24 Zellen LTO prismatisch Batteriepack 80Ah

24 Zellen LTO prismatisch Batteriepack 80Ah

Technical Highlights

  • Impedance less than 0.5 mOhm, suitable for 7000-8000W RMS.
  • Capacity: 80Ah, max. charging current 100 A, ideal for high loads.
  • Voltage: Nominal voltage 2.4V, max. voltage 16.2V, temperature range -30/+70 °C.
  • More technical details
€1,499.00
€1,499.00 €1,499.00
2% discount with credit card
including VAT
Execution: Lang
Estimated delivery: Oct 2–Oct 9.
x set
  • American Express
  • Apple Pay
  • Bancontact
  • BLIK
  • EPS
  • Google Pay
  • iDEAL Wero
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Shop Pay
  • Twint
  • Union Pay
  • Visa
GS Audio18 Zellen LTO Extreme Batteriepack 135Ah
GS Audio-18 Zellen LTO Extreme Batteriepack 135Ah-Lithium - LTO-masori-kaufen
GS Audio-12 Zellen LTO prismatisch Batteriepack 40Ah-Lithium - LTO-masori-kaufen
GS Audio12 Zellen LTO prismatisch Batteriepack 40Ah
GS Audio-24 Zellen LTO prismatisch Batteriepack 80Ah-Lithium - LTO-masori-kaufen
€1,499.00
€1,499.00 €1,499.00

The 24 cell LTO prismatic battery pack 80Ah from GS Audio is a Lithium - LTO battery pack. It consists of 24 prismatic cells of model GS - 20 LTO and has a capacity of 80Ah. The recommended operating voltage is set in a range of 14.4 to 15 volts. The system is designed for applications of 7000 to 8000W RMS. Two different housing dimensions are available in a long and a narrow variant. The internal resistance of the individual cells is below 0.5 mOhm.

Features
  • Lithium - LTO
  • Consisting of 24 prismatic cells
  • Model GS - 20 LTO
  • Capacity: 80Ah
  • 7000-8000W RMS
  • Dimensions Long: 90x690x110mm
  • Dimensions Narrow: 120x540x110mm
  • Internal resistance: less than 0.5 mOhm
Technical Data
  • Nominal voltage per cell: 2.4 volts
  • Dimensions per cell: 108 x 116 x 22 mm
  • Weight per cell: 0.520 kg
  • Volume per cell: 0.26 l
  • Nominal charge current: 40 A
  • Nominal discharge current: 40 A
  • Maximum charge current: 100 A
  • Maximum discharge current: 400A (20C)
  • Connection thread: M5
  • Optimal operating temperature: -25 to +55 °C
  • Maximum operating temperature: -30 to +70 °C
  • Charging method: Constant current and voltage
  • Maximum voltage: 16.2 V
  • Minimum voltage: 10.2 V
  • Recommended voltage: 14.4-15 V

Frequently Asked Questions about 24 Zellen LTO prismatisch Batteriepack 80Ah

What is the capacity of the 24-cell LTO prismatic battery pack 80Ah from GS Audio?

The 24-cell LTO prismatic battery pack 80Ah from GS Audio has a capacity of 80 Ah. This capacity allows it to support versatile applications, particularly in the field of high-performance devices and mission-critical applications that require stable energy management. The high capacity, combined with the robust construction of the prismatic cells, ensures efficient energy supply during peak loads, making the battery pack an ideal solution for continuous operation in demanding environments. Whether in the audio sector with power-intensive amplifiers or in electromobility – the storage capacity remains a key feature for application diversity.

What voltage does GS Audio recommend for the 24-cell LTO prismatic battery pack 80Ah?

GS Audio recommends an operating voltage of 14.4 to 15 volts for the 24-cell LTO prismatic battery pack 80Ah. These voltage values ensure that the battery pack operates optimally within the parameters specified by the manufacturer, contributing to both the longevity of the cells and safe operation. Consistent adherence to the recommended voltage is essential for minimizing losses and maximizing power output. When used in high-performance applications such as audio amplifiers or in hybrid energy systems, the voltage range ensures reliable and continuous energy delivery without overloading the cells.

What is the load capacity of the 24-cell LTO prismatic battery pack 80Ah at RMS power?

