Rage H1 NEO

100 Watt

Rage H1 NEO

Technical Highlights

  • 100 W power handling, 104 dB sensitivity, 2-20 kHz frequency.
  • 4 Ω impedance, 3.4 Ω Re, 1" voice coil, 3.5 kHz threshold.
  • Optimized membranes, higher SPL output, more intense sound.
  • More technical details
€99.00
€99.00 €99.00
2% discount with credit card

Your price match offer

ProductRage H1 NEO

Reply within 1–3 working days · Mon–Fri. Outside the EU, we are happy to review an individual offer.

Privacy

This website is protected by hCaptcha. The privacy policy and terms of service of hCaptcha apply.
including VAT
Estimated delivery: Sep 18–Sep 24.
x pair
  • American Express
  • Apple Pay
  • Bancontact
  • BLIK
  • EPS
  • Google Pay
  • iDEAL Wero
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Shop Pay
  • Twint
  • Union Pay
  • Visa

Delivery & availability

The selected variant is not currently in stock at Masori and is sourced from the supplier. Refer to the estimated delivery window above.

Orders ship together based on the item with the longest lead time. If you need something sooner, ask by email about a possible partial shipment beforehand.

Shipping costs and options depend on the destination. Check the shipping calculator; final costs are shown before placing the order.

Email us the product, car, existing system and budget. We will offer an alternative available sooner.

Ask for an alternative available sooner

Reply in 1–3 working days · Mon–Fri

1 year extra warranty

Every product purchased from Masori includes an additional year of warranty in the third year after purchase (months 25–36). We cover repair or replacement free of charge for covered warranty claims. Automatic and free – exclusively for Masori customers. Your statutory rights remain unaffected.

Warranty terms
B2 Audio-Rage H1 NEO-Horn-Hochtöner-masori-kaufen
€99.00
€99.00 €99.00

Discover the Rage H1 NEO, an innovative horn tweeter from B2 Audio, known for its exceptional performance. This speaker stands out with improved sound quality and an extended frequency response, delivering an intense audio experience. Featuring optimized diaphragms and a higher SPL output, the Rage H1 NEO offers a listening experience that will delight any audiophile with its clear and balanced sound. Sharper and better than ever before – let the impressive features of the Rage H1 NEO convince you.

Specification

  • Frequency response: 2KHz ~ 20 KHz
  • Power handling: 100 w (200 w*)
  • Sensitivity: 104 dB
  • Nominal impedance: 4 Ω
  • DC resistance (Re): 3.4 Ω
  • Recommended crossover: 3.5 KHz / 12 dB min
  • Voice coil 1″

Frequently Asked Questions about Rage H1 NEO

Welche Frequenzgänge deckt der Rage H1 NEO ab?

The Rage H1 NEO from B2 Audio covers a frequency range of 2 kHz to 20 kHz, which means it is capable of accurately reproducing both mid and high frequencies. This is particularly important for sound purists who value a detailed and clear reproduction of musical pieces. The extension of the frequency response ensures that nuances in music playback are not lost, thus providing a comprehensive listening experience.

Wie hoch ist die Belastbarkeit des Rage H1 NEO Lautsprechers?

The Rage H1 NEO tweeter is designed for a nominal power handling of 100 watts, with the ability to handle up to 200 watts for short periods. This high power handling allows you to use the tweeter in setups with more powerful amplifiers without the risk of overload. This way, you can fully utilize your audio system while benefiting from the extraordinary sound quality of the speaker.

Wie hoch ist die Empfindlichkeit des Rage H1 NEO?

The sensitivity of the Rage H1 NEO tweeter is 104 dB. This high sensitivity means that the speaker can achieve a high volume even with low amplifier power. Especially if you enjoy listening to music at high volumes, the high sensitivity offers a clear advantage, as it delivers a powerful sound image with vibrant highs without putting extreme strain on the amplifier.

Was sind die technischen Vorteile der 1-Zoll-Schwingspule im Rage H1 NEO?

The 1-inch voice coil in the Rage H1 NEO enables precise movement of the optimized diaphragm, resulting in clear and detailed sound. The size of the voice coil plays a crucial role in controlling diaphragm movement and heat dissipation, which increases the lifespan of the speaker. Combined with a nominal impedance of 4 Ω and a resistance of 3.4 Ω, the voice coil offers excellent efficiency and outstanding sound fidelity, ideal for demanding audio applications.

Welche Impedanz hat der Rage H1 NEO Lautsprecher?

The Rage H1 NEO tweeter has a nominal impedance of 4 Ω and a DC resistance of 3.4 Ω. These values are crucial for compatibility with most amplifiers, as amplifiers can deliver optimal power output at 4 Ω. This tuning ensures smooth operation and that the speakers harmonize with a wide range of audio systems without any loss of performance.

Welcher Frequenzgrenzwert wird für den Rage H1 NEO empfohlen?

For the Rage H1 NEO, a frequency cutoff of 3.5 kHz at 12 dB is recommended as part of the filter design. This specification is intended to optimize the crossover frequency in two- or three-way systems to ensure the best sound quality. By using the tweeter only from this frequency, distortion in the boundary areas is avoided, resulting in a harmonious sound transition. So make sure your setup takes this value into account to fully exploit its potential.

Warum ist der SPL-Output beim Rage H1 NEO so wichtig?

The high SPL output of the Rage H1 NEO, combined with a sensitivity of 104 dB, ensures that the tweeter can achieve enormous sound pressure levels even with low input power. This is particularly advantageous for mobile applications where amplifier power may be limited. The SPL output helps ensure that the speaker can be heard at large events or outdoors without loss of quality. It is a crucial factor for anyone who values a powerful and assertive audio system.

Welche Aspekte des Rage H1 NEO tragen zur verbesserten Klangqualität bei?

The improved sound quality of the Rage H1 NEO results from the optimized membranes that produce a clear and balanced sound. The combination of precisely tuned voice coil and membrane ensures a precise frequency response, while the high sensitivity allows for loud and clear playback. These technical features guarantee excellent sound fidelity, ideal for discerning music lovers who value every detail. This way, you can fully enjoy an audiophile experience.

Welche Installationshinweise gibt es für den Rage H1 NEO?

When installing the Rage H1 NEO, it is important to consider the recommended cutoff frequency of 3.5 kHz / 12 dB to avoid distortion. Also pay attention to the correct positioning in the vehicle to achieve the best sound quality. The compact design of the voice coil facilitates integration into existing audio systems. Make sure that the speaker is housed in a stable mount. Regardless of the car brand, you should ensure that the installation optimizes the sound direction to provide a comprehensive sound panorama.

Ist der Rage H1 NEO kompatibel mit verschiedenen Automodellen?

Since the Rage H1 NEO has universal dimensions, it is versatile and compatible with most car models, even if no specific brand is mentioned. The compact design and 4 Ω impedance allow the tweeter to be easily integrated into various audio applications in the car. It is advisable to pay attention to space and mounting before installation to fully exploit the sound potential and ensure that it fits perfectly into the existing audio system.
