  3. Mille Legend MLK 700.3 (B-Ware)

Hertz Mille Legend MLK 700.3 (B-Ware) 3" (8cm) Speaker Set

100 Watt

Hertz Mille Legend MLK 700.3 (B-Ware) 3" (8cm) Speaker Set

Technical Highlights

  • Belastbarkeit: RMS 100 W, Spitzenwert 200 W, Impedanz 4 Ohm.
  • Frequenzgang: 200 28k Hz, Empfindlichkeit 90 dB, Hochtöner 92 dB.
  • Schwingspule: Tieftöner Ø 20 mm, Hochtöner Ø 28 mm.
  • More technical details
00 d
00 h
00 m
00 s
€461,30
-30% €659,00 €461,30
5% discount with prepayment
inkl. VAT , possibly plus shipping
Only a few left in stock (1 pieces available)
In stock
Mar 22, - Mar 23,
x Set
  • American Express
  • Apple Pay
  • Bancontact
  • BLIK
  • EPS
  • Google Pay
  • iDEAL Wero
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Twint
  • Union Pay
  • Visa
Klarna Pay conveniently in 12 interest-free installments at €38,44 with Klarna .

Your benefits at Masori

Seen cheaper elsewhere?

Shipping cost calculator

Expert Image

Rob

Expert Image

Max

Unsure if this product fits your car?

We help you – quickly, personally, and without obligation.

Response on weekdays within 24 hours
Hertz-Mille Legend MLK 700.3 (B-Ware)-3" (8cm) Lautsprecherset-masori-kaufen
€461,30
€659,00 €461,30

Mille Legend MLK 700.3 (B-Ware) by Hertz

Refurbished item due to damaged or incomplete original packaging, or minor cosmetic defects. The same warranty conditions apply to refurbished items as to our new items. The product is technically flawless.

The Mille Legend MLK 700.3 from Hertz is a 3-inch Speaker Set that stands out particularly for its excellent performance in the mid to high frequency range. Designed for combination with an ML 1650.3 or ML 1800.3 Legend Woofer in a multi-amplifier system, it is the perfect addition for an optimal sound experience. Particularly interesting is the unique mid contour control with a 3-position switch, which varies the crossover point with the Tweeter at the mid frequencies of the ML 700.3 Legend Midrange. This allows you to customize the sound to your needs and achieve optimal sound quality. Another highlight is the high power handling with a continuous operation of 100 W and a peak value of 200 W. With the Mille Legend MLK 700.3, you choose sound quality at the highest level.

Technical Data

  • Size mm 70
  • Power Handling - RMS W 100
  • Power Handling - Peak W 200
  • Impedance Ohm 4
  • Tweeter Membrane mm 35
  • Woofer Voice Coil Ø mm 20
  • Tweeter Voice Coil Ø mm 28
  • Sensitivity dB SPL Midrange 90 Tweeter 92
  • Frequency Response Hz 200 - 28k
  • Crossover Cut off 4.5 kHz - 6/12 dB Oct.
  • Crossover Type 2-way passive crossover
  • Weight - Woofer kg 0.210
  • Weight - Tweeter kg 0.1
  • Weight - Crossover kg 0.57

Electro-Acoustic Specifications

  • D mm 65
  • Re Ohm 3.8
  • Fs Hz 110
  • Le mH 0.05
  • Vas I 1.1
  • Mms g 2.7
  • Cms mm/N 0.7
  • BL T*m 3.3
  • Qts 0.57
  • Qes 0.67
  • Qms 4
  • Spl dB 90

Your benefits at Masori

Hertz Mille Legend MLK 700.3 (B-Ware) Datasheet

Open datasheet

Frequently Asked Questions about Mille Legend MLK 700.3 (B-Ware)

What are the main features of the Mille Legend MLK 700.3 Speaker Set?

The Mille Legend MLK 700.3 from Hertz features a size of 70 mm and a power handling of 100 Watts RMS. Notably, it has a midrange contour control that allows for individual adjustment of the crossover point between the midrange driver and the tweeter. This offers a unique sound modulation that can be tailored to personal preferences. The impedance is 4 Ohms, and it has a frequency response of 200 Hz to 28 kHz. The sensitivities for the midrange driver and tweeter are 90 dB and 92 dB, making it ideal for complex audio systems.

How does the crossover type of the Mille Legend MLK 700.3 affect the sound?

