Musway CSVT-8.2C VW speaker set

Power 100 watts RMS and 200 watts Max, impedance 4 ohms.
Frequency range 30-22,000 Hz, 20 cm woofer, fiberglass.
28 mm neodymium tweeter, compatibility with VW T5 and T6.
Mehr technische Details

€299,00

~~€299,00~~ €299,00

5% Rabatt mit Vorkasse

inkl. VAT , possibly plus shipping

Bequem in 12 zinsfreien Raten à €24,91 mit Klarna zahlen.

Jetzt mit kostenlosem Versand ab 50€!

Shipping cost calculator

Land/Region

PLZ

Garantie & zusätzlicher Geräteschutz für dein HiFi-System

3 Jahre Masori Garantie Kostenlos 48 Monate Plusgarantie €24,99 60 Monate Plusgarantie Am beliebtesten €34,99

Deshalb wählen uns 100.000+ Kunden

3 Jahre Garantie

Sicher & sorglos
Blitzversand

mit DHL Express
Tiefpreisschutz

Nie zu viel zahlen

Rob

Max

Unsicher, ob dieses Produkt zu deinem Auto passt?

Wir helfen dir – schnell, persönlich und unverbindlich.

Antwort on weekdays within 24h

MuswayMG6.3A

MuswayCSM-8WL

CSVT-8.2C by Musway

The Musway CSVT-8.2C is a VW speaker set specifically designed for the Volkswagen T5 and T6. This 2-way front system set delivers 100 watts RMS and 200 watts max power, covering a frequency range from 30 to 22,000Hz. It includes 20 cm mid-bass drivers with fiberglass cones and 28 mm fabric neodymium tweeters. By installing these larger woofers, you not only get significantly improved bass but also amazing linearity and brilliance up to 20,000 Hz. Another advantage is the straightforward plug-and-play connection. With the CSVT-8.2C, Musway has created a speaker set that impresses with both excellent sound and easy handling.

The original T5/T6 speakers in the doors are only 6.5 inches in size and offer limited linear excursion. Naturally, they produce little bass. In contrast, the CSVT-8.2C’s woofers, with a diameter of 20 cm, have nearly 50% more cone area and long-excursion coils, allowing for much richer bass. To ensure clean playback even at the highest volumes, the woofers are equipped with high-quality fiberglass cones. The ABS basket is designed so that the rubber funnels, available as accessories, can be perfectly secured. This prevents the sound in the door from "dying out" but instead projects directly forward from the speakers.

The finely resolving 28 mm tweeters with silk domes can play very low thanks to their size and harmonize perfectly with the 8-inch speakers in the door. They also deliver remarkable linearity and brilliance up to 20,000 Hz at the high end. The tweeters can be detached from the adapter plate, making them compatible with both the T5 and T6 vans.

Features

20cm (8”) 2-way front system set for VW T5 and T6
Power 100 watts RMS
Power 200 watts max
Impedance 4 ohms
Frequency range 30 - 22000 Hz
20 cm mid-bass driver, fiberglass cone
Y35 magnet with 22 ounces (624 g)
28 mm fabric neodymium tweeter
Mounting depth 34 mm
Mounting opening 193 mm
Plug-and-play connections

Compatibility

Volkswagen T5 (2003 - 2015), front
Volkswagen T6 (since 2015), front

Musway CSVT-8.2C Datenblatt

Datenblatt öffnen

Frequent questions about CSVT-8.2C

Welche Leistung bietet das Musway CSVT-8.2C System?

The Musway CSVT-8.2C speaker set offers a power of 100 watts RMS and a maximum power consumption of 200 watts. It covers a frequency range from 30 to 22,000 Hz. This configuration not only allows for powerful bass thanks to the 20 cm mid-bass drivers with fiberglass membranes, but also impressive linearity and brilliant highs up to 20 kHz. The use of specially designed long-stroke voice coils in the woofers enables deeper and clearer bass reproduction, making the system particularly optimized for high-quality audio applications in the Volkswagen T5 and T6.

Wie tragen die Woofer des CSVT-8.2C zur Klangqualität bei?

