3. Emphaser speakers, Subwoofer & more for the car
  5. ECP-G5

ECP-G5

80 Watt

ECP-G5

Technical Highlights

  • 80 watts RMS rated power handling, 4 Ohm nominal impedance.
  • Frequency response of 85 Hz to 22 kHz, sensitivity 87 dB.
  • CRYSTALGRAIN diaphragm, strontium ferrite magnet, fabric dome.
  • More technical details
€182.46
-13% €209.00 €182.46
2% discount with credit card

Your price match offer

ProductECP-G5

Reply within 1–3 working days · Mon–Fri. Outside the EU, we are happy to review an individual offer.

Privacy

This website is protected by hCaptcha. The privacy policy and terms of service of hCaptcha apply.
including VAT
Estimated delivery: Sep 17–Sep 22.
  • American Express
  • Apple Pay
  • Bancontact
  • BLIK
  • EPS
  • Google Pay
  • iDEAL Wero
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Shop Pay
  • Twint
  • Union Pay
  • Visa

Delivery & availability

The selected variant is not currently in stock at Masori and is sourced from the supplier. Refer to the estimated delivery window above.

Orders ship together based on the item with the longest lead time. If you need something sooner, ask by email about a possible partial shipment beforehand.

Shipping costs and options depend on the destination. Check the shipping calculator; final costs are shown before placing the order.

Email us the product, car, existing system and budget. We will offer an alternative available sooner.

Ask for an alternative available sooner

Reply in 1–3 working days · Mon–Fri

1 year extra warranty

Every product purchased from Masori includes an additional year of warranty in the third year after purchase (months 25–36). We cover repair or replacement free of charge for covered warranty claims. Automatic and free – exclusively for Masori customers. Your statutory rights remain unaffected.

Warranty terms
datasheet
EmphaserEM-FTF2
Emphaser-EM-FTF2-Fiat-Lautsprecherset-masori-kaufen
Emphaser-ECP-M5-5" (13cm) Lautsprecherset-masori-kaufen
EmphaserECP-M5
Emphaser-ECP-G5-5" (13cm) Lautsprecherset-masori-kaufen
€182.46
€209.00 €182.46

The ECP-G5 from Emphaser is a 5-inch speaker set that impresses with its precise sound reproduction and versatile applications. The woofer uses the innovative CRYSTALGRAIN compound diaphragm for warm sound reproduction, combined with a strontium ferrite magnet for powerful bass attacks. The tweeter with a 25 mm fabric dome ensures detailed music playback and can be mounted flexibly. The set includes high-quality crossovers that allow for easy installation. With a nominal power handling of 80 watts RMS and a frequency response of 85 Hz – 22 kHz, the ECP-G5 is a versatile addition to any sound system.

The Woofer

The warmth of the GRAVITY sound is thanks to the new CRYSTALGRAIN compound diaphragm. It combines the high stiffness and damping effect of paper with the direct transient response of the quartz crystals applied on the top side. The diaphragm thickness is chosen to provide stability for powerful bass attacks and the necessary lightness for precise midrange. The durable surround ensures that the ECP-G5 does not lose any of its precise reproduction even at high levels and thus high diaphragm excursions. The clean, crisp bass foundation and its level capabilities are owed to the strong strontium ferrite magnets of the mid/woofer.

The carefully selected components are housed in the minimally designed Emphaser FlowMax aluminum die-cast basket. The very open construction with delicate struts gives the rear-radiated sound maximum freedom and minimizes unwanted reflective surfaces that could affect the sound. Despite its delicate design, the construction offers maximum stability. Another innovation is the new Emphaser screw terminal: although very robust, it requires very little space and ensures secure signal transmission with its solid connection using massive hexagon screws and gold-plated contact surfaces.

