Rainbow Audio EL-W68A MK2 8" (20cm) Active Enclosure Subwoofer

Max, Mikael and 53k+ customers already with Masori sound upgrade

Rainbow Audio EL-W68A MK2 8" (20cm) Active Enclosure Subwoofer

Power 120 W, impedance 4 ohms, frequency response 20-150 Hz.
Signal-to-noise ratio over 91 dB, operating voltage 12-15V.
Input sensitivity 2-20V high, 0.2-2V low, bass +12 dB.
Mehr technische Details

€199,00

~~€199,00~~ €199,00

5% Rabatt mit Vorkasse

inkl. VAT , possibly plus shipping

Bequem in 12 zinsfreien Raten à €16,58 mit Klarna zahlen.

Jetzt mit kostenlosem Versand ab 50€!

Shipping cost calculator

Land/Region

PLZ

Garantie & zusätzlicher Geräteschutz für dein HiFi-System

3 Jahre Masori Garantie Kostenlos 48 Monate Plusgarantie €14,99 60 Monate Plusgarantie Am beliebtesten €19,99

Deshalb wählen uns 100.000+ Kunden

3 Jahre Garantie

Sicher & sorglos
Blitzversand

mit DHL Express
Tiefpreisschutz

Nie zu viel zahlen

Rob

Max

Unsicher, ob dieses Produkt zu deinem Auto passt?

Wir helfen dir – schnell, persönlich und unverbindlich.

Antwort on weekdays within 24h

Rainbow AudioEL-X165S

Rainbow AudioIL-C260 HON

EL-W68A MK2 by Rainbow Audio

The EL-W68A MK2 from Rainbow Audio is an 8-inch active enclosure subwoofer that impresses with a rated power of 120 W. It delivers high sound quality thanks to a signal-to-noise ratio of over 91 dB. With a frequency response of 20 Hz to 150 Hz, it offers a wide sound range. The operating voltage is between 12V and 15V, and the impedance is 4 ohms. The subwoofer is equipped with a high-level input sensitivity of 2 – 20V and a low-level input sensitivity of 0.2 – 2V. It also features an adjustable low-pass filter from 50 Hz to 150 Hz and bass boost from 0 to +12 dB. Its compact dimensions of Ø 360 mm x 121.5 mm make it versatile for various uses.

Technical Data

Rated power 120 W
Signal-to-noise ratio >91dB
Frequency response 20Hz – 150Hz
Operating voltage 12V-15V
Impedance 4 ohms
High-level input sensitivity 2 – 20V
Low-level input sensitivity 0.2 – 2V
Low-pass filter 50 Hz – 150 Hz
Bass boost 0 – +12 dB
Dimensions (DxH) Ø 360 mm x 121.5 mm

Rainbow Audio EL-W68A MK2 Datenblatt

Datenblatt öffnen

Frequent questions about EL-W68A MK2

Welche Nennleistung bietet der Rainbow Audio EL-W68A MK2 Aktiv-Gehäusesubwoofer und wie beeinflusst sie die Audioleistung?

The Rainbow Audio EL-W68A MK2 subwoofer has a rated power of 120 watts. This power enables powerful and precise bass reproduction, ensuring clear sound quality even at high volumes. The 120-watt power ensures that the subwoofer can efficiently amplify low frequencies without distortion. This is particularly important for drivers who desire an intense bass performance in their vehicle. Additionally, the high rated power supports stable performance across various operating conditions, highlighting the durability and reliability of the EL-W68A MK2.

Wie wirkt sich das Signal-Rausch-Verhältnis von über 91 dB auf die Klangqualität des EL-W68A MK2 aus?

The signal-to-noise ratio of over 91 dB in the Rainbow Audio EL-W68A MK2 subwoofer means that the subwoofer has very high clarity and low background noise. A high signal-to-noise ratio ensures that the desired audio signals are clearly above any interference or noise. This results in clean and uncolored bass reproduction, which is particularly advantageous for precise musical details and dynamic soundscapes. For users, this means improved sound quality and a more intense listening experience without distracting background noise.

