Morel TiCW 1258Ft 12" (30cm) Subwoofer

Morel TiCW 1258Ft 12" (30cm) Subwoofer

  • 600 watts RMS power handling, 8 ohms impedance, 19-2000 Hz frequency.
  • 5.1" Hexatech voice coil, copper-clad pole cap, 88 dB Sens.
  • Aluminum frame, titanium former, 19 Hz resonance, 0.38 Qes.
  • Mehr technische Details
00
00
00
00
€679,11
€798,95 €679,11
5% Rabatt mit Vorkasse
inkl. VAT , possibly plus shipping
Klarna Bequem in 12 zinsfreien Raten à €56,59 mit Klarna zahlen.
x Piece
  • American Express
  • Apple Pay
  • Bancontact
  • BLIK
  • EPS
  • Google Pay
  • iDEAL
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Twint
  • Union Pay
  • Visa

Seen cheaper?

Shipping cost calculator

Garantie & zusätzlicher Geräteschutz für dein HiFi-System

Deshalb wählen uns 100.000+ Kunden

Expert Image

Rob

Expert Image

Max

Unsicher, ob dieses Produkt zu deinem Auto passt?

Wir helfen dir – schnell, persönlich und unverbindlich.

Antwort on weekdays within 24h
MorelTiCW1254Ft
Morel-TiCW1254Ft-12" (30cm) Subwoofer-masori-kaufen
Dayton Audio-Reference RSS315HF-4-12" (30cm) Subwoofer-masori-kaufen
Dayton AudioReference RSS315HF-4

TiCW 1258Ft by Morel

Discover the TiCW 1258Ft from Morel, a high-quality 12-inch subwoofer that impresses with its outstanding features. The combination of a copper-clad pole cap and a titanium former ensures minimized inductance, while the 8-ohm impedance provides a high damping factor and improved amplifier control. With a power handling of up to 600 watts RMS and a frequency response from 19 to 2,000 Hz, this subwoofer meets the highest demands. The 5.1" Hexatech voice coil and the self-centering paper cone highlight its technical strengths. All of this is complemented by a robust construction using materials such as aluminum and titanium.

Highlights

  • Copper-clad pole cap and titanium former reduce speed-reducing inductance
  • 8-ohm impedance for a high damping factor and more amplifier control
  • 5.1" Hexatech voice coil for 600 watts RMS power handling
  • Accucenter self-centering, one-piece paper cone

Specifications

  • Woofer Series Titanium Series
  • 12-inch subwoofer
  • Nominal diameter 305 mm
  • Power handling (QMW) 600 Watts
  • Power handling (max) 3,000 Watts
  • Impedance (Z) 8 ohms
  • Sensitivity (SPL at 1m / 2.83V) 88 dB
  • Frequency response 19 to 2,000 Hz
  • Voice coil diameter 130 mm
  • DC resistance (Re) 6.4 ohms
  • Voice coil inductance (Le) 0.62 mH
  • Resonance frequency (Fs) 19 Hz
  • Mechanical Q (Qms) 4.03
  • Electrical Q (Qes) 0.38
  • Total Q (Qts) 0.34
  • Moving mass (Mms) 110g
  • Diaphragm area (Sd) 437 cm²
  • Force factor (BL) 15.25 Tm
  • Equivalent volume (Vas) 170.46 L
  • Maximum excursion (Xmax) 10.5 mm
  • Cone / Diaphragm Material Paper
  • Surround material Rubber
  • Voice coil wire material Aluminum
  • Voice coil former material Titanium
  • Basket / frame material Cast Aluminum
  • Magnet material Ferrite
  • Outer diameter 305 mm
  • Total depth 150 mm
  • Cutout diameter 269.24 mm
  • Mounting holes 6
  • Sealed volume 38.22 L
  • Sealed F3 44 Hz
  • Bass reflex volume 82 mm
  • Bass reflex F3 26 Hz

Morel TiCW 1258Ft Datenblatt

Datenblatt öffnen

Frequent questions about TiCW 1258Ft

Welche technischen Merkmale bietet der Morel TiCW 1258Ft Subwoofer?

The Morel TiCW 1258Ft is a 12" (30cm) subwoofer equipped with a copper-coated pole piece and titanium former to reduce inductance. The 8-ohm impedance improves the damping factor and amplifier control. A 5.1" Hexatech voice coil allows for 600 watts RMS load. The frequency response ranges from 19 to 2,000 Hz, supported by a self-centering paper cone. The subwoofer is made from robust materials such as aluminum and titanium, ensuring its durability. Other technical details include an outer diameter and cutout diameter of 305 mm and 269.24 mm, respectively.

Wie hoch ist die Belastbarkeit des Morel TiCW 1258Ft?

