B2 Audio Rage 8P V5 8" (20cm) Mid-Woofer
SKU:  RAGE8PV5-PAAR

2 Reviews

300 Watt

Rage 8P V5

SKU:  RAGE8PV5-PAAR

2 Reviews

Technical Highlights

  • 600 Watt Max, 99.7 dB sensitivity, 87 Hz 10 kHz frequency.
  • Neo/ferrite magnet, UV-treated paper cone, 4 ohms.
  • Double U-shaped fabric border, stable construction.
  • More technical details
€219,00
€219,00 €219,00
5% discount with credit card
inkl. VAT , possibly plus shipping
Only a few left in stock (2 pieces available)
In stock
Jun 5, - Jun 6,
x pair
  • American Express
  • Apple Pay
  • Bancontact
  • BLIK
  • EPS
  • Google Pay
  • iDEAL Wero
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Shop Pay
  • Twint
  • Union Pay
  • Visa
Klarna Pay conveniently in 12 interest-free installments at €18,25 with Klarna .

Your benefits at Masori

Seen cheaper elsewhere?

Shipping cost calculator

Expert Image

Rob

Expert Image

Max

Unsure if this product fits your car?

We help you – quickly, personally, and without obligation.

Response on weekdays within 24 hours
B2 AudioHN 10PG
The B2 Audio HN 10PG is a round black Lautsprechergitter for 10 Zoll Tiefmitteltöner, with mesh cover, separate frame, and a small red and white B2 Audio sticker on the mesh.
B2 Audio-Rage XL 15 V2 CARBON-15" (38cm) Subwoofer-masori-kaufen
B2 AudioRage XL 15 V2 CARBON
B2 Audio-Rage 8P V5-8" (20cm) Tiefmitteltöner-masori-kaufen
€219,00
€219,00 €219,00

Rage 8P V5 by B2 Audio

The Rage 8P V5 from B2 Audio is an 8-inch (20 cm) mid-bass driver with a sensitivity of 99.7 dB and an impedance of 4 Ohm. The frequency response ranges from 87 Hz to 10 kHz, with a resonance frequency of 87 Hz. A Neo-/Ferrite magnet and a UV-treated paper diaphragm form the drive unit, complemented by a double U-shaped fabric surround. The voice coil measures 2.4 inches (61.1 mm). The overall diameter is 211 mm, the mounting depth is 77.5 mm, the bolt circle diameter is 190 mm, and the diameter of the bass cutout is 181 mm. The overall depth is 85 mm, and the net weight per piece is 3.41 kg.

Features
  • 8 inches (20 cm) mid-bass driver
  • Maximum power 600 Watts
  • Effective power 300 Watts
  • Impedance 4 Ohm
  • Sensitivity 99.7 dB
  • Frequency response 87 Hz–10 kHz
  • Voice coil diameter 2.4 inches (61.1 mm)
  • Magnet type Neo-/Ferrite magnet
  • Diaphragm material UV-treated paper
  • Surround type double U-shaped fabric
  • Overall diameter 211 mm
  • Mounting depth 77.5 mm
  • Bolt circle diameter 190 mm
  • Diameter of the bass cutout 181 mm
  • Overall depth 85 mm
  • Net weight 1 piece 3.41 kg
Technical specifications
  • Resonance frequency 87 Hz
  • VAS 14.69 L
  • RE 3.3 Ohm
  • Qms 11.025
  • Qes 0.256
  • Qts 0.251
  • BL 10.79 T/m
  • MMS 16.4 g
  • Xmax 5 mm
  • SD 226 cm²
  • Nominal diameter 211 mm
  • Magnet weight 1545 g

Your benefits at Masori

B2 Audio Rage 8P V5 Datasheet

Open datasheet

Frequently Asked Questions about Rage 8P V5

What performance features does the Rage 8P V5 offer?

The Rage 8P V5 from B2 Audio is an 8-inch mid-bass driver that impresses with a maximum power of 600 watts. Its effective power is 300 watts at an impedance of 4 ohms. Notably, it has a high sensitivity of 99.7 dB. These technical features enable powerful and clear sound reproduction, ideal for music lovers who value high power reserves. The neo/ferrite magnet ensures stable and precise reproduction across the entire intended frequency spectrum.