Welche Frequenzbereiche deckt der EL-W68A MK2 Subwoofer ab und wie beeinflusst das die Klangwiedergabe?

The Rainbow Audio EL-W68A MK2 subwoofer covers a frequency range from 20 Hz to 150 Hz. This wide frequency range allows for comprehensive bass reproduction, accurately covering both low-frequency bass and mid-bass ranges. With the ability to reproduce frequencies down to 20 Hz, the subwoofer delivers deep, powerful bass that intensifies the listening experience. At the same time, the upper limit of 150 Hz ensures that the bass reproduction remains clear and seamlessly integrates into the overall audio spectrum. This results in a balanced and dynamic sound reproduction that appeals to both music lovers and audiophiles.

Welche Betriebsspannung benötigt der EL-W68A MK2 und wie wirkt sich das auf die Installation und Leistung aus?

The Rainbow Audio EL-W68A MK2 subwoofer operates with a supply voltage between 12V and 15V. This voltage range allows for flexible integration into different vehicle power systems. A supply voltage of 12V corresponds to the standard voltage in most vehicles, which simplifies installation and ensures a reliable power supply. At a higher voltage of up to 15V, the subwoofer can deliver increased performance, which is particularly advantageous in more powerful audio setups. The adaptability of the supply voltage helps ensure that the EL-W68A MK2 delivers optimal performance, regardless of the specific requirements of the vehicle's power system.

Wie kann die Eingangsempfindlichkeit des Rainbow Audio EL-W68A MK2 eingestellt werden und welche Optionen stehen zur Verfügung?

The EL-W68A MK2 from Rainbow Audio offers two options for adjusting the input sensitivity: a high level range of 2 to 20V and a low level range of 0.2 to 2V. This dual option allows for flexible adaptation to different audio sources and signal levels. In the high level range, the subwoofer is ideal for direct connections to amplifiers with higher output voltages, resulting in enhanced bass performance. The low level range, on the other hand, is suitable for sources with lower output power, such as efficient preamplifiers. With these versatile adjustment options, the EL-W68A MK2 ensures optimal integration and performance in various audio configurations.

Welche Einstellungen bietet der anpassbare Tiefpassfilter des EL-W68A MK2 und wie kann er optimal konfiguriert werden?

The Rainbow Audio EL-W68A MK2 subwoofer is equipped with an adjustable low-pass filter that can be set in the range of 50 Hz to 150 Hz. This low-pass filter allows for precise adjustment of the upper limit of the frequencies reproduced, optimizing the subwoofer for the existing audio system. By setting the low-pass filter to lower frequencies, for example, 50 Hz, the subwoofer can emphasize deeper bass, which is particularly desirable for music genres with strong bass components. Higher settings up to 150 Hz provide shorter and more precise bass reproduction that seamlessly integrates into the sound landscape. The flexible configuration of the low-pass filter ensures that the EL-W68A MK2 achieves an optimal balance between depth and clarity of bass reproduction.

Wie beeinflusst die Bassverstärkung des EL-W68A MK2 die Klangwiedergabe und welche Einstellungen sind möglich?

The Rainbow Audio EL-W68A MK2 subwoofer offers bass enhancement from 0 to +12 dB, allowing for the adjustment of bass intensity according to individual preferences. By increasing the bass enhancement, the subwoofer can produce deeper and more powerful bass, which is particularly beneficial for music styles with a strong bass component. An enhancement of up to +12 dB further emphasizes bass reproduction without compromising the clarity of sound playback. At the same time, a neutral setting for bass enhancement allows for a balanced sound reproduction that harmoniously integrates into the overall audio system. The ability to adjust the bass enhancement ensures that the EL-W68A MK2 responds flexibly to different sound preferences and audio sources.

Welche Abmessungen hat der Rainbow Audio EL-W68A MK2 und welche Installationshinweise sind zu beachten?