The Mille Legend MLK 700.3 is equipped with a 2-way passive crossover. This crossover separates the audio into two ranges at a crossover cut-off of 4.5 kHz with a slope of 6/12 dB per octave. This means that high and mid frequencies are treated separately to minimize distortion and achieve a clear separation of frequency bands. This ensures high sound quality, which particularly unfolds in complex audio compositions, benefiting discerning music listeners greatly.

What power specifications does the Mille Legend MLK 700.3 offer?

The Mille Legend MLK 700.3 Speaker Set from Hertz impresses with a robust RMS power of 100 W, while the peak power is 200 W. Its tweeter diaphragm has a diameter of 35 mm, while the voice coil of the woofer and tweeter measures Ø 20 mm and Ø 28 mm, respectively. These specifications allow for powerful reproduction of mid to high frequencies and are ideal for those seeking strong and clear sound reproduction in their audio systems.

How do the Thiele-Small parameters of the Mille Legend MLK 700.3 behave?

The Thiele-Small parameters of the Mille Legend MLK 700.3 include a Re value of 3.8 Ohms and a free resonance frequency (Fs) of 110 Hz. With an equivalent membrane area Vas of 1.1 liters and a total quality factor Qts of 0.57, it is excellent for precise and controlled deep bass reproduction. The parameter BL, which indicates a magnetic force of 3.3 T*m, reflects its performance in controlling the diaphragm movement. These values are crucial for assessing the quality of speakers in terms of their acoustic properties.

What dimensions are important for the installation of the Mille Legend MLK 700.3?

When installing the Mille Legend MLK 700.3, you should consider its compact dimensions of 70 mm. This facilitates its integration into various vehicles or audio installations. The low weight of 0.21 kg for the woofer and 0.1 kg for the tweeter makes it possible to install it even in tight spaces without compromising vehicle dynamics. Its dimensions and the weight of the crossover at 0.57 kg ensure that the speaker can be easily integrated into most audio systems, taking minimal space requirements into account.

How does the midrange contour controller of the Mille Legend MLK 700.3 modify the sound?

The midrange contour controller of the Mille Legend MLK 700.3 offers the ability to adjust the sound of the speaker by varying the crossover point between the midrange driver and the tweeter. This 3-position switch allows you to individually regulate the balance between mid frequencies and higher frequencies, depending on personal listening preferences. This feature can be particularly useful when you change your preferences or the type of music being played and need finer control over the audio performance, leading to a differentiated and personalized listening experience.

What sensitivity values does the Mille Legend MLK 700.3 offer?

The sensitivity of the Mille Legend MLK 700.3 is a key feature that underscores its efficiency in audio playback. The midrange driver has a sensitivity of 90 dB, while the tweeter operates at 92 dB. These values mean that the speaker can produce a considerable volume at a given input voltage, which is particularly important for sound quality in different listening environments and vehicle configurations. Higher sensitivities lead to a clearer and more dynamic sound image that can also perform well at lower power requirements.

What acoustic properties does the Mille Legend MLK 700.3 have?

The Mille Legend MLK 700.3 offers excellent electro-acoustic specifications, such as a Cms of 0.7 mm/N, which affects the compliance of the speaker diaphragm. The mechanical quality Qms of 4 ensures that it provides resonance-free playback characteristics. With an Mms of 2.7 g, the effective moving mass is shown, which directly influences sound quality and the precision of curve representation and bass reproduction. These acoustic parameters allow for an accurate reproduction of musical details, providing audiophile listening experiences at a high level.

What is the frequency response of the Mille Legend MLK 700.3?

The Mille Legend MLK 700.3 from Hertz covers a comprehensive frequency range from 200 Hz to 28 kHz. This wide frequency response ensures that both mid and high tones are reproduced clearly and precisely. The min-max range is ideal for complex music compositions where a variety of sound nuances must be represented. Especially in combination with other components of the series, the sonic impression, particularly at high volumes, is enabled. This frequency response is excellent for genres that require detailed high and mid-frequency representations, such as classical music.

Is the Mille Legend MLK 700.3 compatible with other sound systems?

The Mille Legend MLK 700.3 is specifically designed to be combined in multi-amplifier systems, particularly with the ML 1650.3 or ML 1800.3 Legend Woofer. The product dimensions and technical specifications, such as the impedance of 4 Ohms, make it compatible with a variety of existing audio systems. This means it can be integrated into different vehicle models, provided the spatial requirements are met. It is advisable to check the dimensions before installation to ensure that the Speaker Set fits perfectly with the existing system and allows for seamless integration.
