Hertz HMS 10 S4-LD-G.1 10" (25cm) Subwoofer

1 Review

300 Watt

HMS 10 S4-LD-G.1

1 Review

Technical Highlights

  • Power handling 300 W RMS, 600 W peak, impressive performance.
  • Impedance 4.5 ohms, ensures optimal sound and bass.
  • Voice coil Ø 50 mm, UV-resistant polypropylene cone.
  • More technical details
€359,00
€359,00 €359,00
5% discount with prepayment
inkl. VAT , possibly plus shipping
Delivery
Apr 18, - Apr 21,
x Piece
  • American Express
  • Apple Pay
  • Bancontact
  • BLIK
  • EPS
  • Google Pay
  • iDEAL Wero
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Shop Pay
  • Twint
  • Union Pay
  • Visa
Klarna Pay conveniently in 12 interest-free installments at €29,91 with Klarna .

Your benefits at Masori

Seen cheaper elsewhere?

Shipping cost calculator

Expert Image

Rob

Expert Image

Max

Unsure if this product fits your car?

We help you – quickly, personally, and without obligation.

Response on weekdays within 24 hours
Audio SystemR 10 FA Evo
Audio System-R 10 FA Evo-10" (25cm) Subwoofer-masori-kaufen
The Deaf Bonce Apocalypse DB-SA2510 is a black 25 cm subwoofer with green accents, 1000 W RMS, wiring terminals, and a detailed outer casing.
Deaf BonceApocalypse DB-SA2510
Hertz-HMS 10 S4-LD-G.1-10" (25cm) Subwoofer-masori-kaufen
€359,00
€359,00 €359,00

HMS 10 S4-LD-G.1 by Hertz

The HMS 10 S4-LD-G.1 from Hertz is a 10-inch Subwoofer with a nominal power handling of 300 Watts RMS and a peak power handling of 600 Watts Peak. The model features a polypropylene diaphragm with UV inhibitors and a sporty Grille with integrated LED lighting. The construction is optimized for marine use as well as Free Air operation, so no special enclosure is required. The Subwoofer has a 50 mm voice coil and a magnet system made of high-density flux ferrite. The physical specifications include a mounting depth of 116 mm and a total weight of 5.1 kg. The design allows for free color customization of the removable Grille through painting.

Features
  • 10-inch (25 cm) Subwoofer
  • Power: 300 Watts RMS
  • Power: 600 Watts Peak
  • Polypropylene diaphragm with UV inhibitors
  • Integrated LED lighting in the Grille
  • Optimized for Free Air operation
  • Removable and paintable sporty Grille
  • Magnet made of high-density flux ferrite
  • Voice coil with a diameter of 50 mm
  • Xmech: ±19 mm
  • Weight: 5.1 kg
Technical Specifications
  • Mounting depth: 116 mm
  • Total diameter (A): 280 mm
  • Mounting diameter (B): 227 mm
  • Magnet diameter (C): 164 mm
  • Total height (F): 48 mm
  • Magnet size: 140 x 60 x 30 mm
  • Impedance (Re): 4.5 Ohm
  • Resonance frequency (Fs): 41 Hz
  • Vas: 37 liters
  • Xmax: 13.5 mm
  • Qts: 0.71
  • Spl: 88 dB
  • Mms: 69 g
  • Cms: 0.22 mm/N
  • BL: 10.2 T*m
  • Le: 0.9 mH

Your benefits at Masori

Hertz HMS 10 S4-LD-G.1 Datasheet

Open datasheet

Frequently Asked Questions about HMS 10 S4-LD-G.1

What bass performance does the HMS 10 S4-LD-G.1 Subwoofer from Hertz deliver?

The HMS 10 S4-LD-G.1 Subwoofer from Hertz offers impressive bass performance thanks to its 300 Watts RMS and 600 W Peak power handling. These power ratings allow the subwoofer to produce deep and powerful bass that enhances sound in any marine environment. With a depth of 116 mm and an Xmech of ±19 mm, the subwoofer achieves precise bass reproduction even at high volume. The optimized motor and suspension design also ensures minimal distortion without the need for a special enclosure. The combination of high power handling and thoughtful design makes the HMS 10 S4-LD-G.1 ideal for impressive bass performance.

What are the dimensions of the Hertz HMS 10 S4-LD-G.1 Marine Subwoofer?

The Hertz HMS 10 S4-LD-G.1 has a size of 25 cm (10 inches), making it ideal for marine applications. The physical dimensions of the subwoofer are W 280 mm x H 227 mm x D 164 mm, with a mounting depth of 116 mm. This compact design allows for flexible installation on boats. The magnet measures 140 x 60 x 30 mm, while the weight of the component is 5.1 kg. These precise dimensions are crucial for integration into existing systems and provide a balance between performance and space-saving design.