The Morel TiCW 1258Ft subwoofer has a power handling capacity of 600 watts RMS and can withstand a maximum of up to 3,000 watts. This high power handling capacity is due to the 5.1" Hexatech voice coil, which is made from materials such as aluminum. The combination of robust materials and the strong voice coil allows the subwoofer to deliver clear sound reproduction without distortion, even at high volumes. This makes the subwoofer ideal for music lovers who want to experience powerful and precise bass.

Was sind die Abmessungen und Gehäuseanforderungen für den TiCW 1258Ft?

The TiCW 1258Ft from Morel has a nominal diameter of 305 mm and an overall depth of 150 mm. The cutout diameter is 269.24 mm, which must be taken into account during installation. For optimal sound, a sealed enclosure with a volume of 38.22 liters or a bass reflex enclosure with a volume of 82 mm is recommended. These dimensions support the optimized frequency response and bass output of the subwoofer to provide a balanced and powerful soundscape. Installation should be based on these dimensions and recommendations.

Welche Materialien werden für den TiCW 1258Ft verwendet?

The Morel TiCW 1258Ft relies on high-quality materials such as a copper-coated pole cap and a titanium former to maximize performance. The voice coil is made of aluminum wire and is shaped with titanium, contributing to maximizing lifespan and efficient heat distribution. The basket and frame are made of cast aluminum, and the magnet is made of ferrite. The paper diaphragm and rubber surround material complete the choice of materials to enable precise sound reproduction and ensure durability.

Wie verbessert der Morel TiCW 1258Ft die Verstärkerkontrolle?

The Morel TiCW 1258Ft subwoofer uses an 8-ohm impedance, which increases the damping factor and thus ensures better control over the amplifier. The specific treatment with a copper-coated pole cap and titanium former minimizes inductance, further optimizing the speed and precision of sound reproduction. This allows amplifiers to operate more effectively, produce less distortion, and achieve precise control over bass frequencies. As a result, this provides a detailed and powerful sound.

Wie ist der Frequenzgang des Morel TiCW 1258Ft gestaltet?

The Morel TiCW 1258Ft offers a frequency response of 19 Hz to 2,000 Hz. This allows for a wide sound reproduction from deep bass to upper mids. The 5.1" Hexatech voice coil contributes to the optimal transmission of the entire frequency spectrum without compromising sound quality. The combination of a self-centering paper diaphragm and the high-quality materials of the subwoofer ensures that even at high sound pressure levels, a precise and clear reproduction occurs, allowing details in music and film sound to come to the fore perfectly.

Wie beeinflussen die mechanischen Parameter des TiCW 1258Ft den Klang?

The Morel TiCW 1258Ft impresses with its outstanding mechanical parameters: The mechanical quality (Qms) is at 4.03, while the electrical quality (Qes) is at 0.38, resulting in a total quality (Qts) of 0.34. These parameters significantly influence the vibration behavior and low-frequency reproduction. The resonance frequency of 19 Hz allows for deep, rich bass, while the high mechanical stability provided by the cast aluminum basket and the paper diaphragm ensures precise movement. The sound is therefore voluminous, detailed, and balanced.

Welche Bedeutung haben die Thiele-Small-Parameter des TiCW 1258Ft?

The Thiele-Small parameters of the Morel TiCW 1258Ft are essential for precise sound tuning. With a resonance frequency (Fs) of 19 Hz and a total Q factor (Qts) of 0.34, excellent low-end reproduction is achieved. The moving mass (Mms) is 110 g, which, along with the diaphragm area (Sd) of 437 cm², ensures the ability to respond quickly to signals. The force factor (BL) of 15.25 Tm ensures that the subwoofer remains controlled even at high sound pressure levels. These parameters are crucial for performance and sound quality.

Welche Rolle spielt die 5,1"-Hexatech-Schwingspule im TiCW 1258Ft?

The 5.1" Hexatech voice coil in the Morel TiCW 1258Ft is primarily responsible for its high performance. It allows for an RMS power handling of 600 watts, optimized by the use of aluminum wire to provide excellent thermal properties. The voice coil is also embedded in a titanium carrier, ensuring durability and resistance to deformation at high temperatures. This construction ensures that the music remains clear and undistorted even at high volumes, ideal for intense listening experiences and dynamic audio playback.

Ist der Morel TiCW 1258Ft Subwoofer einfach zu installieren?

The installation of the Morel TiCW 1258Ft subwoofer requires precise work, but its clear specifications allow for a smooth adjustment. The cutout diameter is 269.24 mm and requires 6 mounting holes for stable installation. The total depth of the subwoofer is 150 mm and the outer diameter is 305 mm, allowing for easy integration into most subwoofer enclosures, whether sealed or bass reflex. A sealed enclosure volume of 38.22 liters optimizes power output, while bass reflex designs may be preferred at a volume of 82 mm for lower frequencies.