The Tweeter

The 25 mm fabric dome tweeter impresses with its warm sound and can reproduce even the smallest musical details. The diaphragm geometry offers a uniform directivity pattern for excellent sound in various installation situations. Besides the low weight of diaphragm, surround, and voice coil, it is especially the deliberate omission of ferrofluid that allows the tweeter to play so lively, spatially, and distortion-free. The protective grille offers high sound permeability and low reflections due to its very large opening area. The included mounting housing allows installation at two different radiation angles for perfect adaptation to the vehicle acoustics.

The Crossover

The components of the crossovers have been defined through intensive test series in the lab and in various vehicles to achieve the best possible phase alignment of the components with minimal space requirements. The result is authentic-sounding voices and instruments with precise stage imaging and impressive spatial depth. The crossovers are divided into a tweeter and woofer branch. This allows easy installation directly at the mounting location without the need to lay new cables across the vehicle.

Main Features Woofer

  • 13 cm mid-woofer
  • Emphaser CRYSTALGRAIN compound diaphragm with inverted dustcap
  • Emphaser FlowMax aluminum die-cast basket with optimized temperature management
  • Strontium ferrite magnet
  • Butyl rubber surround
  • Two-layer copper wire voice coil wound on a heat-resistant aluminum voice coil former
  • Durable Connex centering spider with integrated voice coil lead
  • Emphaser screw terminal with gold-plated contact surfaces

Main Features Tweeter

  • 25 mm fabric dome with neodymium magnet
  • Housing with low installation depth
  • Protective grille with very large opening area for high sound permeability and low reflections
  • Mounting housing for installation at two different radiation angles

Main Features Crossovers

  • 12 dB woofer / 12 dB tweeter filter
  • Two-stage level adjustment for the tweeter
  • Separate crossovers for tweeter and woofer for optimal installation convenience
  • Use of high-quality air coils, MKP capacitors, and MOX resistors in the direct signal path
  • Pre-assembled connection cables

Technical Specifications

  • Rated power handling: 80 Watt RMS
  • Nominal impedance: 4 Ohm
  • Frequency response: 85 Hz – 22 kHz
  • Sensitivity 1W/1m: 87 dB
  • Mounting diameter: 116 mm
  • Mounting depth: 60 mm

Scope of Delivery

  • 2 tweeters
  • 2 woofers/mid-woofers
  • 4 crossovers
  • Optional speaker cover: ESP-GR5

datasheet

Open data sheet

Frequently Asked Questions about ECP-G5

What advantages does the CRYSTALGRAIN compound membrane of the Emphaser ECP-G5 offer?

The CRYSTALGRAIN compound membrane of the Emphaser ECP-G5 provides a remarkable combination of high stiffness and the damping effect of paper, enhanced by quartz crystals attached to the surface. This construction allows for an ideal balance between stability for powerful bass attacks and the necessary lightness for precise midrange reproduction. The membrane thickness is designed to maintain precision even at high volume levels. Therefore, the ECP-G5 is particularly suitable for listeners who appreciate detailed and powerful music playback without experiencing distortion. The innovative membrane significantly contributes to the acoustic excellence of the Speaker Set.

How does the crossover work in the Emphaser ECP-G5 Speaker Set?

The crossovers of the Emphaser ECP-G5 Speaker Set are precisely designed for the ideal phase alignment of the components. They use high-quality air coils, MKP capacitors, and MOX resistors in the direct signal path to achieve optimal sound separation between the tweeters and woofers. With a 12 dB filter for both woofers and tweeters and a two-stage level adjustment for the tweeter, they offer maximum flexibility and sound quality. The separate crossovers for tweeters and woofers allow for easy and flexible installation in the vehicle without additional wiring in the interior.

How does the strontium ferrite magnet of the woofer affect performance?

The strontium ferrite magnet of the woofer in the Emphaser ECP-G5 is crucial for powerful bass reproduction. This type of magnet offers a high magnetic flux density, which increases the sensitivity of the speaker, enabling a more dynamic and precise sound. This property is particularly important for reproducing low frequencies, as it ensures better control of the membrane movement. Additionally, the magnet contributes to the robustness of the sound at high volumes without losing clarity. The combination of magnet and membrane is therefore ideal for rich bass reproduction.