What is the frequency response of the B2 Audio Rage 8P V5?

The frequency response of the B2 Audio Rage 8P V5 ranges from 87 Hz to 10 kHz. This bandwidth allows for a wide sound spectrum, covering low to mid frequencies. The mid-bass driver is particularly suitable for reproducing both bass tones and mid frequencies. The resonance frequency of 87 Hz supports a natural sound character. These features make the Rage 8P V5 an ideal solution for sound setups that require both depth and clarity.

What technical characteristics does the membrane of the Rage 8P V5 have?

The membrane of the Rage 8P V5 is made of UV-treated paper, which is durable and resistant to environmental influences. A double U-shaped fabric surrounds the membrane and provides additional stability, which is essential at high volumes. This construction minimizes deformation and allows for more precise sound reproduction. The combined use of UV-treated paper and double U-shaped fabric is a mature concept to achieve both durability and acoustic clarity.

What are the dimensions of the Rage 8P V5 and how does this affect installation?

The Rage 8P V5 has an overall diameter of 211 mm with a mounting depth of 77.5 mm. The bolt circle diameter is 190 mm and the bass cutout measures 181 mm. These specifications make it suitable for a variety of speaker enclosures, provided that the mounting depth is taken into account. The precise fit allows for easy installation in most vehicle setups without requiring major modifications. These dimensions are crucial for mounting and smooth operation in the desired area.

What role does the Neo/Ferrite magnet play in the Rage 8P V5?

The Rage 8P V5 uses a Neo/Ferrite magnet specified at a weight of 54.5 ounces. This combination of neodymium and ferrite magnets provides an optimal balance of weight and magnetic strength, ensuring powerful and efficient operation. The magnet significantly contributes to the high sensitivity of the speaker and enables dynamic sound reproduction. The use of such a hybrid magnet is critical for performance and positively influences energy efficiency, especially during intense use.

What does the impedance of 4 ohms mean for the Rage 8P V5?

The Rage 8P V5 has an impedance of 4 ohms, making it ideal for use in various audio amplifier systems. A 4-ohm impedance means that the speaker tends to draw more power from the amplifier, resulting in higher volume. This value is standardized for many car audio and home audio systems, facilitating compatibility. The low-impedance characteristic allows for more efficient power usage and increases output performance, especially in high-powered audio systems.

How does a sensitivity of 99.7 dB affect sound quality?

A sensitivity of 99.7 dB in the Rage 8P V5 means that the speaker efficiently generates volume from the supplied power. The higher the sensitivity, the less power is needed to achieve high volume, which is particularly advantageous in environments with low amplifier power. This high sensitivity supports clear and robust sound waves, even at low input power levels. It provides the user with an advantage in dynamic situations where authentic and detailed sound reproduction is desired.

What Thiele-Small parameters does the Rage 8P V5 have and what do they indicate?

The Thiele-Small parameters of the Rage 8P V5 include an FS of 87 Hz, VAS of 14.69 liters, RE of 3.3 Ohms, and Qms of 11.025. The Qes is 0.256 and the Qts is 0.251, while the motion factor BL is specified as 10.79 T/M. These parameters describe the performance of the speaker in a defined enclosure. They assist in the planning and optimization of speaker designs by modeling the behavior of the speaker to maximize its efficiency and sound quality in various applications.

What materials and designs are unique to the B2 Audio Rage 8P V5?

The B2 Audio Rage 8P V5 is characterized by its exceptional design, which includes a UV-treated paper diaphragm. The material ensures durability and acoustic precision. The double U-shaped fabric surround provides additional stiffness and control over diaphragm movement, especially at high volumes. Together with the neo/ferrite magnet, it results in an innovative combination that makes the speaker ideal for demanding audio projects. These specific design and material choices significantly contribute to the sound quality and longevity of the speaker.

Is the Rage 8P V5 compatible with common car brands?

The Rage 8P V5 has detailed dimensions that allow for adaptation to various car systems. With a mounting depth of 77.5 mm and an overall diameter of 211 mm, it fits easily into most car speaker installation spaces. However, since no specific car brand is mentioned in the description, compatibility depends on the individual vehicle model and installation situation. Therefore, it is advisable to check the vehicle's installation options to achieve an optimal fit and sound quality.
