30 Zellen LTO prismatisch Batteriepack 100Ah

30 Zellen LTO prismatisch Batteriepack 100Ah

Technical Highlights

  • Power up to 10000W RMS, impedance under 0.5 mOhm, capacity 100Ah.
  • Max. charging current 100A, max. discharging current 400A, voltage 14.4-15V.
  • Rated charge 40A, prismatic cells, voltage range 10.2-16.2V.
  • More technical details
€1,899.00
€1,899.00 €1,899.00
2% discount with credit card

Your price match offer

Product30 Zellen LTO prismatisch Batteriepack 100Ah · Lang

Reply within 1–3 working days · Mon–Fri. Outside the EU, we are happy to review an individual offer.

Privacy

This website is protected by hCaptcha. The privacy policy and terms of service of hCaptcha apply.
including VAT
Execution: Lang
Estimated delivery: Oct 6–Oct 13.
x set
  • American Express
  • Apple Pay
  • Bancontact
  • BLIK
  • EPS
  • Google Pay
  • iDEAL Wero
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Shop Pay
  • Twint
  • Union Pay
  • Visa

Delivery & availability

The selected variant is not currently in stock at Masori and is sourced from the supplier. Refer to the estimated delivery window above.

Orders ship together based on the item with the longest lead time. If you need something sooner, ask by email about a possible partial shipment beforehand.

Shipping costs and options depend on the destination. Check the shipping calculator; final costs are shown before placing the order.

Email us the product, car, existing system and budget. We will offer an alternative available sooner.

Ask for an alternative available sooner

Reply in 1–3 working days · Mon–Fri

1 year extra warranty

Every product purchased from Masori includes an additional year of warranty in the third year after purchase (months 25–36). We cover repair or replacement free of charge for covered warranty claims. Automatic and free – exclusively for Masori customers. Your statutory rights remain unaffected.

Warranty terms
GS AudioCrystal Series GS-2300.1 LED
GS Audio-Crystal Series GS-2300.1 LED-1-Kanal Verstärker-masori-kaufen
GS Audio-Gold 10000 15 Zoll (B-Ware)-15" (38cm) Subwoofer-masori-kaufen
GS AudioGold 10000 15 Zoll (B-Ware)
GS Audio-30 Zellen LTO prismatisch Batteriepack 100Ah-Lithium - LTO-masori-kaufen
€1,899.00
€1,899.00 €1,899.00

The 30 cell LTO prismatic battery pack 100Ah from GS Audio is based on Lithium - LTO technology. It consists of 30 prismatic individual cells of model GS - 20 LTO and has a total capacity of 100Ah. The recommended operating voltage is between 14.4V and 15V. The system is designed for power ranges from 8500W RMS to 10000W RMS. The design is compact and is available in both a long and a square dimension variant. The maximum discharge current is 400A with an internal resistance of less than 0.5 mOhm.

Features
  • Product type: Lithium - LTO
  • Manufacturer: GS Audio
  • Battery pack consisting of 30 prismatic cells
  • Capacity: 100Ah
  • Power: 8500-10000W RMS
  • Dimensions Long: 120x6750x110mm
  • Dimensions Square: 370x230x110mm
  • Internal resistance: <0.5 mOhm
Technical Data
  • Recommended voltage: 14.4-15V
  • Maximum voltage: 16.2V
  • Minimum voltage: 10.2V
  • Maximum discharge current: 400A (20C)
  • Nominal discharge current per cell: 40A
  • Maximum charge current per cell: 100 A
  • Nominal voltage per cell: 2.4 Volts
  • Weight per cell: 0.520 kg
  • Volume per cell: 0.26 l
  • Connection thread: M5
  • Optimal operating temperature: -25/+55 °C
  • Maximum operating temperature: -30/+70 °C
  • Charging method: Constant current and voltage

Frequently Asked Questions about 30 Zellen LTO prismatisch Batteriepack 100Ah

What are the dimensions of the 30-cell LTO prismatic Battery pack 100Ah?

The 30-cell LTO prismatic Battery pack 100Ah from GS Audio offers two different form factors. The elongated form factor measures 120x6750x110mm. This form factor is particularly suitable for slimmer installation areas and allows for an elongated distribution of the cells in the space. The square form factor, on the other hand, measures 370x230x110mm. Both form factors provide flexibility in installation, depending on the available space in the vehicle interior. The square format is preferred when square or rectangular area capacities are to be utilized, especially when space-saving on the sides is required. According to these dimensions, precise planning is recommended for optimal utilization of capacity and available space.

What is the capacity and recommended voltage of the 30-cell LTO Battery pack?

