paramount, as is the case with the Voce AV 6.5.

In which frequency ranges does the Voce AV 6.5 from Audison operate optimally?

The Voce AV 6.5 from Audison covers an impressive frequency range of 50 Hz to 7 kHz, making it a versatile component in any audio system. This bandwidth allows for the reproduction of deep bass frequencies as well as precise mid to high frequencies, ideal for complex audio installations. When combined with a suitable amplifier, the speaker can effortlessly deliver both soft sounds and powerful beats. Especially for music lovers who want to experience both depth and clarity in their sound, the Voce AV 6.5 shines particularly well. These frequency capabilities complement its wide musical application and make it a valuable addition to any high-end audio system.

What design of the Voce AV 6.5 speaker reduces rear wave reflections?

The Voce AV 6.5 speaker from Audison features a special cabinet design that specifically aims to reduce rear wave reflections. The aerodynamically shaped and spoke-like chassis parts, along with the open design, significantly contribute to minimizing unwanted rear waves. This construction optimizes sound guidance and reduces disturbing resonances to ensure uncolored sound reproduction. Especially at high volumes and with complex musical pieces, the effect of this design becomes particularly evident, as reflections can distort playback. This design keeps the audio output of the speaker transparent and clear, providing an authentic sound image.

What characteristics of the diaphragm of the Voce AV 6.5 enhance performance?

The diaphragm of the Voce AV 6.5 speaker from Audison is made of pressed paper combined with cotton fibers, significantly improving its acoustic properties. This material choice ensures an optimal weight ratio and allows for a quick response to audio inputs, which in turn enhances sound fidelity. Thanks to a special light-damping treatment, the diaphragm remains shape-stable, maintaining performance even under high loads. This combination positively affects the dynamic range of the speaker, reduces distortion, and ensures precise reproduction of musical content across various genres. As a result, the Voce AV 6.5 offers an intense, unadulterated sound experience.

What role does the Triple Wave surround play in the Voce AV 6.5?

The Triple Wave surround of the Voce AV 6.5 from Audison has a crucial task, namely to ensure linear and reliable power transfer under extreme operating conditions. Made from butyl rubber, this surround is particularly flexible and durable, allowing for a smooth and efficient transition between the diaphragm and the frame. This design enables the diaphragm to move evenly without distorting the sound, which is especially beneficial at high volumes or low frequencies. Additionally, the Triple Wave construction minimizes restoring force and prevents unwanted vibrations, leading to a clearer reproduction of the frequency spectrum overall.

How does the Radial Venting System in the Voce AV 6.5 ensure thermal stability?

The Radial Venting System of the Voce AV 6.5 speaker from Audison significantly improves thermal stability by optimizing heat dissipation during operation. This technology ensures effective ventilation of the voice coil, increasing thermal resilience and preventing performance losses. Especially under intense operating demands, such as those that can occur with prolonged high volume, the system showcases its advantages. Through continuous heat dissipation, the efficiency of the speaker is maintained even under maximum load, enhancing its reliability in various application environments. This feature makes the Voce AV 6.5 the ideal solution for demanding audio installations.