The Rainbow Audio EL-W68A MK2 subwoofer has compact dimensions of Ø 360 mm x 121.5 mm. These measurements make the subwoofer versatile and allow for easy integration into various vehicle types and installation elements. When installing the EL-W68A MK2, care should be taken to ensure that there is sufficient space in the intended enclosure to guarantee optimal ventilation and vibration damping. The cylindrical shape of the subwoofer allows for flexible placement, whether in the trunk, under the seats, or in custom-made enclosures. Additionally, the positioning should be chosen so that the subwoofer has unobstructed access to power supply and audio inputs to ensure a smooth installation and best performance.

Wie gewährleistet der Rainbow Audio EL-W68A MK2 eine hohe Klangqualität durch seine technischen Parameter?

The Rainbow Audio EL-W68A MK2 subwoofer offers a combination of high nominal power of 120 watts, an excellent signal-to-noise ratio of over 91 dB, and a wide frequency range of 20 Hz to 150 Hz. These technical parameters significantly contribute to the high sound quality of the subwoofer. The high nominal power enables powerful and precise bass reproduction, while the high signal-to-noise ratio ensures that the audio output remains clear and uncolored. The extensive frequency range allows for detailed and dynamic bass representation that seamlessly integrates into the overall audio system. Additionally, the adjustable low-pass filter and variable bass boost provide further options for fine-tuning the sound reproduction, making the EL-W68A MK2 an outstanding audio performer.

Welche Tipps gibt es zur Installation des EL-W68A MK2 in Bezug auf Abmessungen und Platzierung im Fahrzeug?

When installing the Rainbow Audio EL-W68A MK2 subwoofer, it is important to consider the compact dimensions of Ø 360 mm x 121.5 mm. Due to these dimensions, flexible placement in the vehicle is possible, for example in the trunk, under the seats, or in specially made enclosures. Ensure that there is enough space for ventilation to allow optimal heat dissipation and to avoid overheating of the subwoofer. The cylindrical shape facilitates integration into various installation areas, while the low height allows for discreet mounting. Additionally, the subwoofer should be mounted in a stable position to minimize vibrations and ensure consistent sound quality. Also, make sure that the connections are easily accessible to allow for simple wiring and adjustment of settings.

Welche technischen Merkmale des EL-W68A MK2 tragen zur hohen Klangqualität in Fahrzeugen bei?

The Rainbow Audio EL-W68A MK2 subwoofer integrates several technical features that together ensure high sound quality in vehicles. Key features include a rated power of 120 watts, which allows for a powerful bass signal, and a signal-to-noise ratio of over 91 dB, which ensures clear and uncolored audio playback. The wide frequency response of 20 Hz to 150 Hz covers a comprehensive bass spectrum, while the adjustable low-pass filter from 50 Hz to 150 Hz allows for precise tuning of bass frequencies. The variable bass boost from 0 to +12 dB enables fine-tuning of bass intensity according to personal preferences. Additionally, the stable impedance of 4 ohms and flexible input sensitivities ensure seamless integration into various vehicle audio systems, contributing to an overall outstanding sound quality.

Wie lässt sich der EL-W68A MK2 in verschiedene Audio-Systeme integrieren unter Berücksichtigung der technischen Daten?

The Rainbow Audio EL-W68A MK2 subwoofer can be easily integrated into various audio systems thanks to its technical specifications. With an impedance of 4 ohms, the subwoofer is compatible with most common amplifiers, allowing for simple wiring. The two options for input sensitivity, 2 – 20V for high levels and 0.2 - 2V for low levels, provide flexibility in adapting to different audio sources. The adjustable low-pass filter from 50 Hz to 150 Hz allows for precise tuning of bass reproduction, while the bass boost from 0 to +12 dB offers additional customization options. The operating voltage of 12V-15V ensures that the subwoofer can be easily operated in most vehicle power systems. Additionally, the compact dimensions allow for flexible placement in the vehicle, further facilitating integration into various audio setups.