The GS Audio 30-cell LTO prismatic Battery pack has a capacity of 100Ah. This high capacity makes the Battery pack ideal for power-intensive applications, such as in sound systems operating between 8500 and 10000 Watts RMS. The recommended voltage for this Battery pack is between 14.4 and 15 Volts. This voltage setting ensures that you get the maximum efficiency and lifespan from your Battery pack by keeping the energy flow at a stable level. The range of these voltage values offers flexibility for different usage scenarios and charging conditions.

What voltage and current are important for the individual cell GS-20 LTO?

The GS-20 LTO individual cell in the Battery pack has a nominal voltage of 2.4 Volts. This voltage is essential to ensure the proper operation of the cell in various applications. The nominal charging current is 40 Amperes, while the maximum charging current reaches 100 Amperes. The nominal discharging current is also rated at 40 Amperes, but the cell can handle short-term discharge currents of up to 400 Amperes, which corresponds to its strong resilience. These performance characteristics are particularly important for applications that require fast charging or discharging cycles to manage peak loads without stressing the cell.

What are the temperature ranges for the optimal operation of the LTO cells?

The optimal operating temperature range for the LTO cells of the GS Audio 30 cells Battery Pack is between -25°C and +55°C. Maintaining this range is crucial to ensure maximum performance and longevity of the cells, as extreme temperatures can affect the chemical processes within the cell. However, the cells are designed to withstand an extended temperature range of -30°C to +70°C. Particularly important is the insulation of the battery cells to minimize heat loss and remain stable, enabling smooth operation even in cold or hot environments.

What is the maximum discharge current of the 30 cells LTO prismatic Battery Pack 100Ah?

The 30 cells LTO prismatic Battery Pack from GS Audio is designed for extremely high loads. The maximum discharge current of each individual cell is 400A, which corresponds to the 20C rating. This indicates that the Battery Pack is suitable for high-performance applications that require rapid discharging, such as intensive audio setups. With such high currents, you can effectively handle load peaks without performance losses. The internal resistance of less than 0.5 milliohm also supports this function by ensuring minimal energy loss during discharging. However, it is advisable to integrate discharge limiting through efficient thermal management systems into the overall concept.

What is the weight of the individual cell of the 30 cells LTO Battery Pack?

A single GS-20 LTO cell, from which the 30 cells LTO prismatic Battery Pack is made, weighs 520 grams. Each cell illustrates that the total weight of the entire Battery Pack should not be underestimated, and appropriate considerations should be taken into account during the installation assessment. The volume of an individual cell is 0.26 liters, which is particularly beneficial when planning the installation and considering weight distribution in the vehicle. This moderate weight of the individual cell supports flexibility in the design of compact battery pack configurations, which could be advantageous for developers of mobile devices.

What charging methods does the 30 cells LTO prismatic Battery Pack support?

The charging methods for the 30 cells LTO prismatic Battery Pack from GS Audio include constant current and constant voltage charging. These methods ensure that the cells are charged evenly and efficiently, maximizing lifespan and ensuring stable performance outputs. In the constant current method, a constant current is supplied until a certain voltage is reached. After that, charging switches to constant voltage, where the voltage is maintained while the current is gradually reduced. This charging characteristic significantly reduces the risk of overcharging and overheating and is particularly important for increasing efficiency during different charging cycles.

Which connection is used for the 30-cell LTO prismatic Battery pack?

For the 30-cell LTO prismatic Battery pack from GS Audio, M5 type threaded connections are used. This is a crucial aspect for ensuring stable connections in the electrical system, as the thread size offers compatibility with a wide range of cable connections. The choice of M5 threaded connections affects resistance to mechanical stress and is helpful in maintaining good connections, especially in assembly variants away from production or in the tuning area. The processing and quality of the threads are important to achieve reliable electrical performance and trouble-free long-term stability even under vibrations or external influences.

How does the power density of the cells in the 30-cell LTO Battery pack behave?

The power density of the cells in the 30-cell LTO prismatic Battery pack from GS Audio is particularly evident in supporting high current applications and maximum discharge tolerance. With a maximum discharge current of 400A and an internal resistance of less than 0.5 milliohm, the architecture of the cells allows for highly energetic output with minimal losses. Here, the prismatic structure of the cells provides an orderly and uniform power output, ensuring that energy performance is maintained even during peak applications when dealing with high loads. This aspect is essential in energy-intensive applications such as mobile electric storage.

What voltage values can the 30-cell LTO Battery pack be charged to?

The GS Audio 30-cell LTO prismatic Battery pack is designed to operate within a voltage range of 10.2 to a maximum of 16.2 volts. It is important to note that charging with a maximum voltage of 16.2 volts utilizes the battery's limits, so this should only be done under controlled conditions to ensure longevity. With the correct voltage range, energy efficiency is optimal, and potential overcharging issues are avoided. This voltage adjustment also enables application in vehicles with various electrical load requirements, which operate, for example, in high-end sound systems.