How is the HMS 10 S4-LD-G.1 Subwoofer installed?

The installation of the HMS 10 S4-LD-G.1 Subwoofer from Hertz is particularly easy due to the Free Air Design. Its dimensions ensure that it can be mounted without a special enclosure, significantly simplifying the installation process. Integration typically occurs in the interior of a boat, with the brackets being easily accessible. The sporty grill that houses the LEDs is removable to allow for custom painting. When installing, the mounting depth of 116 mm should be considered. Thanks to the design, the subwoofer is excellent for demanding marine use.

What LED features does the Hertz HMS 10 S4-LD-G.1 offer?

The Hertz HMS 10 S4-LD-G.1 is equipped with integrated LEDs in the sporty white grill, providing visual enhancement and customization. This LED feature allows the appearance of the subwoofer to seamlessly match the boat's environment. The grill can be painted to add a personal touch to the ship's design. Thanks to the HM RGB 1 BK remote control available as an accessory, the light colors and modes can be flexibly changed to suit the mood or event. This adds a special ambiance to any event at sea.

What membrane materials and protection properties does the HMS 10 S4-LD-G.1 have?

The Subwoofer HMS 10 S4-LD-G.1 uses a polypropylene membrane treated with UV inhibitors. These special materials ensure that the product is resistant to the harsh conditions of maritime use. Protection against UV radiation improves the longevity and stability of the membrane in the long term, which can be crucial at sea. The use of high-density magnetic flux ferrite contributes to the impressive performance and efficiency of the Subwoofer by providing strong magnetic inductance. This combination of material choice and protective mechanisms makes the HMS 10 S4-LD-G.1 ideal for continuous operation in intense maritime environments.

What are the Thiele-Small parameters of the Hertz HMS 10 S4-LD-G.1?

The HMS 10 S4-LD-G.1 is equipped with specific Thiele-Small parameters that precisely describe its acoustic performance. The Qts value is 0.71, indicating the overall quality factor behavior, while the Qes is 0.76 and the Qms is 11, representing the electrical and mechanical quality values. The resonance frequency Fs is 41 Hz, the effective moving mass Mms is 69 g, and the equivalent volume Vas is specified as 37 liters. These values provide insight into the dynamic performance of the Subwoofer, characterize its efficiency, and define, among other things, the bass properties in the specific maritime context.

Is the Hertz HMS 10 S4-LD-G.1 Subwoofer compatible with various types of ships?

The Hertz HMS 10 S4-LD-G.1 Subwoofer is suitable for a wide range of ship types thanks to its free air design and robust construction. Due to its compact size and straightforward installation requirements, it can be easily integrated into various boat configurations. Installation is done without the need for a special enclosure, significantly expanding its application possibilities on different ships. The universal sizing and custom design with adjustable LED lighting make it suitable for private yachts as well as larger sea vessels. This offers flexibility while maintaining full sound performance.

How do the magnet and voice coils of the HMS 10 S4-LD-G.1 affect sound quality?

The HMS 10 S4-LD-G.1 uses a powerful magnet measuring 140 x 60 x 30 mm and a large voice coil of Ø 50 to ensure exceptional sound quality. The high flux density magnet allows the Subwoofer to generate strong and consistent magnetic fields, which in turn enables precise control of the diaphragm movement. This ensures clear and distortion-free bass reproduction. The large voice coil improves thermal handling and provides higher load capacity with consistent power delivery. This combination of magnet and coil technology ensures reliable reproduction of low frequencies.

What role does the optimized motor and suspension design play in the Hertz HMS 10 S4-LD-G.1?

The optimized motor and suspension design of the HMS 10 S4-LD-G.1 is crucial for the performance of this marine Subwoofer. Through targeted design optimization, the Subwoofer can operate in Free Air, making it ideal for use on boats without special enclosures. This design provides a long linear excursion capability, allowing for high performance with low distortion. Additionally, the optimized design relieves the main speakers by taking over the reproduction of the lowest frequencies. The result is improved efficiency of the entire sound system and more powerful bass representation with minimal space requirements.

What advantages does the Hertz HMS 10 S4-LD-G.1 offer with its polypropylene diaphragm?

The use of a polypropylene diaphragm with UV inhibitors in the Hertz HMS 10 S4-LD-G.1 offers several advantages. Most importantly, it ensures the durability and resistance of the Subwoofer against UV radiation, which is essential in marine environments. These special material properties prevent fading and brittleness of the diaphragm due to constant sun exposure. Furthermore, the lightweight yet robust material contributes to precise bass reproduction by allowing fast diaphragm movements. This results in a clean and distortion-free sound that fully meets the demands of rigorous marine use.