The 20 cm woofers used in the Musway CSVT-8.2C feature an impressive 50% larger diaphragm area compared to the original 16.5 cm speakers in the Volkswagen T5 and T6. This results in a significant improvement in bass reproduction. The fiberglass membranes of the woofers are not only robust but also provide increased clarity and brilliance to the sound by minimizing distortion. Thanks to the ABS basket, which is specifically designed to accommodate rubber cones, the sound is optimally emitted, enhancing the overall sound quality of the subwoofers.

Wie beeinflusst der Plug+Play Anschluss die Installation?

The Plug+Play connection of the Musway CSVT-8.2C allows for a straightforward and quick installation in the Volkswagen T5 and T6. Since no additional adapters are required, the system can be connected directly to the existing wiring harnesses. The 20 cm midrange drivers and 28 mm neodymium tweeters are designed to fit precisely into the factory installation locations of the vehicles, which simplifies the installation process and reduces the need for modifications.

Welche Rolle spielt die Einbautiefe des CSVT-8.2C?

With a mounting depth of only 34 mm, the Musway CSVT-8.2C can be easily installed in the doors of the Volkswagen T5 and T6 despite its larger woofers. This compact design is crucial to ensure that the speaker does not collide with other components in the door area. At the same time, the mounting opening with a diameter of 193 mm ensures that the system is securely anchored, which supports sound quality and the longevity of the installation.

Welche Frequenzen können die Hochtöner abdecken?

The 28 mm textile neodymium tweeters of the Musway CSVT-8.2C are remarkably finely resolving and can cover frequencies up to an impressive 22,000 Hz. This wider frequency range ensures that even the highest audio frequencies are reproduced clearly and without distortion. The use of silk domes allows the tweeter to play particularly low, harmonizing with the woofers, resulting in a balanced and detailed sound image.

Welche technischen Vorteile bieten die Glasfaser-Membranen der Tiefmitteltöner?

The fiberglass membranes of the 20 cm mid-bass drivers in the Musway CSVT-8.2C offer a range of advantages, including increased strength and low weight. This allows the woofers to perform faster and more accurate movements, resulting in more precise bass reproduction. These materials also help to reduce distortion and produce a cleaner sound, even at high volumes and intense use, which enhances the overall performance of the speakers.

Welche Frequenzbereiche deckt das Musway CSVT-8.2C ab?

The Musway CSVT-8.2C front system set covers a frequency range from 30 Hz to 22,000 Hz. This wide range allows for detailed reproduction of both low and high frequencies, creating a balanced sound image. This is particularly advantageous for listeners who appreciate both bass resonance and high sound fidelity in their music pieces. The woofers and tweeters are perfectly matched to ensure a harmonious sound image across the entire frequency range.

Wie kann die Kompatibilität des CSVT-8.2C mit Fahrzeugen geprüft werden?

The Musway CSVT-8.2C is specifically designed for the Volkswagen models T5 and T6 and offers direct compatibility for the front doors of these vehicles. Compatibility is ensured by using the original connection points, which allow for plug-and-play installation. With a mounting depth of 34 mm and a mounting opening of 193 mm, the system fits precisely into the designated installation locations without requiring modifications to the door structure. The tweeters can be easily replaced due to the detachable adapter plate.

Wie lassen sich die Tweeter des CSVT-8.2C anpassen?

The 28 mm tweeters of the Musway CSVT-8.2C feature a practical adapter plate that allows them to be quickly and easily removed from the installation locations for replacement or repositioning if necessary. This allows for flexible adjustment to different acoustic requirements in the vehicle. Additionally, their design harmonizes perfectly with the 20 cm mid-bass drivers, positively influencing the integration and thus the overall acoustics in the vehicle space.

Welche Materialien werden im Musway CSVT-8.2C verwendet?

The Musway CSVT-8.2C features 20 cm mid-bass drivers equipped with high-quality fiberglass membranes, contributing to increased stability and clear sound. The 28 mm tweeters use finely resolved fabric neodymium to ensure high fidelity. The robust ABS basket of the woofers provides structural integrity and uniform sound flow. This careful selection of advanced materials contributes to the outstanding performance and durability of the speaker system, delivering superior output.