What role does the aluminum die-cast basket play in the ECP-G5?

The FlowMax aluminum die-cast basket of the Emphaser ECP-G5 features an exceptionally open design, minimizing unwanted reflections. This open structure supports rear sound radiation and improves the temperature management of the speakers. Despite the lightweight and delicate construction of the basket, it offers high stability, ensuring consistent performance even at high volumes. The robust build increases durability and reduces resonances that could affect the sound. This results in clear and uncolored sound reproduction of the entire speaker set.

What is special about the tweeter of the Emphaser ECP-G5 speaker?

The tweeter of the Emphaser ECP-G5 features a 25 mm textile dome that enables a warm and detailed sound even in complex musical passages. The design deliberately omits ferrofluid, making the tweeter particularly lively, spatial, and free from coloration. A protective grille with a very large opening area ensures high sound permeability and minimizes reflections. The housing design allows the tweeter to be mounted at two different radiation angles, significantly facilitating and optimizing adaptation to the specific acoustics of various vehicle interiors.

How is the installation of the Emphaser ECP-G5 in the vehicle?

The installation of the Emphaser ECP-G5 speaker set is well thought out and user-friendly due to the small installation dimensions. The installation diameter of the woofer is 116 mm with a mounting depth of 60 mm, allowing it to fit in many standard speaker openings. The included screw terminal with hexagon screws and gold-plated contact surfaces also supports a stable and secure connection of the cables. This design facilitates fitting into various vehicle models. For optimal sound distribution, the tweeter can be flexibly positioned, allowing for individual adjustments to the acoustics of the vehicle.

How does the butyl rubber surround affect the performance of the woofers?

The butyl rubber surround of the woofers in the Emphaser ECP-G5 is crucial for maintaining the mobility of the diaphragm, even at high levels. It provides the right balance between flexibility and stability, thus supporting the ability for precise sound reproduction by allowing the diaphragm to return evenly to its rest position. This also contributes to extending the lifespan of the speaker by minimizing stress cracks or deformation. The formulation of the butyl material also offers lasting resistance to environmental influences, ensuring consistent performance over many years.

What are the special features of the Crossover of the ECP-G5?

The Crossover of the Emphaser ECP-G5 is specifically designed for precise sound separation and includes high-quality components such as air coils and MKP capacitors. The crossovers are integrated into a 12 dB filter configuration for both driver types, resulting in clear and balanced sound separation. Additionally, they offer a two-step level adjustment for the Tweeter, allowing for optimization of high-frequency reproduction according to personal preference. This technological approach ensures realistic stage representation and provides the flexibility to adjust the sound without complex reconfigurations.

What frequency range does the Emphaser ECP-G5 Speaker Set cover?

The Emphaser ECP-G5 Speaker Set offers a frequency range of 85 Hz to 22 kHz, ensuring a wide sound spectrum reproduction—from deep bass to brilliant highs. This range covers most musical requirements and ensures that both low-frequency and high-frequency audio elements are reproduced accurately. The combination of a woofer that delivers powerful and precise bass and a Tweeter that provides clear and vibrant highs optimizes the sound image. This extension is ideal for listeners who demand full and uncolored music reproduction in their vehicle.

What materials are used in the ECP-G5 speaker for vibration damping?

In the ECP-G5 Speaker Set from Emphaser, various materials are used for vibration damping to maximize sound performance. The CRYSTALGRAIN compound diaphragm of the woofer combines the stiffness of paper with the damping ability of the applied quartz crystals. The aluminum die-cast chassis not only provides stability but also minimizes resonances due to its open structure. Additionally, the butyl rubber surround uses elastic properties that position the woofer with low vibrations. This choice of materials supports precise reproduction and creates a clean sound without distortion from unwanted vibrations.