The 24-cell LTO prismatic battery pack 80Ah is designed for applications with RMS power between 7000 and 8000 watts. This impressive load capacity makes it an excellent choice for high-performance applications that demand continuous and stable energy supply. Particularly in the field of professional audio equipment, where powerful amplifiers are used, the battery pack can deliver its full performance without compromise. The ability to support such high RMS values results from the combination of 24 prismatic cells, which enable consistent current delivery and thermal stability even under extreme conditions.

What are the dimensions of the 24-cell LTO prismatic battery pack 80Ah?

The 24-cell LTO prismatic battery pack 80Ah from GS Audio is available in two different form factors: The Long version measures 90x690x110 mm, while the Slim version measures 120x540x110 mm. These dimensions take into account the versatile installation needs in a variety of application scenarios, including tight spaces in vehicles or specific integrations in energy systems. The differences in length and width of the two versions provide flexible solutions for specific space requirements, while the height of 110 mm remains consistent in both cases to allow for uniform handling and mounting.

Which car brands is the 24-cell LTO prismatic battery pack 80Ah compatible with?

The 24-cell LTO prismatic battery pack 80Ah from GS Audio is designed for a wide range of vehicles. Due to its two size options – Long version with 90x690x110 mm and Slim version with 120x540x110 mm – it fits into various vehicle models regardless of the car brand. When installing, it is important to consider the available space in the engine compartment or specifically designated battery compartments to ensure safe and effective integration. If specific adjustments are necessary, these can be made, depending on the vehicle, with standard mounting systems.

What technical specifications are relevant for the individual cells of the 24-cell LTO prismatic battery pack 80Ah?

The individual cells with the model GS - 20 LTO have specific technical specifications: The dimensions are 108 x 116 x 22 mm with a weight of 0.520 kg and a volume of 0.26 l. With a nominal voltage of 2.4 volts and a nominal charge current as well as nominal discharge current of 40 A, the cells offer maximum load capacity. The maximum charge current is 100 A, while the maximum discharge current reaches 20C or 400 A. Additionally, the cells are equipped with a connection thread in M5 and an internal resistance of less than 0.5 mOhm, which together ensure optimal current distribution.

What are the optimal operating conditions for the 24-cell LTO prismatic battery pack 80Ah?

For optimal performance, the 24-cell LTO prismatic battery pack 80Ah is designed for temperatures ranging from -25 to +55 °C. This temperature range ensures the stability and reliability of the prismatic cells in both common and extreme environmental conditions. In applications where temperatures reach the maximum operational limit of -30 to +70 °C, the battery pack remains functional. Adhering to these operating temperatures is crucial to avoid efficiency losses and ensure long-term functionality, especially under challenging operating conditions.

What charging method is recommended for the 24-cell LTO prismatic battery pack 80Ah?

For the 24-cell LTO prismatic battery pack 80Ah, the constant current and constant voltage charging method is recommended. This charging method ensures that the individual cells of the battery pack are charged evenly, preventing uneven wear and overload. Monitoring current and voltage values during the charging process is essential for ensuring safety and extending the lifespan of the cells. In high-quality charging environments, this method optimizes efficiency and charging behavior, which is particularly important for high-performance applications.

What is the maximum discharge current of the cells in the 24-cell LTO prismatic battery pack 80Ah?

The maximum discharge current for the individual cells in the 24-cell LTO prismatic battery pack 80Ah is 20C, which corresponds to 400A. This outstanding discharge capacity makes the cells ideal for applications that require high current levels in a short time, such as in the automotive sector or in high-power electronic devices. With such a high discharge current, the cells can handle abrupt loads without damage, which is essential for preventing voltage drops and promoting smooth operation at full power.

Is the 24-cell LTO prismatic battery pack 80Ah operational at variable temperatures?

Yes, the 24-cell LTO prismatic battery pack 80Ah is suitable for operation in a variety of temperature conditions. The prismatic cells are designed to function optimally in a temperature range of -25 to +55 °C and can even withstand temperatures from -30 to +70 °C in extreme cases. This temperature tolerance ensures functionality in both cooler and warmer regions and systems, such as vehicles, including electric vehicles in different climates. This flexibility is crucial for reliable use in mobile and stationary energy systems.
